| HAWKI trending system: HISTORY report |
|
|
|
Last update: 2014-01-15T07:01:17 (UT)
|
|
|
*Date on this monitor changes at 21:00 UT |
|
|
|
|
Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
9.15 |
ADU |
OFF | ± 0.5 |
136 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 4, DIT=2.0 |
| 2 |
• | QC1DB |
MEDIAN |
8.45 |
ADU |
OFF | ± 0.5 |
136 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 3, DIT=2.0 |
| 3 |
• | QC1DB |
MEDIAN |
4.78 |
ADU |
OFF | ± 2.0 |
83 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 4, DIT=300 |
| 4 |
• | QC1DB |
MEDIAN |
5.6 |
ADU |
OFF | ± 2.0 |
83 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 3, DIT=300 |
| 5 |
• | QC1DB |
MEDIAN |
10.4 |
ADU |
OFF | ± 0.5 |
136 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 1, DIT=2.0 |
| 6 |
• | QC1DB |
MEDIAN |
9.15 |
ADU |
OFF | ± 0.5 |
136 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 2, DIT=2.0 |
| 7 |
• | QC1DB |
MEDIAN |
6.26 |
ADU |
OFF | ± 2.0 |
83 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 1, DIT=300 |
| 8 |
• | QC1DB |
MEDIAN |
5.37 |
ADU |
OFF | ± 2.0 |
83 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 2, DIT=300 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local text file
|
| Plot 5 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 10.4 | ADU |
| rel. thresholds: | 9.858681...10.858681 | ADU |
| N_data plotted: | 136 |
| [click on plot for closeup] |
| Plot 6 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 9.15 | ADU |
| rel. thresholds: | 8.6530205...9.6530205 | ADU |
| N_data plotted: | 136 |
| [click on plot for closeup] |
| Plot 2 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 8.45 | ADU |
| rel. thresholds: | 7.952656...8.952656 | ADU |
| N_data plotted: | 136 |
| [click on plot for closeup] |
| Plot 1 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 9.15 | ADU |
| rel. thresholds: | 8.648738...9.648738 | ADU |
| N_data plotted: | 136 |
| [click on plot for closeup] |
| Plot 7 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 6.26 | ADU |
| rel. thresholds: | 4.256128...8.256128 | ADU |
| N_data plotted: | 83 |
| [click on plot for closeup] |
| Plot 8 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 5.37 | ADU |
| rel. thresholds: | 3.3683575...7.3683575 | ADU |
| N_data plotted: | 83 |
| [click on plot for closeup] |
| Plot 4 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 5.6 | ADU |
| rel. thresholds: | 3.5998115...7.5998115 | ADU |
| N_data plotted: | 83 |
| [click on plot for closeup] |
| Plot 3 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 4.78 | ADU |
| rel. thresholds: | 2.7833085...6.7833085 | ADU |
| N_data plotted: | 83 |
| [click on plot for closeup] |
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot, data points belonging to that date are specially marked.
If configured,
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
|
