SINFONI trending system: HISTORY plot
Last update: 2011-06-26T16:51:25 (UT)
same group: science_persistence science_std science_wave
close window history: 2009 2010   2011   HEALTH FULL
  ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB none   days VAL-0.5,0.5 495 qc_delta_time this | last_yr | all Difference in time between science data and its associated telluric standard (in days).
2 •QC1DB none   unitless VAL-0.7,0.7 494 qc_delta_am this | last_yr | all Difference in airmass between science data and its associated telluric standard.
*Data sources: QC1DB: QC1 database; LOCAL: local text file
Plot 1
data source:sinfoni_sci
(QC1 database)
parameter | dataset:qc_delta_time•
average:none
fixed thresholds:-0.5...0.5days
N_data:495
[click on plot for closeup]
Plot 2
data source:sinfoni_sci
(QC1 database)
parameter | dataset:qc_delta_am•
average:none
fixed thresholds:-0.7...0.7unitless
N_data:494
[click on plot for closeup]
This plot

These are the trending plots for the SINFONI QC parameters derived from the SCIENCE products.

Science product monitoring has been implemented beginning 2009-05-01.

NOTE: Large positive outliers in the delta time or delta airmass plots are the result of a missing airmass keyword in either the science or STD image.
NOTE 2: From 2009-10-01 the delta time/airmass values are measured from mid-OB. Previously, the delta time/airmass values are those of the first science frame in the OB.

Find more information about SINFONI Science data here.

Other QC parameters are also trended here.

General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
