SINFONI trending system: HISTORY report
HELP USERS-GUIDE MORE
Last update: 2016-07-15T03:30:27 (UT)
same group: HCAO
close window history: 2008 2009 2010 2011 2012 2013 2014 2015   2016   2017   2018 2019   HEALTH FULL
  ... ... ... ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 0.881 unitless VAL0.45,1.0 173 qc_strehl_med this | last_yr | all median strehl ratio of fibre as computed over full K-band.
2 oQC1DB MEDIAN 0.57 unitless x 10-4 none  173 qc_strehl_mederr this | last_yr | all rms of median strehl ratio of fibre.
(this data set is NOT scored)
3 •QC1DB MEDIAN 63.9 counts VAL15.,110 173 qc_frmdif_meanflux this | last_yr | all average flux level in fibre frame extracted spectrum (counts).
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
data source:sinfoni_hcao
(QC1 database)
dataset:qc_strehl_med•
median:0.881unitless
fixed thresholds:0.45...1.0unitless
N_data plotted:173
[click on plot for closeup]
Plot 2
data source:sinfoni_hcao
(QC1 database)
dataset:qc_strehl_mederro
median:0.57unitless x 10-4
thresholds:none
N_data plotted:173
[click on plot for closeup]
Plot 3
data source:sinfoni_hcao
(QC1 database)
dataset:qc_frmdif_meanflux•
median:63.9counts
fixed thresholds:15.0...110counts
N_data plotted:173
[click on plot for closeup]
General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
