SINFONI trending system: FULL plot
Last update: 2010-12-22T11:43:03 (UT)
| now: 2012-05-24T13:31:24 (UT)
HELP USERS-GUIDE MORE
same group: wavelength res_power   slit_pos#17 fwhm_lines N_lines lamp_mean lamp_max
DATE*: [?] 2012-05-17
report | NR 		2012-05-18
report | NR 		2012-05-19
report | NR 		2012-05-20
report | NR 		2012-05-21
report | NR 		2012-05-22
report | NR 		2012-05-23
report | NR
P...
Product quality:
products products products products products products products
  no OPSLOG data
close window history: 2005 2006 2007 2008 2009 2010   2011   HEALTH FULL
  ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research: News:
- png file - advanced studies: QC1 browser | QC1 plotter

Plot
?		 Symb
?		 Source
*		 OPS?
**		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB no MEDIAN 1027.53003 pixels none   1154 qc_slit17_x all (full time range) X-position of slitlet #17 in J-band at the 250 mas camera scale
1 •QC1DB no MEDIAN 1026.70996 pixels none   78 qc_slit17_x all (full time range) X-position of slitlet #17 in the J-band at the 100 mas camera scale
1 •QC1DB no MEDIAN 1025.18506 pixels none   45 qc_slit17_x all (full time range) X-position of slitlet #17 in the J-band at the 25 mas camera scale
2 •QC1DB no MEDIAN 1026.13 pixels none   1054 qc_slit17_x all (full time range) X-position of slitlet #17 in the H-band at the 250 mas camera scale
2 •QC1DB no MEDIAN 1025.34998 pixels none   140 qc_slit17_x all (full time range) X-position of slitlet #17 in the H-band at the 100 mas camera scale
2 •QC1DB no MEDIAN 1024.53003 pixels none   29 qc_slit17_x all (full time range) X-position of slitlet #17 in the H-band at the 25 mas camera scale
3 •QC1DB no MEDIAN 1026.14001 pixels none   1185 qc_slit17_x all (full time range) X-position of slitlet #17 in the K-band at the 250 mas camera scale
3 •QC1DB no MEDIAN 1025.93005 pixels none   408 qc_slit17_x all (full time range) X-position of slitlet #17 in the K-band at the 100 mas camera scale
3 •QC1DB no MEDIAN 1024.52539 pixels none   243 qc_slit17_x all (full time range) X-position of slitlet #17 in the K-band at the 25 mas camera scale
4 •QC1DB no MEDIAN 1025.33997 pixels none   1233 qc_slit17_x all (full time range) X-position of slitlet #17 in the H+K-band at the 250 mas camera scale
4 •QC1DB no MEDIAN 1024.48999 pixels none   194 qc_slit17_x all (full time range) X-position of slitlet #17 in the H+K-band at the 100 mas camera scale
4 •QC1DB no MEDIAN 1024.21997 pixels none   138 qc_slit17_x all (full time range) X-position of slitlet #17 in the H+K-band at the 25 mas camera scale
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: to indicate that OPSLOG data are included
Plot 1
data source:sinfoni_wave
(QC1 database)
parameter | dataset:
(numbers applicable to • )		qc_slit17_x•
median:1027.53003pixels
thresholds:none
N_data:1154
[click on plot for closeup]
Plot 2
data source:sinfoni_wave
(QC1 database)
parameter | dataset:
(numbers applicable to • )		qc_slit17_x•
median:1026.13pixels
thresholds:none
N_data:1054
[click on plot for closeup]
Plot 3
data source:sinfoni_wave
(QC1 database)
parameter | dataset:
(numbers applicable to • )		qc_slit17_x•
median:1026.14001pixels
thresholds:none
N_data:1185
[click on plot for closeup]
Plot 4
data source:sinfoni_wave
(QC1 database)
parameter | dataset:
(numbers applicable to • )		qc_slit17_x•
median:1025.33997pixels
thresholds:none
N_data:1233
[click on plot for closeup]
General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
