UVES trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-03-28T13:26:13 (UT)
  | now: 2024-03-28T23:51:55 (UT) muc02 QC pipeline: uves-6.1.11 (installed 2023-06-22)
same group: Resolution   B_CD2_A B_CD2_B RU_CD3_A RU_CD3_B RL_CD3_A RL_CD3_B Thermal FWHM
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
UVES news:
Report news:
DATE*: [?] 2024-03-21
report | NLT
2024-03-22
report | NLT
2024-03-23
report | NLT
2024-03-24
report | NLT
2024-03-25
report | NLT
2024-03-26
report | NLT
2024-03-27
report | NLT
2024-03-28
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw no CAL raw files
P...
CAL product quality:
products products products products products products products no CAL products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB none   NONE none  248 resol_med this | last_yr | all Resolution vs. T4 for CD#2, BLUE 437, 1x1, 0.4 arcs slit
2 QC1DB none   NONE none  53 resol_med this | last_yr | all Resolution vs. T4 for CD#2, BLUE 437, 1x1, 1 arcs slit
3 QC1DB none   NONE none  196 resol_med this | last_yr | all Resolution vs. T4 , CHIPU 580 1x1 data
4 QC1DB none   NONE none  195 resol_med this | last_yr | all Resolution vs. T4 , CHIPL 580 1x1 data
5 QC1DB none   NONE none  237 resol_rms this | last_yr | all Resolution rms vs. T4 for CD#2, BLUE 437, 1x1, 0.4 arcs slit
6 QC1DB none   NONE none  50 resol_rms this | last_yr | all Resolution rms vs. T4 for CD#2, BLUE 437, 1x1, 1 arcs slit
7 QC1DB none   NONE none  182 resol_rms this | last_yr | all Resolution rms vs. T4 , CHIPU 580 1x1 data
8 QC1DB none   NONE none  186 resol_rms this | last_yr | all Resolution rms vs. T4 , CHIPL 580 1x1 data
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_med
average:none
thresholds:none
N_data plotted:248
[click plot for closeup]
Plot 2
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_med
average:none
thresholds:none
N_data plotted:53
[click plot for closeup]
Plot 3
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_med
average:none
thresholds:none
N_data plotted:196
[click plot for closeup]
Plot 4
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_med
average:none
thresholds:none
N_data plotted:195
[click plot for closeup]
Plot 5
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_rms
average:none
thresholds:none
N_data plotted:237
[click plot for closeup]
Plot 6
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_rms
average:none
thresholds:none
N_data plotted:50
[click plot for closeup]
Plot 7
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_rms
average:none
thresholds:none
N_data plotted:182
[click plot for closeup]
Plot 8
scores: not implemented
data source:uves_wave
(QC1 database)
dataset:resol_rms
average:none
thresholds:none
N_data plotted:186
[click plot for closeup]
This plot

This is the trending report for monitoring the dependencies between the temperature and UVES Resolution based on QC parameters derived from wavelength calibration frames (WAVE_ECH). It trends the measured resolution in the Health Check calibrations which are taken in BLUE (437nm) and RED (580nm) settingis.

The resolutions (from the user manual) are :

SLITW R_blue R_red(L) old_R_red(U)
#2.1 20000 20000 19000
#2.0 22000 22000 20900
#1.50 31000 31000 29450
#1.40 32000 32000 30400
#1.30 34000 34000 32300
#1.20 37000 37000 35150
#1.10 39000 39000 37050
#1.00 41000 42000 39900
#0.90 44000 46000 43700
#0.80 50000 53000 50350
#0.70 54000 60000 57000
#0.60 59000 68000 64600
#0.50 65000 78000 74100
#0.40 71000 91000 86450
#0.30 78000 108000 102600
#0.20 82000 129000 122550


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
