VIMOS trending system: HISTORY plot

Last update: 2007-06-22T07:42:15 (UT)

close window

history:

2003

2004

2005

2006

2007

2008

2009

HEALTH

...

Print:	Information and research:
- png file	- advanced studies: QC1 browser \| QC1 plotter

Plot	Symbol [info]	Source*	Average [info]			Thresholds [info]		N_data	Data downloads	Remarks
Plot	Symbol [info]	Source*	method	value	unit	method	value	N_data	Data downloads	Remarks
1	•	`QC1DB`	`MEDIAN`	`1.843`	`e/ADU`	`VAL`	`0,1.86`	`8`	this \| last_yr \| all	CONAD from U filter flats
1	•	`QC1DB`	`MEDIAN`	`1.906`	`e/ADU`	`none`		`6`	this \| last_yr \| all	CONAD from B filter flats
1	•	`QC1DB`	`MEDIAN`	`1.855`	`e/ADU`	`none`		`1`	this \| last_yr \| all	CONAD from V filter flats
1	•	`QC1DB`	`MEDIAN`	`1.860`	`e/ADU`	`none`		`3`	this \| last_yr \| all	CONAD from R filter flats
1	•	`QC1DB`	`MEDIAN`	`1.917`	`e/ADU`	`none`		`9`	this \| last_yr \| all	CONAD from I filter flats

2	•	`QC1DB`	`MEDIAN`	`1.662`	`e/ADU`	`VAL`	`0,1.70`	`4`	this \| last_yr \| all	CONAD from U filter flats
2	•	`QC1DB`	`MEDIAN`	`1.752`	`e/ADU`	`none`		`6`	this \| last_yr \| all	CONAD from B filter flats
2	•	`QC1DB`	`MEDIAN`	`1.687`	`e/ADU`	`none`		`6`	this \| last_yr \| all	CONAD from V filter flats
2	•	`QC1DB`	`MEDIAN`	`1.706`	`e/ADU`	`none`		`8`	this \| last_yr \| all	CONAD from R filter flats
2	•	`QC1DB`	`MEDIAN`	`1.764`	`e/ADU`	`none`		`2`	this \| last_yr \| all	CONAD from I filter flats

3	•	`QC1DB`	`MEDIAN`	`1.902`	`e/ADU`	`VAL`	`0,1.95`	`1`	this \| last_yr \| all	CONAD from U filter flats
3	•	`QC1DB`	`MEDIAN`	`1.965`	`e/ADU`	`none`		`6`	this \| last_yr \| all	CONAD from B filter flats
3	•	`QC1DB`	`MEDIAN`	`1.904`	`e/ADU`	`none`		`2`	this \| last_yr \| all	CONAD from V filter flats
3	•	`QC1DB`	`MEDIAN`	`1.915`	`e/ADU`	`none`		`11`	this \| last_yr \| all	CONAD from R filter flats
3	•	`QC1DB`	`MEDIAN`	`1.963`	`e/ADU`	`none`		`9`	this \| last_yr \| all	CONAD from I filter flats

4	•	`QC1DB`	`MEDIAN`	`1.773`	`e/ADU`	`VAL`	`0,1.80`	`4`	this \| last_yr \| all	CONAD from U filter flats
4	•	`QC1DB`	`MEDIAN`	`1.878`	`e/ADU`	`none`		`6`	this \| last_yr \| all	CONAD from B filter flats
4	•	`QC1DB`	`MEDIAN`	`1.790`	`e/ADU`	`none`		`1`	this \| last_yr \| all	CONAD from V filter flats
4	•	`QC1DB`	`MEDIAN`	`1.816`	`e/ADU`	`none`		`3`	this \| last_yr \| all	CONAD from R filter flats
4	•	`QC1DB`	`MEDIAN`	`1.923`	`e/ADU`	`none`		`10`	this \| last_yr \| all	CONAD from I filter flats

*Data sources: OPSLOG: Paranal ops logs; QC1DB: QC1 database; LOCAL: local text file

This plot

Trending plot for CONAD (conversion factor from ADU to electrons).

The conversion factor is determined from lamp flats taken with low gain. The nominal value for each detector is indicated (dashed line).

General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
