| Plot |
Symbol
[info] |
Source* |
Average [info] |
Thresholds [info] |
N_data |
Data downloads |
Remarks |
| method |
value |
unit |
method |
value |
|
1 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(xx), Q2 |
|
1 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(xx), Q1 |
|
1 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(xx), Q3 |
|
1 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(xx), Q4 |
|
|
2 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(xy), Q2 |
|
2 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(xy), Q1 |
|
2 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(xy), Q3 |
|
2 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(xy), Q4 |
|
|
3 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(yx), Q2 |
|
3 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(yx), Q1 |
|
3 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(yx), Q3 |
|
3 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(yx), Q4 |
|
|
4 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(yy), Q2 |
|
4 |
• | LOCAL |
none | |
pix/mm |
none | |
88 |
n/a |
coefficient a(yy), Q1 |
|
4 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(yy), Q3 |
|
4 |
• | LOCAL |
none | |
pix/mm |
none | |
87 |
n/a |
coefficient a(yy), Q4 |
|
|
|
*Data sources: OPSLOG: Paranal ops logs; QC1DB: QC1 database; LOCAL: local text file
|
This plot
Trending plots for monitoring the coefficients of the mask to CCD transformation.
The transformation is as follows:
X = a(xx)*x + a(xy)*y + x(0)
Y = a(yx)*x + a(yy)*y + y(0)
with (x,y) being mask coordinates in mm and (X,Y) CCD coordinates in pixel.
X direction is along the slit orientation, y direction is perpendicular to
the slits (i.e. in dispersion direction).
These trending plots show the time
evolution of the matrix coefficients a(xx), a(xy), a(yx), and a(yy). The
diagonal coefficients a(xx) and a(yy) give the scale factor between mask and
CCD (near 8.4 pixel/mm). The coefficients a(xy) and a(yx) give the rotation
and should be near zero.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot, data points belonging to that date are specially marked.
If configured,
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
