VIMOS trending system: HISTORY plot
Last update: 2009-01-11T04:36:01 (UT)
close window history: 2006 2007   2008   2009   HEALTH
  ...
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 196.25 ADU 3SIG± 4.30402 67 median_master this | last_yr | all average across all detectors, high gain
2 •QC1DB MEDIAN 8.30751 ADU none   67 ron_bias this | last_yr | all average across all detectors, high gain
3 •QC1DB MEDIAN 7.83 ADU 3SIG± 4.48588 67 rms_master this | last_yr | all average across all detectors, high gain
4 •QC1DB MEDIAN 6.01065 ADU 3SIG± 4.57603 67 fpn_master this | last_yr | all average across all detectors, high gain
5 •QC1DB MEDIAN 0.66502 ADU 3SIG± 0.35104 67 struc_master this | last_yr | all average across all detectors, high gain
6 •QC1DB MEDIAN 7.61577 ADU 3SIG± 5.02594 67 median_master this | last_yr | all rms of average across all detectors, high gain
7 •QC1DB MEDIAN 1.66082 ADU none   67 ron_bias this | last_yr | all rms of average across all detectors, high gain
8 •QC1DB MEDIAN 8.17032 ADU 3SIG± 4.30899 67 rms_master this | last_yr | all rms of average across all detectors, high gain
9 •QC1DB MEDIAN 9.16467 ADU 3SIG± 4.86184 67 fpn_master this | last_yr | all rms of average across all detectors, high gain
10 •QC1DB MEDIAN 0.82325 ADU 3SIG± 0.29934 67 struc_master this | last_yr | all rms of average across all detectors, high gain
*Data sources: QC1DB: QC1 database; LOCAL: local text file
This plot

[an error occurred while processing this directive]

General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
