CHANGE RECORD

ISSUE

DATE

SECTION/

PAGE

AFFECTED

REASON/INITIATION

DOCUMENTS/REMARKS

1.0 / prep 1

20/12/2000

All

NOVEMBER 2000 - First Version by Eszter Pozna

Update for MAR2001 RELEASE by E. Pozna
1.1	08/04/2001	20,22,23,49, 52,81	VLTSW20010019-18: OCS.SUBSYST setup keyw no longer supported
		20 (49)	VLTSW20010017: always use INS.MODE is compulsory in the first SETUP
		11,31,36,54,80	VLTSW20010014: STOP cmd is not supported
		15,18,83	VLTSW20010054 : OCS.OCS.* à OCS.OS.*
		26,27,28	VLTSW20010012: no alias tables
		30	VLTSW20010044: db classes for each subsystem interface
		18,26,79	Config kw not supported OCSi.OCS.ALIAS
		25,26,42,51,77	Configuration file xxoControl.cfg->xxmcfgINS.cfg
		36	Cancel inactive exposures using command END
		37	Added description to FORWARD
		41	Added new sections in chapter 9.8 in SOS
		52	New section 11.10 db point/structure (FAQ)
		38	New section – binary tables

Update for MAR 2002 RELEASE by E. Pozna
ISSUE	DATE	SECTION	REASON/INITIATION/REMARKS
1.2	20/03/2002	4	VLTI module
		9.8.6.2	VLTSW20010618 : Multiple ICS headers
		9.4.5	VLTSW20010575 : Wait –first VLTSW20020051 : reply to wait command (9.4.5)
		9.5	VLTSW20010044:Life cycle (present in MAR2001 but not mentioned in doc)
		9.8.6	VLTSW20010691: Partial header files (New section)
		9.8, 9.8.5.3, 9.8.6.3, 9.8.4	SOS (new feature in MARCH2002) Sos interaction new section 9.8.4
		9.7.2	Exposure status
		9.7.4	VLTSW20010724: substates
		9.7.1	last expoId (updates)
		9.4.3.1,9.4.3.2, 9.4.3.5	VLTSW20010104 : SETUP (new sections) While exp running; repeate ; redeclare
		9.4.6	VLTSW20010535: END cmd
		9.4.7	VLTSW20010682: Forward
		9.9.2	VLTSW20010013 :default startup
		7.7	VLTSW20010494: default mode
		9.2,10.2	User specifed cfg keyword (AppConfigure argument)
		7 7.2 7.5, 7.3, 7.6	Configuration (VLTSW20010010/13, VLTSW20010448) DBROOT, DBIFROOT OCS.INSi.HDRCAT , default values for DCS/OS cfg kw.
		7.4	VLTSW20010448: TELESCOP fits kw (OCS.TEL.ID)
		13	Maintenance of boss
		11	FAQ added questions
		Reference	updated
		Appendix	updated

Update for APR2003 RELEASE by E. Pozna
ISSUE	DATE	SECTION	REASON/INITIATION/REMARKS
3	30/03/2003	7.7	VLTSW20020342- max number of modes
		10.1.1	VLTSW20020180 added overload able function SetupPostProc
		10.6	VLTSW20010458/VLTSW20020360/ VLTSW20020583 Operation bypassing the OS/SOS (new section)
		9.4.3.4	VLTSW20020256 SETUP –noExposure (new subsection )
		9.4.5 9.7.5 11.16	VLTSW20010669: WAIT -header Synchronization (new section)
		11.6.2	VLTSW20020478 additional fits header keywords at SOS level (new section)
		9.6.1	VLTSW20020427: supplementary 'arf' files are removed
		7.3	VLTSW20020281: added optional detector configuration keyword: OCS.DETi.WIPING to set wiping
		7.3	VLTSW20020280: added optional detector configuration keyword: OCS.DETi.STOP to leave detector ONLINE
		9.6	VLTSW20020431: auto add cfg and setup kws to FITS header VLTSW20010669: each exposure starts with a new empty header
		9.7.4	Added new substates
		6.6 10.2	New section about dictionaries Updated with dictionary info
		11.17	FAQ special online action
		9.4.3.3	Default mode (1 mode) – new section
		Appendix	CDT,dict,cfg updated

Update for APR2004 RELEASE by E. Pozna
ISSUE	DATE	SECTION	REASON/INITIATION/REMARKS
4	30/03/2004	7.1	VLTSW20030249 - added new cfg kw OCS.CON.LOGLEVEL
		8	VLTSW20020505 - new 'image file naming' scheme is applied as default : "Standard-Naming"
		9.4.5	VLTSW2003312 - added new parameter '-cond' to command WAIT
		9.4.5	VLTSW2003350 - added new parameter '-all' to command WAIT
		7.1	VLTSW20030387 – new configuration keyword OCS.ARC.TIMEOUT
		9.4.3.4	VLTSW20030119 - SETUP cmd without paremeter '-expoId' specified is considered as –noExposure
		10.1.1	VLTSW20030388 - Added overloadable empty functions ApplImageHandleProc()
		7.3	VLTSW20030149 - When cfg kw OCS.DETi.STOP is set, cmd ONLINE is only sent when state is not yet ONLINE.
		9.4.9	VLTSW20030250 New command ACCESS
		9.10	New section: archiver process
		11.16	FAQ updates
		Appendix	Manpage,CDT, dictionary update

Update for JAN2006 RELEASE by E. Pozna
ISSUE	DATE	SECTION	REASON/INITIATION/REMARKS
5	06/12/2005	7.3 9.6.3	VLTSW20040364 Handling of multiple files during one exposure (e.g. IR mosaic mode)
		6.1 9.4.5 9.7.2 9.10	VLTSW2004025, VLTSW20030523 Sequential handling of archiver process queue ; VLTSW20040387 Check existence of Archiver process VLTSW20050050 Performance test of Archiver process (9.10 new section)
		9.4.2	VLTSW20040155 Check TCS state during ONLINE VLTSW20050122 Report error of sub-command
		7.5 9.7.5	VLTSW20020714 ICS Check for ICS substate before internal commands (EXPEND/EXPSTART) are sent VLTSW20050161 - Collect all available headers in case of error after image has been generated
		9.4.6	VLTSW20050161 - Command END is allowed in STANDBY state.
		6.12.	Default loglevel - no long on stdout.
		8	Usage of OCS.DET.IMGEXT in setting the filename.
		7.2	Maximum number of dictionaries per interface
		10.1, 10.1.2	Overloading boss (new section)

Update for FEB2007 RELEASE by E. Pozna
ISSUE	DATE	SECTION	REASON/INITIATION/REMARKS
6	09/02/2007	9.6.3	VLTSW20060018- Sort the fits extentions into Alphabetical order (OCS.DETi.ARCMODE MERGEALL)
		9.4.8	VLTSW20060232-Support ADDFITS command options -extnum –extname
		9.6.3	VLTSW20050387 Handle DIT files without merging (OCS.DETi.ARCMODE NORMAL)
		9.4.5.1, 7.3	VLTSW20060119 Support of Optimised sequence of exposures on IRACE detector (OCS.DET.OPTSEQ).

TABLE OF CONTENTS

1 Scope................................................................................................................................................................................................ 3

2 Documents and Acronyms................................................................................................................................................ 3

2.1 Applicable Documents................................................................................................................................................ 3

2.2 Reference Documents.................................................................................................................................................. 3

2.3 Acronyms............................................................................................................................................................................ 3

3 Introduction.............................................................................................................................................................................. 3

4 Overview....................................................................................................................................................................................... 3

5 User’s Guide.................................................................................................................................................................................. 3

6 Getting Started........................................................................................................................................................................ 3

6.1 The processes of the Observation Software............................................................................................... 3

6.2 Initializing......................................................................................................................................................................... 3

6.3 Server class....................................................................................................................................................................... 3

6.4 State handling................................................................................................................................................................ 3

6.5 Configuration.................................................................................................................................................................. 3

6.6 Dictionary.......................................................................................................................................................................... 3

6.7 Command handling...................................................................................................................................................... 3

6.8 Database events............................................................................................................................................................ 3

6.9 Interfaces........................................................................................................................................................................... 3

6.10 Exposures............................................................................................................................................................................ 3

6.11 OS as Super OS.................................................................................................................................................................... 3

6.12 Logging.................................................................................................................................................................................. 3

7 Configuration Guide.............................................................................................................................................................. 3

7.1 General system configuration keywords................................................................................................... 3

7.2 Configuration of the subsystems....................................................................................................................... 3

7.3 Additional detector configuration keywords........................................................................................ 3

7.4 Additional TCS configuration keywords..................................................................................................... 3

7.5 Additional ICS configuration keywords....................................................................................................... 3

7.6 OS Subsystem Configuration Keywords.......................................................................................................... 3

7.7 Instrument modes......................................................................................................................................................... 3

8 Setup Guide.................................................................................................................................................................................... 3

9 Programmer’s Guide.............................................................................................................................................................. 3

9.1 Initialisation................................................................................................................................................................... 3

9.2 The Server class.............................................................................................................................................................. 3

9.3 Interface classes.......................................................................................................................................................... 3

9.4 Standard commands.................................................................................................................................................. 3

9.4.1 STATE Command and related functions....................................................................................................................... 3

9.4.2 State changing commands.............................................................................................................................................. 3

9.4.3 SETUP Command.............................................................................................................................................................. 3

9.4.4 START Command.............................................................................................................................................................. 3

9.4.5 WAIT Command................................................................................................................................................................. 3

9.4.6 Other exposure control commands................................................................................................................................ 3

9.4.7 FORWARD command........................................................................................................................................................ 3

9.4.8 Commands operating on fits file.................................................................................................................................... 3

9.4.9 ACCESS command............................................................................................................................................................ 3

9.4.10 Commands VERSION and DEBUG........................................................................................................................... 3

9.5 Database and database events.......................................................................................................................... 3

9.6 The final image................................................................................................................................................................ 3

9.6.1 Partial header files........................................................................................................................................................... 3

9.6.2 Binary Tables..................................................................................................................................................................... 3

9.6.3 Handling of multiple files during one exposure.......................................................................................................... 3

9.7 Exposure............................................................................................................................................................................... 3

9.7.1 The exposure table............................................................................................................................................................ 3

9.7.2 Exposure status................................................................................................................................................................. 3

9.7.3 Functions accessing the exposure table...................................................................................................................... 3

9.7.4 Main steps of exposure..................................................................................................................................................... 3

9.7.5 Synchronization................................................................................................................................................................ 3

9.8 Super Observation Software (SOS)...................................................................................................................... 3

9.8.1 Configuration of OS subsystem...................................................................................................................................... 3

9.8.2 Hierarchical setup keywords.......................................................................................................................................... 3

9.8.3 Dictionary for SOS............................................................................................................................................................ 3

9.8.4 SOS interaction................................................................................................................................................................. 3

9.8.5 Command handling.......................................................................................................................................................... 3

9.8.6 Creating the finale image file by SOS........................................................................................................................... 3

9.8.7 Not-BOSS-based OS as a subsystem of SOS................................................................................................................. 3

9.9 Startup of Main process........................................................................................................................................... 3

9.9.1 Command line options..................................................................................................................................................... 3

9.9.2 Default Startup.................................................................................................................................................................. 3

9.10 Archiver process............................................................................................................................................................ 3

9.10.1 Startup of Archiver Process....................................................................................................................................... 3

9.10.2 Command queue.......................................................................................................................................................... 3

9.10.3 Performance of Archiver process.............................................................................................................................. 3

10 Observation Software Based on BOSS.................................................................................................................... 3

10.1 Function overloading................................................................................................................................................ 3

10.1.1 Functions to be overloaded....................................................................................................................................... 3

10.1.2 Overload of non empty functions.............................................................................................................................. 3

10.2 Additional configuration keyword................................................................................................................ 3

10.3 Additional setup keyword...................................................................................................................................... 3

10.4 Add new command........................................................................................................................................................ 3

10.4.1 Send a message............................................................................................................................................................ 3

10.5 Modifying existing command callbacks....................................................................................................... 3

10.5.1 Declare mode, detector, subsystem, exposure status............................................................................................. 3

10.6 Operation bypassing the OS/SOS............................................................................................................................ 3

11 FAQ and Troubleshooting................................................................................................................................................ 3

11.1 Manual start up of BOSS OS.................................................................................................................................... 3

11.2 Parameter ‘-expoId’ in the commands............................................................................................................. 3

11.3 Subsystem list or instrument mode is not declared in the setup................................................. 3

11.4 Usage of command STATUS...................................................................................................................................... 3

11.5 Usage of command ADDFITS..................................................................................................................................... 3

11.6 Add additional keyword to the fits header.............................................................................................. 3

11.6.1 Example-1: Add keyword to OS image.................................................................................................................... 3

11.6.2 Example-2: Add keyword to SOS image file........................................................................................................... 3

11.7 Dictionary for OS........................................................................................................................................................... 3

11.8 Parameter ‘-detId’ in command........................................................................................................................... 3

11.9 Place of pre-processing functions...................................................................................................................... 3

11.10 Instrument with no detector............................................................................................................................... 3

11.11 Data base point ‘NewData’..................................................................................................................................... 3

11.12 Additional Action when Exposure fails, succeeds or aborted...................................................... 3

11.13 Interface for subsystem that does not fall into any of the given categories.................. 3

11.14 What to do when OS subsystem of SOS is not based on BOSS............................................................. 3

11.15 TCS in the SOS structure............................................................................................................................................ 3

11.16 File merging........................................................................................................................................................................ 3

11.17 Add Special Online Action........................................................................................................................................ 3

12 Installation Guide................................................................................................................................................................. 3

13 Maintenance................................................................................................................................................................................ 3

14 Reference...................................................................................................................................................................................... 3

14.1 Manpage of the bossControl................................................................................................................................. 3

14.2 Manpage of the bossSERVER class....................................................................................................................... 3

14.3 Manpage of bossAbortCB, bossStartCB, bossPauseCB…....................................................................... 3

14.4 Manpage of bossEXPOSURE class.......................................................................................................................... 3

14.5 Manpage of bossINSMODE class............................................................................................................................ 3

14.6 Manpage of bossINTERFACE_DCS............................................................................................................................ 3

14.7 Manpage of bossINTERFACE_CCD............................................................................................................................ 3

14.8 Manpage of bossArchiver................................................................................................................................... 3

This page has been left intentionally blank.

1 Scope

This document describes the BOSS package.

2 Documents and Acronyms

2.1 Applicable Documents

The following documents, of the exact issue shown, form a part of this document to the extent specified herein. In the event of conflict between the documents referenced herein and the contents of this document, the contents of this document shall be considered as a superseding requirement.

Reference	Document Number	Issue	Date	Title
[AD 01]	GEN-SPE-ESO-19400-0794	2.0	31/10/1997	DICB - Data Interface Control Document
[AD 02]	VLT-SPE-ESO-10000-0011	2.0	30/09/1992	VLT Software Requirements Specification
[AD 03]	VLT-PRO-ESO-10000-0228	1.0	10/03/1993	VLT Software Programming Standards
[AD 04]	VLT-PLA-ESO-10000-0441	1.0	01/05/1995	VLT Science Operation Plan
[AD 05]	VLT-MAN-ESO-17210-0667	1.0	03/12/1997	Guidelines for VLT applications.
[AD 06]	VLT-SPE-ESO-17212-0001	2.0	23/02/1995	INS Software Specification
[AD 07]	VLT-SPE-ESO-17240-0385	2.1	15/07/1996	INS Common Software Specification
[AD 08]	VLT-ICD-ESO-17240-19400	2.6	17/11/1997	ICD between VCS and Archive
[AD 09]	VLT-ICD-ESO-17240-19200	1.0	29/10/1996	ICD between VCS and OH

2.2 Reference Documents

The following documents contain additional information and are referenced in the text:

Reference	Document Number	Issue	Date	Title
[RD 01]	VLT-MAN-ESO-17240-1973	2.0	03/01/2001	Template Instrument User Manual
[RD 02]	VLT-SPE-ESO-15400-0886	2.0	18/12/1996	XXXX ICS
[RD 03]	VLT-MAN_ESO-17110-0771	1.7	30/09/1999	CCS-Event Tool Kit –EVH
[RD 04]	VLT-MAN_ESO-17240-0853	1.1	06/05/1996	Objective SLX-OSLX
[RD 05]				VLT SW Installation
[RD 06]	VLT-ICD-ESO-17240-19400	2.0	17/11/97	VLT Archive System
[RD 07]	VLT-MAN-ESO-17240-0672	1.6	25/09/98	CCD Detectors Control Software-User Manual
[RD 08]	VLT-MAN-ESO-13640-1388	1.1	22/11/99	FIERA CCD Controller –Software User Manual
[RD 09]	VLT-MAN-ESO-14100-1878	1.2	13/12/99	IRACE DCS User Manual
[RD-10]	VLT-MAN-ESO-17240-2325	1.0	10/10/2000	Configuration Tool User Manual
[RD-11]	VLT-MAN-ESO-17240- 2153	1.3		Startup Tool

2.3 Acronyms

This document employs several abbreviations and acronyms to refer concisely to an item, after it has been introduced. The following list is aimed to help the reader in recalling the extended meaning of each short expression:


OS	Observation Software
BOSS	Base Observation Software Stub
XXXX	Template instrument
XXXX ICS	Template instrument ICS
XXXX OS	Template instrument OS
OS	Observation Software
SOS	Super OS. An OS that also controls OS.
<CAT>	Category denoting detector, instrument, telescope or OS subsystem
single exposure	One exposure.
parallel exposure	Exposures started at the same time
semi-parallel exposure	Exposures running simultaneously. Started separately from each other.

3 Introduction

This version of the UM describes the behavior of the BOSS package JAN2006 version.

The Observation software is responsible for taking exposures. Typically there is one image file generated during an exposure, and the exposures are executed sequentially. The concept of exposure refers to a whole series of procedures which begins with the setup of the instrument, preparation/start/monitoring of observation, handling of any user or system input, and ends with the finale handling of the image file during which all relevant information is saved into the header of the fits file and the image is sent to archive.

Nevertheless due to diverse requirements the OS is also capable of handling situations such as:

- more data files are generated during one exposures

- exposures are executed simultaneously on different detectors

- queuing the final handling of the image files for optimized exposure sequence

- setup of new exposures while previous one is still running

- controlling special subsystem

- ignoring part of the system

- supervising other OS-es.

The OS coordinates the communication between the subsystems of an instrument (ICS-es, DCS-es) and the telescope, handles user interaction with the system at any times (such as ending or aborting an exposures) and reports any unexpected events or errors occurring at all levels at any time.

The BOSS software (BOSS is short for base observation software stub) is designed to incorporate the common features of all observation software, while the OS that is based on BOSS should incorporate the specialties characterizing the instrument.

The observation software of a specific instrument therefore consists of a

· an instrument independent part (BOSS), and

· an instrument specific part (OS).

Boss includes the implementation of all the standard commands [AD 07]. In special cases, the default process can be extended. The communication with the subsystems takes place through interfaces. The package includes suitable interfaces for the most commonly used subsystems. When an exposure is finished, the VOLAC system [RD 06] is informed about the event (through a database point) to archive the image.

During the development of an OS one must exploit the features and functionality of BOSS as much as possible. This would make sure that the application OS-es have the least size, and therefore make the maintenance of the software easier.

The development of an OS is described through an example [RD 01]. The implementation of the most commonly used extra features (such as additional command or keyword) are described in Chapter 10.

Before going through the details of BOSS, it is recommended to install template instrument [RD 01] and run some templates. This would allow you to try out the features described in the following chapters and gain better understanding of the responsibilities of the OS.

4 Overview

The BOSS software package consist of the following modules:

Module	Description
ibac	Instrument Basic Application Classes Includes handling of logs, bits, strings, list ..
ixac	Instrument Extended Application Classes This module contains classes to handle common VLT data types (e.g. Short Fits Keywords, Database,…)
boss	Base Observation Software Stub Incorporates the implementation of the common properties of OS
osb	Interface module including the dictionary and CDT of boss ( ESO-VLT-DIC.BOSS, bossSERVER.cdt)
bossvlti[1]	Necessary only for VLTI instruments This small module contains the interface for ISS.

Release versions numbers:

MAR2001: boss 1.35.1.3, osb 1.12, bossvlti 1.2, ixac 1.37, ibac 1.26

MAR2002: boss 1.81, osb 1.20, bossvlti 1.5, ixac 1.43, ibac 1.29

APR2003: boss 1.106, osb 1.24, bossvlti 1.5, ixac 1.45, ibac 1.29

APR2004: boss 1.129, osb 1.28, bossvlti 1.6, ixac 1.46, ibac 1.30

JAN2006: boss 1.153, osb 1.36, bossvlti 1.6, ixac 1.49, ibac 1.33

FEB2007: boss 1.163, osb 1.39, bossvlti 1.6, ixac 1.51 , ibac 1.33

5 User’s Guide

The Template Instrument User Manual [RD 01] introduces a virtual instrument XXXX with the basic characteristics of real instruments, and also incorporates an observation software based on BOSS. Users are suggested to install and startup the template instrument and experience the effect of the OS commands by running a BOB template. Having an instrument running you gives a chance to test immediately the various features described below.

6 Getting Started

6.1 The processes of the Observation Software

The Observation Software of an instrument consists of two processes:

· ‘Main Control Process’

It is a multipurpose process the functionality of which is described in detail in this document.

The name of the process is ‘xxoControl’ where xx is the instrument ID. Only in case of complex instruments (handling more then one instruments by a super OS) it is allowed to have more then one OS Main process in the system.

· ‘Archiver Process’ [2]

The ‘File Handler Process’ is an auxiliary process that handles the post-processing of data, i.e. merging image file with header files. The process also takes care of informing VOLAC when the final image is ready. The name of this auxiliary process is composed of the string ‘bossArchiver_’ and the instrument id, e.g.: ‘bossArchiver_xxo’.

BOSS takes care of the communication between the ‘Main Control Process’ and the ‘Archiver Process’. There should be only one Archiver process for each control process. The existence of the Archiver process is checked by the Main process when the instrument is set to ONLINE and also at the start of the image taking exposures.

The subtasks of merging (i.e. names of header files, binary tables to be merged/appended /deleted) are saved in a supplementary file with extension ‘<imageFileName>.arf’, which is removed after the final image is ready. (When the process is started up in debug mode the supplementary files are renamed as ‘.arf_’ after successful handling, however all the ‘<imageFileName>.arf_’ files are removed during the startup of the Archiver process[3].)

BOSS also takes care of queuing the commands for the Archiver process should the requests from the Main process come faster then they are processed by the Archiver (see also 9.4.5).

The processes of the Instrument OS must be started at the same time[4]. For more information on the Archiver process see 9.10.

6.2 Initializing

There is a support class (bossCtrlMain.C) included in BOSS to support initialising and exiting CCS, initialising the boss ‘Main Control Process’, and setting the verbose level according to the command line options (see Chapter 9.1). The developers are recommended to apply it following the pattern of the main function of the template instrument [RD 01].

6.3 Server class

The heart of the boss package is the bossSERVER class. The default functionalities of BOSS can be altered when necessary.

The bossSERVER class includes special (normally empty) functions. In these functions (i.e. in their overloads) the implementation of the additional properties of the instruments should be placed.

Note that overloading other functions is also possible (as most of the function of the bossSERVER are declared virtual)[5], however it is not recommended.

In some cases the default properties of BOSS fully satisfies the requirement of an instrument. In this case the instrument can be startup based on its configuration and database using the auto startup functionality (see section 9.9.2).

6.4 State handling

The bossSERVER takes care of handling the states and sub-states of the instrument.

The states of the subsystems are [AD 07]: OFF, LOADED, STANDBY, ONLINE.

The state of the instrument is normally associated with the state of its subsystems and it represents the minimum states of all the subsystems. Therefore when one of the subsystems is state OFF, the global state of the instrument is also OFF.

Whether the OS is running (i.e. it is loaded or shutdown) can be checked separately from the global state. OS process is alive, thus it is either ONLINE or OFF.

When the global state of the instrument is ONLINE the OS is ready to accept commands, the execution of which is reflected in the substate of the instrument: e.g. SETUP, OBSERVING, PAUSED, IDLE, see also section 9.7.4.

6.5 Configuration

The instruments are configured via Application Configuration Files. These files (that should be placed in a separate module) contain information about the individual subsystems and the OS of the instrument and also startup options.

The configuration of the OS of an instrument (Section 7) consists of the declaration of its subsystems (Section 7.2, 7.3, 7.6) and the instrument modes (Section 7.7).

6.6 Dictionary

The configuration and setup keywords are declared in dictionaries, where the configuration keywords are checked during startup and the setup keywords are checked during runtime.

The common configuration and setup keywords regarding the OS are specified in dictionary

ESO-VLT-DIC.OSB.

Any additional instrument specific configuration and setup keywords must be specified by the user.

The additional configuration keywords should be included in the dictionary ESO-VLT-DIC.<INSNAME>_CFG.

Note that as the configuration file is handled by the configuration tool (ctoo) the dictionary (which contains the additional configuration keyword) must be also set as part of the instrument configuration [RD-10]. Section 10.2 explains how to add additional configuration keywords.

Additional setup keywords (see also 10.3) should be specified in the dictionary[6] named:

ESO-VLT-DIC.<INSNAME>_OS.

The following dictionaries are automatically loaded by BOSS:

ESO-VLT-DIC.OBS ESO-VLT-DIC.OSB

ESO-VLT-DIC.TPL ESO-VLT-DIC.<INSNAME>_OS

ESO-VLT-DIC.DPR

6.7 Command handling

BOSS supports the handling of the following commands:

ABORT, ADDFITS, ACCESS, COMMENT, CONT, DEBUG, END, EXIT, FORWARD, OFF, ONLINE, PAUSE, PING,

SETUP, STANDBY, START, STATE, STATUS, WAIT, VERSION

Normally the commands are declared in templates and sent to an OS by BOB. Nevertheless the commands can be also sent directly to the OS (using e.g. testscripts or GUI).

Handling these commands BOSS takes care of the necessary communication between its subsystem. It sends (synchronous and asynchronous) messages to the subsystems and synchronises their replies.

The state and substate of the OS is updated according to the actions of the given command.

The default implementation of the commands callbacks are placed in the class bossSERVER.

For more information about the details of the procedures see Chapter 9.4.

6.8 Database events

During the initialization BOSS attaches database events to some of the database points of the subsystems of the instrument. These database events are playing an important role in the synchronization process of BOSS.

The addresses of the relevant database points - status, state, newdata - are given in the configuration file.

For more details see Chapter 9.5.

6.9 Interfaces

BOSS includes several interface classes through which the communication between OS and the instrument’s subsystems can take place. These are:

bossINTERFACE, bossINTERFACE_ICS, bossINTERFACE_TCS,

bossINTERFACE_OCS, bossINTERFACE_DCS, bossINTERFACE_CCD,

bossINTERFACE_IRACE, bossINTERFACE_TCCD, bossINTERFACE_FIERA

The subsystems are declared in the configuration file however the interfaces for them have to be declared in SERVER class of the instrument (see Chapter 9.2). Each subsystem must be coupled to an interface. It is also essential to build the database according to the subsystems.

BOSS stores the declared interfaces on its internal subsystem list. The interfaces are identified by the name of their belonging subsystem. (The names of the subsystems are given in the configuration file.)

6.10 Exposures

The exposures that can be handled by BOSS fall into the following categories:

Single exposure: Single exposure.

The looping TCCD (without image is saved) belongs to also this category.

Parallel exposures[7]: Two or more exposures are handled simultaneously. Exposures are started at the same time, and have the same expoId. Only one single START command is used to start the exposures (see Figure 1).

Semi-Parallel exposure: Exposures are running simultaneously (see Figure 2), however they are handled independently from each other, and each exposure has its unique exposure id. The exposures are started separately.

Figure 1 Example for parallel exposure

Figure 2 Example for semi-parallel exposure

Each time an exposure is declared by the user (through the command SETUP) BOSS adds the exposure to its internal exposure table, that is also represented in the database. The exposure table is updated each time when the state, mode, filename, etc of an exposure is modified (see also Section 9.7.1, Table 9). In case of error it could be useful to check exposure table.

The exposures are identified by their exposure id-s. Before an exposure can be started the detector (or detectors) with which the exposure is taken must be uniquely identified. (See also declaration of mode, and parameter detId of the commands).

6.11 OS as Super OS

An OS become SOS (see Chapter 9.8) when one or more of its subsystem is an OS. The configuration of an SOS (Chapters 7.6, 9.8.1) is similar to the configuration of a normal OS.

To setup the parameters of the subsystems on lower levels hierarchical keywords are used (see section 9.8.2)

6.12 Logging

Logging can help detecting bugs or understanding the behavior of the code. The different type of logs are declared in the module ibac. There are five types of logs, which will appear according to command line or start up options. Developers are recommended to apply these logs in the OS application. Please see below the application of these logs (for more information, see man pages of ibac and ibacLog):

Note that as default nothing is looged on the stdout. The loglevel can be changed via commandline option and the command DEBUG.

Warning log:

Log data into the standard VLT log file and to the stdout (if verbose is specified). The level is put to 1. This procedure is called when there are errors or abnormal events for application

WarningLog ("A configuration file has to be specified");

WarningLog ("Could not read database attribute %s.",dbaddr);

Info log:

Log data into the standard VLT log file and to the stdout (if verbose is specified). the level is put to 2. This procedure is called when operational mode is modified.

InfoLog("Checking FITS header file '%s'", fitsHdrFile);

InfoLog("Getting TCS FITS header at start of exposure");

Action log:

Log data into the database attribute dependent on the level specified. Log data into the standard VLT log file and to the stdout.

ActionLog(1, "Cleaning up done.");

ActionLog(1, "%s command failed", msg.Command());

Test log:

Log data into the standard VLT log file and to the stdout (if verbose is specified). The level is put to 3.

TestLog(" expoId: %d ; detector :%s ",expoId, (char*)detId);

TestLog("Handling the DB event from attribute '%.80s'",dbaddr);

Debug log:

Log data into the standard VLT log file and to the stdout (if verbose is specified). The level is put to 5. This procedure is called when users want more detailed debugging information.

Recommended to add at the beginning of each function.

ExtDbgLog("bossSERVER::OnlineCB()");

ExtDbgLog("bossEXPOSURE::GetSubsystems(expoId :%d)",expoId);

7 Configuration Guide

The OS is configured via configuration file [AD 07].

In this configuration file the basic information about the instrument (name, prefix, database) and its subsystems (that are to be controlled by the OS) must be declared.

The subsystems that can be handled by BOSS fall into the following categories:

DET: detector subsystem

INS: instrument subsystem

OS: OS subsystem (in case of SOS)[8]

TEL: telescope

These categories are also referred as <CAT> below. If there are more than one subsystem belonging to the same category they must be indexed.

Some keywords must be declared for all type of subsystems (Chapter 7.2) while others only for certain type of subsystems. Many configuration parameters have default values. When the default value is applicable the keyword can be omitted from the configuration. The optional keywords are written by italic letters in the tables.

The instrument modes (see Chapter 7.7) must be also declared in the configuration file to make the SETUP simpler.

The configuration file is handled by the bossSERVER class. It configures the interface classes for the given subsystems, and stores the defined modes in its internal mode table, that is also represented in the database. (See classes bossINS_MODES and bossMODES_TABLE_ENTRY on figure Figure 3.)

For an example of a complete configuration of an instrument please take a look at the configuration of the template instrument OS [RD 01] in the Appendix 1.

Note that the configuration of the ICS [AD 06, AD 07,RD 02] itself is also placed togethere with the OS configuration but here only the keywords relationg to the OS are described.

7.1 General system configuration keywords

Here only the keywords that are relevant to the OS are described.

Table 7.1 Configuration of the subsystems

Configuration keyword	Short description
INS.CON.ID	Instrument identifier
INS.CON.PREFIX	Name prefix for modules and servers
OCS.CON.OSDBROOT	Database point of the intrument OS itself (optional).
OCS.CON.ORIGIN	Origin
OCS.CON.RELEASE	Release date
OCS.ARC.TIMEOUT	Archiver timeout (optional).
OCS.CON.LOGLEVEL	Log level (optional).

The name of the instrument and the two letter instrument code always have to be supplied in the configuration.

Name of the instrument:

INS.CON.ID "XXXX";

Two letter instrument code:

INS.CON.PREFIX "xx";

Database address of the OS of the instrument:

OCS.CON.OSDBROOT “<alias>xxo”;

The default value for OSDBROOT is: “:Appl_data:<INS.CON.ID>:OS”;

Archiver timeout:

OCS.ARC.TIMEOUT 60;

The support process of the OS -called the ‘archiver process’- takes care of the merging of the images. Via this keyword the time -as default 60 sec- allowed to handle one image can be altered.

Loglevel:

OCS.CON.LOGLEVEL 1;

This is an optional configuration keyword, which only taken into account if the logging level otherwise not specified as command line option (see section 11.1). Value of this keyword should be 1 to 5 which corresponds to the gradual increase of Acton/Log/Verbose level (see also 6.12). Default value is 0.

General information about origin, release date can be supplied by keywords

OCS.CON.ORIGIN and OCS.CON.RELEASE.

7.2 Configuration of the subsystems

Table 7.2 Configuration of the subsystems

Configuration keyword	Short description
OCS.<CAT>.NUM	Number of subsystem belonging to the given category.
OCS.<CAT>i.NAME	name of the subsystem
OCS.<CAT>i.ACCESS	access mode of the subsystem: NORMAL, IGNORE,FORBIDDEN
OCS.<CAT>i.DICTi	Dictionary of the subsystem : ESO-VLT-DIC.XXXX
OCS.<CAT>i.ENVNAME	Environment name where process of the subsystem is running
OCS.<CAT>i.PROCNAME	name of process of the subsystem
OCS.<CAT>i.KEYWFILT	Keywords that are forwarded to the subsystem
OCS.<CAT>i.TIMEOUT	timeout for OS process
OCS.<CAT>i.DBROOT	The database address of the subsystem (optional).
OCS.<CAT>i.DBSTATE	db address of ‘state’ (optional)
OCS.<CAT>i.DBIFROOT	The database address of the subsystem interface (optional).

Number of subsystems - OCS.<CAT>i.NUM

The number of the subsystems of the given category is a required information for the startup tool [RD-11] therefore should be placed in the configuration file[9].

Note that this keyword is not available for TCS subsystem, as there can be only one TCS.

E.g.: OCS.DET.NUM 2

denotes that there are two DCS subsystems , e.g. one FIERA and one TCCD.

Name of subsystem - OCS.<CAT>i.NAME

The individual subsystems can be referred to by their NAME-s. The names can be up to 32 character long, nevertheless it is recommended to use short names.

E.g.: OCS.DET1.NAME “TCCD”

Note that in case of Unit telescope (TEL) the name is restricted to have the following values:

“UT1”, “UT2”, “UT3”, “UT4”. (UT0 can be used when TCS is in simulation)

Access mode of subsystem- OCS.<CAT>i.ACCESS

As the examples below show, the ACCESS of a subsystem can have three values:

OCS.DET1.ACCESS "NORMAL"

OCS.DET2.ACCESS "FORBIDDEN"

OCS.TEL.ACCESS "IGNORE"

In normal operation mode the subsystem process must be properly installed and ready to be started up. In this case the ACCESS modes must be set to NORMAL.

When the subsystem is IGNORED all request (i.e. messages) to the subsystem will be ignored, i.e. considered as successfully finished. This option can be used during development when the process for the subsystem is not yet available, or just simply make the tests quicker. When a subsystem is ignored its state has no impact on the global state of the instrument.

When during operation one of the subsystem goes out of order its access mode should be switched to FORBIDDEN. This forbids the usage of this subsystem. In this case all request to the subsystem are rejected (error message is sent).

Dictionary of subsystem - OCS.<CAT>i.DICTi

Only the ‘tail’ of the dictionary of the subsystem must be given, i.e: XXXX for a dictionary ESO-VLT-DIC.XXXX.

More then one dictionary can be supplied using indexes.

E.g.: OCS.INS.DICT1 "ICS_AA"

OCS.INS.DICT2 "ICS_BB"

Please note that the maximum number of dictionaries per subsystem is 20.

Dictionary for additional configuration keywords should be specified differently please see also section 6.6 and for an example section 10.2.

Environment name - OCS.<CAT>i.ENVNAME

e.g.: OCS.INS.ENVNAME "wxxxx"

Note that the environment where the process is running, should not be given by environment variable, eg,.: $RTAPENV.

On the contrary, the environment variables are set according to the configuration file.

Keyword filter- OCS.<CAT>i.KEYWFILT

The keywords in the setup that match the pattern will be forwarded to the subsystem.

When more the one filter id given, they must be separated by a comma.

E.g.: OCS.DET2.KEYWFILT "DET2.*.*.*.*.*.*,DET.*.*.*.*.*.*"

Timeout - OCS.<CAT>i.TIMEOUT

Must be given in seconds.

E.g.: OCS.DET2.TIMEOUT 600

Database address of subsystem - OCS.<CAT>i.DBROOT

Must be supplied when other then default, e.g.:

OCS.DET3.DBROOT "<alias>fiera";

Default values:

DCS: "<alias><INS.CON.ID>:DCS:<OCS.DETi.NAME>"

ICS: "<alias><INS.CON.ID>:<OCS.INSi.NAME>"

TCS: "<alias>TCS"

OS: "<alias><INS.CON.ID>:DCS:<OCS.OSi.NAME>"

Based on the value of DBROOT other default database addresses -of state, newdata(DCS) and status (DCS)- are specifed.

Database address of state - OCS.<CAT>i.DBSTATE

The state (i.e. ONLINE, STANDBY, OFF) of the subsystems are stored in a database point.

In order to declare the global state of the instrument it is required to supply the database addresses of these point in the configuration file when other then default.

E.g.:

OCS.OS2.DBSTATE "<alias>yyo:status.state";

OCS.TEL.DBSTATE "<alias>TCS:tcsState.tcsSubstate";

OCS.INS1.DBSTATE "<alias>XXXX:ICS:PROCESSES:WS:icsControl.state";

Default values:

DCS (TCCD/FIERA): " <DBROOT>.opState"

DCS (IRACE): "<DBROOT>.:irace.state"

ICS: "<DBROOT>:PROCESSES:WS:icsControl.state"

TCS: "<RTAPENV>:<alias>TCS:tcsState.tcsState"

OS: “<DBROOT>:status.state”

Database address of interface - OCS.<CAT>i.DBIFROOT

The keyword specifies the root database address of the interface of subsystem. When database is declared as specified in section 9.5, the default values are applicable, and keyword can be omitted from the configuration.

The keyword is used for declaring the db address of the interface of the subsystem where configuration and runtime information (e.g. lifecycle for DCS) about the subsystem is displayed by BOSS.

Defaults:

DCS : "<OSDBROOT >:subsystems:<OCS.DETi.NAME>" , e.g. : "<alias>xxo:subsystems:fiera"

ICS: “<OSDBROOT >:subsystems:<OCS.INSi.NAME>” , e.g.: "<alias>XXXX:OS:subsystems:ics"

TCS: “<OSDBROOT >:subsystems:<OCS.TEL.NAME>” , e.g.: "<alias>xxo:subsystems:tcs"

OS: “<OSDBROOT >:subsystems:<OCS.OSi.NAME>” , e.g.: "<alias>sos:subsystems:xxxx"

where the database root of the OS (<OSDBROOT>) is specified[10] by the configuration kewyords : OCS.CON. OSDBROOT.

7.3 Additional detector configuration keywords

According to the type of the detector boss supplies default values the database address of status, state, and new filename. When the detector is not TCCD, FIERA or IRACE or the data are different then the default the keywords in Table 7.3 must be supplied.

Table 7.3 Additional detector configuration keywords

Configuration keyword	Short description
OCS.DETi.TYPE	Type of the detector ACE,FIERA, IRACE
OCS.DETi DBSTATE	db address of ‘state’ (when other then default)
OCS.DETi.DBNEWDT	db address of ‘new data file’ (when other then default)
OCS.DETi.DBEXPSTS	db address of ‘exposure status’ (when other then default)
OCS.DETi.WIPING	Start/Stop wiping of detectors during online/standby
OCS.DETi.STOP	Leave detector ONLINE when the system is set to STANDBY
OCS.DETi.ARCMODE	Set option for merging all the files when more then oneing all the files w x commandnt tfiles are generated by the detector during one exposure
OCS.DETi.OPTSEQ	Allow optimised sequence of exposures (c).

Type - OCS.DETi.TYPE

The TYPE of the detector is FIERA, ACE or IRACE according to the available detector subsystem interfaces. Based on the type of the detector, the default data for the database address of state, status, and newdata are declared. Therefore the database addresses below only have to be supplied when other then default.

Database points:

The database points for state, newdata, exposure status, specified by keywords OCS.DETi.DBSTATE, OCS.DETi.DBNEWDT, OCS.DETi.DBEXPSTS generate events that are captured by BOSS. The procedures that are executed in the event of their change are described in Chapter 9.5.

These data must be supplied when other then default. The default values are:

Type:TCCD or FIERA

OCS.DETi.DBSTATE "<DBROOT>.opState";

OCS.DETi.DBNEWDT "<DBROOT>.:exposures:exposure_1:transfer.fileNameUnComp";

OCS.DETi.DBEXPSTS "<DBROOT>.:exposures:exposure_1.expStatus";

Type: IRACE

OCS.DETi.DBSTATE "<DBROOT>:irace.state";

OCS.DETi.DBNEWDT "<DBROOT>:exposure.newDataFileName"

OCS.DETi.DBEXPSTS "<DBROOT>:exposure.expStatus"

Where <DBROOT> refers to address given by the keyword OCS.DETi.DBROOT, or its default value (see section 7.2), so for example for TCCD the default db addresses become:

OCS.DET2.DBSTATE "<alias>tccd.opState"

OCS.DET2.DBNEWDT "<alias>tccd:exposures:exposure_1:transfer.fileNameUnComp"

OCS.DET2.DBEXPSTS "<alias>tccd:exposures:exposure_1.expStatus"

In Appendix 1 example for setting the database points for FIERA and IR DCS can be also found.

(Note that as default values are used the settings are commented out.)

Set Wiping- OCS.DETi.WIPING (optional):

When the keyword OCS.DETi.WIPING is set to true (i.e. ‘T’) it starts wiping the detectors during online and stops the wiping during standby. The OS sends the corresponding commands STARTWP, STOPWP to the CCD during the execution of commands ONLINE and STANDBY respectively. The default value of the keyword is ‘F’. (If the state is already in the desired value these commands will not be resent).

Leave detector ONLINE - OCS.DETi.STOP (optional):

When keyword CS.DETi.STOP is set to false (i.e. ‘F’) the OS leaves the detector ONLINE when the system is set to STANDBY. The default value of the keyword is ‘T’.

When the OS receives a normal STANDBY or OFF command (without the parameter ‘–subSystem’ specified), then these commands are not forwarded to the detectors that have their corresponding configuration keyword set to false:

OCS.DETi.STOP=F;

However, if the OS receives a STANDBY or OFF command to place a specific detector in the STANDBY or OFF state e.g. :

STANDBY -subSystem FIERA

the command is forwarded to the subsystem regardless whether or not keyword OCS.DETi.STOP is specified.

Set handling of data files - OCS.DETi.ARCMODE

This keyword refers to the handling of multiple files, i.e. for the case when during one exposure more then one image file is produced (e.g. when IRACE is in mosaic mode).

For the case when there is only one image is produced during the exposures this keyword can be omitted. From JAN2006 release there are two options to handle multiple files, “MERGEALL” or as default “NORMAL”. If MERGEALL option is configured then all the files which has been generated and reported by the detector (via new datafile attribute) are merged together into one file.

During “NORMAL” option the handling of multiple files corresponds to the single file handling. For more details see Section 9.6.3.

Allow Optimised qequence of exposures - OCS.DETi.OPTSEQ

This keyword has been introduced for back compatibility reasons for IRACE subsystems. For other type of detectors it can be omitted. In case of IRACE detector it should be set when optimized exposures are needed. For FIERA detectors this option is always enabled.

When this keyword is set to T (i.e. TRUE) the optimized sequence of exposures is allowed regarding WAIT command option -cond CanSetupNextObs (see also 9.4.5.1).

If OPTSEQ is T WAIT -cond CanSetupNextObs returns when READING OUT or TRANSFERRING state is reached, otherwise it returns when exposure is completed (status SUCCESS).

Default value: T for FIERA, F for IRACE.

7.4 Additional TCS configuration keywords

Table 7.4 Additional TCS configuration keywords

Configuration keyword	Short description
OCS.TEL.ID	Sets TELESCOP kw in the fitshdr when TCS is ignored

The TELESCOP keyword that is placed in the final fits header is normally specified by the TCS subsystem. When the TCS subsystem is ignored but given on the subsystemlist of a selected mode (7.7), the TELESCOPE keyword still has to be included in the fitsheader. In this case its value is set as given by

the OCS.TEL.ID keyword in the configuration.

The OCS.TEL.ID must correspond to the given Telescope as declared in DICD. E.g.: For Unit Telescope i the value must be set to: 'ESO-VLT-Ui'.

Boss gives a log when keyword is not specified in the configuration. (The OCS.TEL.ID is checked when the acces of TCS is normal.)

7.5 Additional ICS configuration keywords

Table 7.5 Additional ICS configuration keywords

Configuration keyword	Short description
OCS.INSi.HDRCAT	Category of the ICS keywords in the final fits header (optional).
OCS.INSi.DBSUBST	Substate of ICS, must be declared if not default.

The keyword OCS.INSi.HDRCAT should be used when more then one ICS headers are merged together with the final imagefile. As the result of this keyword, the category of the keywords (INS.*.*) in the header file created by the subsystem will be replaced by the specified category. Typically an index is added, (e.g. "INS3") however other specifications (e.g. "XXX INS") are also possible. The newly created keywords must be included in the dictionaries of the subsystem.

See chapter 9.6.1, 9.8.6.2 for more details.

The keyword OCS.INSi.DBSUBST should be used when the substate database point of the ICS does not correspond to the default: "<OCS.INSi.DBROOT>:PROCESSES:WS:icsControl.substate"

which is the case special ICS subsystem or a 2^nd ICS. This database attribute plays role in the synchronization (9.7.5) i.e. OS checks if ICS substate to avoid user commands and internal OS request (getting fitsheader) collision.

7.6 OS Subsystem Configuration Keywords

An OS can also be a subsystem in case of SOS. The OS as a subsystem is configured by the same keywords as other subsystems. See Table 7.2.

Table 7.6 Additional OS configuration keywords (required only when OS subsystem is not based on BOSS)

Configuration keyword	Short description
OCS.OSi.DBSTATE	db address of ‘state’ (when other then default)
OCS.OSi.DBNEWDT	db address of ‘new data file’ (when other then default)
OCS.OSi.DBEXPSTS	Exposure status database attribute (when other then default)
OCS OSi PREFIX	Keyword prefix for SOS Setup keywords (optional)

The configuration keywords OCS.OSi.DBSTATE, OCS.OSi.DBNEWDT, OCS.OSi.DBEXPSTS specifying the database address of the state, newdata and exposure status respectively are only necessary when the subsytem OS is not based on BOSS. The default values are:

OCS.OSi.DBSTATE <DBROOT>:status.state;

OCS.OSi.DBNEWDT <DBROOT>.osNewData;

OCS.OSi.DBEXPSTS <DBROOT>:exposure.expStatus;

Where DBROOT is specified by the keyword OCS.DETi.DBROOT, when other then default (see section 7.2).

The setup keywords sent to SOS and intended to reach sub OS-es must be prefixed. The default prefix is OCSi (where i correspons to the category index). It is possible but not recommended to specify other prefix by the keyword OCS. OSi.PREFIX. (For more infirmation on SOS setup keyword see section 9.8.2)

For more information about super OS see Chapter 9.8.

7.7 Instrument modes

The modes of the instrument - that is declared as a series of SETUP parameters - can include SETUP values for the ICS, DCS, OS subsystems and also for the telescope as well. When an instrument mode is specified, the subsystems that are involved in the given mode must be also declared.

Setting up/or starting subsystems that are not on the subsystem-list are not allowed to. (A warning log appears on the logmonitor if setup includes a subsystem that is not on the subsystemlist.) Single exposures can be executed simultaneously only if they have the same instrument mode. Currently no proper check is included for these points in BOSS, so satisfying the above conditions are the user’s responsibility.

Note that the modes are always specific properties of the instrument. Declaring them makes the setup of the exposures simpler. [AD 07]

The selected mode always has to be specified in the first setup of an exposure. The setup of a mode can be only omitted when there is only one mode specified in the configuration (see section 9.4.3.3) or when previous exposure is repeated (see section 9.4.3.2).

The maximum number of modes is limited to 40.

Table 7.7 Configuration of instrument modes

Configuration keyword	Short description
OCS.MODEi.NAME	Name of the mode.
OCS.MODEi.SETUP	List of setup keywords together with their values.
OCS.MODEi.SUBSYST	List of the name of the subsystems involved in the mode.
OCS.MODEi.PATH	The instrument path that is connected to the mode.

To configure an instrument mode the keyword in Table 7.7 are used, as the following examples show:

# Instrument modes

# mode 1

OCS.MODE1.NAME "IR_IMAGING"

OCS.MODE1.SETUP "-function DET1.DIT 10 DET1.NDIT 1"

OCS.MODE1.SUBSYST "IRDCS ICS UT0"

OCS.MODE1.PATH "BLUE"

# mode 2

OCS.MODE2.NAME "GUIDING"

OCS.MODE2.SETUP "-file ccd.ref"

OCS.MODE2.SUBSYST "TCCD ICS"

OCS.MODE2.PATH "RED"

During the declaration of the OCS.MODE2.SETUP, the parameters ‘–function’ and ‘–file’ are used (similarly to the SETUP command).

Please note that the length of the NAME, PATH, and subsyst is limited to 64, 64, 256 characters respectively. The length of the SETUP declaration is limited to 256 characters. In case this is not enough (as normally) declare the setup values in a file and use the ‘–file’ parameter as shown in the second example (GUIDING mode).

The keyword OCS.MODEi.SUBSYST declares the subsystems that are involved in the given mode.

The instrument mode always has to be declared in the first SETUP of an exposure unless there is only one mode specified in the configuration file (see also Chapter 8). The mode has to be set by the keyword INS.MODE as the following example shows:

SETUP –expoid 0 –function INS.MODE IR_IMAGING

The INS.MODE setup keyword is also forwarded to the ICS subsystem together with the other INS*.*.* keywords (pattern declared in the configuration file by the keyword KEYWFILT) in the setup.

Please note that in the case one of the setup keywords, that is also included into the specified mode is repeated in the same setup, the value given in the mode will be set[11]. E.g. in case of

SETUP –expoid 0 –function INS.MODE IR_IMAGING DET1.DIT 5

the value of DET1.DIT will be set to 10.

When someone needs to overwrite a value declared in the specified mode, a subsequent SETUP command has to be sent (without specifying the mode). E.g.:

SETUP –expoid 0 –function INS.MODE IR_IMAGING

SETUP –expoid <id> –function DET1.DIT 5

In the above case the value of DET1.DIT is set to 5, and also the name of the mode is changed to ‘Undeclared’. Note that this will only effect the value of database point where the mode is stored (see also Table 9). However, the ICS will NOT get a new setup command with ‘INS.MODE Undefined’. Note that modification is only valid for the given exposure, the actual parameters of the mode can not be changed during SETUP. Therefore a subsequent command with ‘INS.MODE IR_IMAGING’ is sent the keyword DET1.DIT is set to 10 again.

In general when one of the mode setup keywords are redefined with different values the given mode cannot be identified any longer.

Nevertheless changing the path (using keyword OCS.PATH) is allowed and will not effect the name of the mode. I.e. in the following example the mode stored by OS remains ‘IR_IMAGING’.

SETUP –expoid 0 –function INS.MODE IR_IMAGING

SETUP –expoid <id> –function OCS.PATH “RED”

The detector(s) with which the exposure is taken must be present on the subsystemlist (that is specified by the given mode). BOSS automatically detects the detectors on the subsystem list and stores their names. See also exposure table (Table 9) in Section 9.7.1.

For example the following setup

SETUP –expoid <id> –function INS.MODE IR_IMAGING

declares the detector unambiguously. In the above case the exposure is taken by IRDCS.

If there are more then one detectors are on the subsystem list (declared by a given mode), the exposures can be started with any or all of the declared detectors on the subsystem.

When the exposure has to be started only by one detector only (and there are more detectors are specified on the subsystem list) the required detector has to be specified during the START command using the –detId parameter. E.g.:

START –expoId 1–detId IRDCS

When detId is not specified parallel[12] exposure will be started. I.e. START command is sent to all the detectors on the subsystem list simultaneously.

8 Setup Guide

Any SETUP keywords that are in the dictionaries of the subsystems can be given in the setup. One must make sure that the keywords are indexed according to the declaration in configuration file (see filter).

The keywords declared in the SETUP command are forwarded to the subsystems by BOSS. The command is successful when all subsystems set up the corresponding data successfully. (See tests of the XXXX Instrument [RD 01]).

There are special keywords for declaring the image name and for selecting an instrument mode. It is also possible to modify the elements of a selected instrument mode. These keywords are declared in the BOSS dictionary.

Do not include subsystem and mode configuration keywords in the setup!!

Also do not include setup keyword in the configuration!!

Table 8.1 Setup keywords

Setup keyword	Short description
INS.MODE	declare instrument mode (optional)
OCS.PATH	set the path (optional)
[13]OCS.DETi.IMGNAME	declare the image filename (required when image is to be saved)
OCS.DETi.NAMING	Set filenaming type (optional, default is standard naming)
OCS.DETi.IMGEXT	Set filename extention (optional, to be used in special cases)

Setting the image name by keyword OCS.DETi.IMGNAME:

The name of the image file is declared by the keyword OCS.DET.IMGNAME[14] in the SETUP. When this keyword is specified, BOSS first stores the name (for its internal use), and later (when an exposure is ready to be started) it takes care that the filename is set correctly according to the naming type. As default OS is using standard naming. This means that the given filename is automatically extended by a number indicating the day of the year, and a serial number.

OS takes care of setting the image filename for the detector (in charge) by sending a SETUP to the detector with the appropriate DCS setup keyword.

When the image filename is set as an empty string, i.e. : OCS.DET.IMGNAME “”, it is interpreted to take an exposure without saving the image. Not all the detectors support this. E.g. IRACE detector software returns an error when image filename is not set at the start of the exposure. BOSS DCS interfaces therefore include a check for this.

See examples for usage of SETUP keywords below:

SETUP "-expoId 0 -function INS.MODE IR_SPECTROSCOPY INS.DROT.POSANG 10.0 DET2.WIN1.UIT1 15.0 DET2.EXP.NREP 1 OCS.DET.IMGNAME testImage.fits"

SETUP "-expoId 1 -function OCS.PATH red"

Setting the Image naming with OCS.DETi.NAMING

The naming type can have the following values:

“Standard-Naming”

“Sequence-Naming”

“Request-Naming”

As default “Standard-Naming” is applied. According to this scheme the filename has the following format: <imgname><doy>_<seq>_<imgext>.fits

The elements of which are composed as:

<imgname> : base filename without extention

<seq> : sequential number between 0001-9999

(see more detailed description at “Sequence-Naming”)

<doy> : day of the year 001-256

<imgext> : extention as specified by the setup keyword OCS.DETi.IMGEXT

Note that the <imgext> filename extention is to be used for related files (e.g. produced by splitting,
or different detectors running in parallel), and not for consecutive images.

When “Sequence-Naming” is applied, the filename is supplemented with 4 digits. When files with the given base name (specified by OCS.DET.IMGNAME) already exist in the INS_ROOT, the digit is automatically set to the consecutive number. Nevertheless files generated with the same base name but via different naming scheme - e.g. request naming <basename>.fits - do not influence the sequence number.

The first file is named as:

<basename>_0001.fits

All the following files are named as:

<basename>_0002.fits, <basename>_0003.fits, ….,<basename>_xxxx.fits,

When “Request -Naming” is selected, file with specified name should not exist already. During the start of the exposure an error is returned when file with the given filename already exists.

Once a particular detector’s naming type is setup it will remain until the user changes it again.

If the naming is not declared “Standard-Naming” is applied as default.

When the detector for the naming scheme is not specified (i.e. the index is omitted when naming is set) all the detectors naming type is set accordingly, i.e.

‘OCS.DET.NAMING Request-Naming’

sets the naming type of all detectors to “Request-Naming”.

Note: When the TCCD is in simulation mode, always “Request-Naming” is set. As in this case TCCD accepts only special filenames (e.g. ccdImageLcuSim.fits).

Setting the Instrument Mode

For information on keywords INS.MODE, OCS.PATH please see Section 7.7.

More information about the functionalities of SETUP command is found in Section 9.4.3

9 Programmer’s Guide

The main classes that construct the BOSS software can be seen in Figure 3. In this chapter, the roles of these classes are introduced in detail. It is important for the developers to understand the functionality of the relevant classes.

Figure 3 Class design of the module boss

9.1 Initialisation

The ‘main’ function of an instrument OS is supported by the bossCtrlMain class of the BOSS package.

The ‘main’ function of an instrument OS therefore should follow the example bellow:

static char *rcsId="@(#) $Id: xxoControl.C,v 1.14+ 2000/08/04 19:20:06 vltsccm Exp $";

static void *use_rcsId = ((void)&use_rcsId,(void *) &rcsId);

#include "bossCtrlMain.h"

int main(int argc, char *argv[])

{

bossCtrlMain mainHandler("xx",rcsId);

mainHandler.CreateServer( new xxoSERVER( "XXXX");

// Startup: Register to CCS, set defaults, parse runstring, create SERVER object

mainHandler.Init(argc, argv);

//Enter the main loop

evhHandler->MainLoop();

//Terminate : Deregister from CCS

mainHandler.Exit(EXIT_SUCCESS);

}

The instrument ID and the version of the module (typically the rcsId) must be given as arguments of the constructor function of bossCtrlMain[15]. The instrument ID (i.e. ‘xx’ in the above example) is used for identification of the processes. (The instrument ID must correspond to configuration keyword INS.CON.PREFIX. See also section 7.1)

When the instrument ID is ‘xx’ the processes of the instrument OS are named as follows:

xxoControl : ‘Main Control Process’

bossArchiver_xxo : ‘File Handler Process[16]’ :

The CreateServer function of bossCtrlMain as its names implies creates a new instance of the instrument’s OS SERVER class. Note that the OS SERVER class of the instrument has to be a child class of the bossSERVER class !

The developer of an instrument OS must supply the following data:

database address of the root point of the OS (e.g.: "<alias>xxo")
Name of the instrument (e.g.: "XXXX") (which has to correspond to INS.CON.ID

Specified in the configuration module, e.g. in xxmcfg/config/xxmcfgINS.cfg [RD-10]

dictionary ("XXXX_OS" for ESO-VLT-DIC.XXXX_OS) of the instrument (if there is )

These parameters must be given as arguments[17] [18] of the constructor function of the SERVER class.

The Init() function of the class bossCtrlMain regiters to CCS and also initialize and configure the instrument server by calling the Init() function of the SERVER class. See details of SERVER class including the steps of functions Init() and Configure() in the next chapter.

9.2 The Server class

The bossSERVER -as shown in Figure 4a - is an evh [RD 03] application. Figure Figure 4b shows the protected variables of this class, that can be accessed by the child classes.

Figure 4 a) The inheritance chain of the bossSERVER class.

b) Protected variables of the bossSERVER class

When a server class is created it carries out the following action as default:

bossSERVER::bossSERVER(char * InsName)

:bossDB_TASK(dbPoint)

{

// set the name of configfile, dictionary

// Saves the name of the root database point

// Resets error handling

// Create instance of : dictionary

// Check if exposure db root point exists

// Reset list of pending WAIT commands

// Sets state alignment

}

Additional processes can be added when necessary in the overloads. The bossSERVER has several protected variables (Figure 4) that are therefore accessible for the instrument servers (i.e. the child classes of the bossSERVER).

The Init() function of the class bossCtrlMain regiters to CCS and also initialize and configure the instrument server by calling the Init() function of the bossSERVER instance. See details of functions Init() and Configure() below.

ccsCOMPL_STAT bossSERVER::Init()

{

// Sets filter for application keywords

// Define the instrument mode keyword (INS.MODE)

// Add triggers in the setup

// Set action log database point

// Set db point for handling sub-systems

// optional: Set interfaces of the subsystems

SubsystemInterfaces()

// Initialise subsystems (DCS)

// Clear database

// Load dictionary, configfile

// Configure the system

Configure(char *configFile)

// Add callbacks

// optional user declaration: Application specific initialization post process

InitPostProc()[19]

// Initialise archiver interface

// Sets interface for the ‘file handler[20]’ process

// Configure archiver process interface

// Sets the expoId of the DCS-es to be undefined

}

The steps of the function Configure are shown below:

ccsCOMPL_STAT bossSERVER::Configure(char *configFile)

{

// If no config file is specified retrieve previously loaded file

// Clear 'appConfig' object.

// Load the configuration file

// Load extra-dictionaries if specified in the configuration file

// Configure the sub-system interfaces

// Load sub-system dictionaries

// Configure instrument modes

// optional user declaration: configuration through additional keywords

AppConfig()

// Dispatches application configuration keywords to keyword event handler

// Sets state of the Instrument

}

Some of the above steps are highlighted and marked as optional. These are the functions that can be or overloaded in the SERVER class of an instrument OS.

The function ‘SubsystemInterfaces’ has a default implementation in BOSS to generate the interfaces automatically based on the configuration file (During auto startup the default function is used (see section 9.9.2). When there are subsystems that do not fall into the predeclared categories (ICS, DCS, TCS, OS) the function ‘SubsystemInterfaces’ has to be overloaded specifying all the subsystem interfaces (see also section 9.3). Below you find an example how to declare an interface of a subsystem:

ccsCOMPL_STAT xxoSERVER::SubsystemInterfaces()

{

//#= Define a subsystem of an instrument

// bossINTERFACE_IRACE irdcsPtr_; // declared in header file

irdcsPtr_ = new bossINTERFACE_IRACE (“<alias>iracq”, “DET1”);

AddSubSystem (irdcsPtr_);

…

return SUCCESS;

}

To have a direct access to the interfaces declare them as protected variable in the header file of the class. In order to couple the interface to the subsystem (declared in the configfile) the database point of the subsystem and category together with its index must be given as an argument.

Always add the subsystem interface to the subsystemList (see next chapter) using the function:

ccsCOMPL_STAT bossSERVER::AddSubSystem(bossINTERFACE *subSystemPtr)

For an example please see the implementation of template instrument OS [RD 01].

Note that missing keywords in the configuration can be source of various errors. Make sure that the second argument of the interface corresponds to the category of the keywords in the configuration exactly.

In case additional configuration keywords are necessary to configure the system, these keywords have to be placed into the dictionary of the instrument OS, and the belonging implementation should go into the function:

ccsCOMPL_STAT bossSERVER::AppConfigure(ctooCONFIG *)

Note that functions InitPostProc() and AppConfigure () are just empty functions in BOSS. The function InitPostProc and AppConfigure are typically used during the declaration of setup and configuration keywords. See Chapters 10.2, 10.3 for more information how to declare additional keywords.

9.3 Interface classes

There are several interface classes available in the BOSS library that should satisfy most needs. The available interfaces are shown in Figure 5.

In special cases you might wish to overload some of these interface classes. (Refer to man pages of the interface classes). When new interface class is to be developed it must always inherit from the base class bossINTERFACE.C or from any of its child class.

Figure 5 Available interface classes in BOSS

The interfaces should be selected according to the type of the subsystem. Each interface class has its own database class, with the same name. It is essential to include the corresponding database classes of the interfaces into the database of the instrument.

For more information how to declare the connection between given subsystem, its interface, and its database, see the function SubsystemInterfaces of the bossSERVER class (Section 9.2). Example is given in the template instrument document [RD 01].

BOSS stores the declared interfaces on its internal subsystem list (see class bossINTERFACE_LIST on Figure 3.). The interfaces are identified by the name of their belonging subsystem. (The names of the subsystems are given in the configuration file.)

9.4 Standard commands

The bossSERVER class contains the implementation of all callbacks that are called whenever a standard command is sent to the OS process. The list of the standard commands [AD 07] can be found in the appendix.

As the there are all the commands callbacks are implemented in one bossSERVER class, ( and it is therefore consists of numerous functions) for maintenance reason it is shared among several files:

bossSERVER.C bossSetModeCB.C bossWaitCB.C

bossStateCtrl.C bossExitCB.C bossAddFitsCB.C

bossExpoCtrl.C bossStateCB.C bossCommentCB.C

bossStatusCB.C bossStateAlign.C

bossSetupCB.C bossForwardCB.C

Note: most of the commands supported by bossSERVER class have a <subSystem> parameter, which is used to forward the command towards software (i.e sub-systems) implicated in the control of the instrument.

The behavior of the standard commands can be changed. See following sections.

9.4.1 STATE Command and related functions

STATE ==>-state <STRING>

Returns the state and substate of the instrument in the format of:

ONLINE/BUSY

STANDBY/IDLE

Note the state and sub-state of the instrument are saved in the database under points ... . When the command STATE is received the function StateCB is executed, which reads these dbpoints :

evhCB_COMPL_STAT bossSERVER::StateCB(msgMESSAGE &msg, void *)

{

// Gets current value of the state form the db point ...

// Gets current value of the sub-state from the db point...

// Compose complete state i.e. STATE/SUBSTATE

// Sends reply

// Handles error when necessary

}

The instrument state is associated with the state of the subsystem. It shows the minimum state of its subsystems (or the state of the OS[21]).

Event is attached to the ‘state’ database attribute of each subsystems. (See also configuration in Table 7.2.) . When ‘ aligned state’ is true (i.e. ‘T’) every time when a subsystem’s state is altered the function evhCB_COMPL_STAT bossSERVER::StateEvtCB(evtEVENT_MSG& event , void *)

is called that checks and sets the overall state of the instrument.

9.4.2 State changing commands

OFF -subSystem <STRING> ==> -done <STRING>

ONLINE -subSystem <STRING> ==> -done <STRING>

STANDBY -subSystem <STRING> ==> -done <STRING>

The handling of these commands is carried out by the OnlineCB, StandbyCB, OffCB. These functions are reasonably simple and they are also similar to each other. A successful reply (i.e. ‘OK’) for these commands is sent when the given subsystem or all the -not ignored- subsystems (see Table 7.7) has successfully carried out the given command and all innate or configurable actions are fulfilled.

The state of the instrument is updated through database events (see chapter 9.4.1).

Apart form forwarding the commands to the not ignored subsystems there are some additional features included in the state change commands some of which are configurable:

- After normal replies received form the subsystem(s) the state of the subsystem(s) and the global state are checked. If within a short period of time the state do not change to the requested state (this could be for example due to slow scan) an error is reported.

- Although the commands are not forwarded to the TCS, at the end of the ONLINE command the state of TCS is checked (if not ignored) and in the eventuality that it is not ONLINE a warning is given to the user to ignore TCS (day mode) or set it ONLINE (night mode).

- Existence of the Archiver process is checked during ONLINE command.

- If configured by OCS.DETi.WIPING keyword the wiping of detector is started/stopped during the execution of command ONLINE/STANDBY respectively (see also 7.3).

- If configured by OCS.DETi.STOP keyword do not forward the STANDBY command to the detector (as e.g. requested during the standard startup of the instrument via the startup tool stoo). Useful for e.g. for undisturbed execution of looping images (see also 7.3).

- Start telemetry of FIERA after successful ONLINE command execution.

- In case the internal commands (e.g. STARTTL, STARTWP, STOPWP) during the execution of the state change command fail an error reply is given to the command even though the requested state might have been achieved (the source of the error is reported).

The main skeleton of the online callback is shown below:

evhCB_COMPL_STAT bossSERVER::OnlineCB(msgMESSAGE &msg, void *userData)

{

// Check if execution of command is allowed in the current state

// Log action

// Gets current sub-state

// Set sub-state

// optional user declaration: Call pre-processing function

// Re-configure server according to the configuration file

// Handles command

// calls function StateCtrlCmdProc which executes the following:

//Parse message parameters

// If parameter '-subsystem' is specified

// send message to specified sub-system

// Else

// send command to all available sub-systems (except TCS).

// Wait sub-system reply(ies)

// Synchronize sub-system replies

}

The developer of an OS can optionally include an additional step into the callback process by overloading the functions:

ccsCOMPL_STAT bossSERVER::OffPreProc(msgMESSAGE &, void *)

ccsCOMPL_STAT bossSERVER::StandbyPreProc(msgMESSAGE &, void *)

ccsCOMPL_STAT bossSERVER::OnlinePreProc(msgMESSAGE &, void *)

that are originally empty (returning SUCCESS immediately).

9.4.3 SETUP Command

SETUP -expoId <INTEGER> -detId <STRING> -file <STRING> -function <STRING>

-noMove <LOGICAL> -check <LOGICAL> -noExposure <LOGICAL>

Þ -expoId <INTEGER>

evhCB_COMPL_STAT bossSERVER::SetupCB(msgMESSAGE &msg, void *)

{

// Check condition for execution of command

// Log action

// Sets the start time marker of the command

// Sets sub-state to 'SETUP'

// Handle setup command: parses command parameter

// If there is no setup keyword Return error

// Get/Check expoId specified in command

// Extracts application configuration keywords

// If application configuration keywords found

// Configure list of the sub-system interfaces

// Configure instrument modes.

// Handles instrument modes (if specified): adds setup keywords corresponding to the instrument mode

// Update database (add new exposure)

// Check if exposure is declared in the db

// Check instrument modes : check whether setup keywords influence the current instrument mode

// Calls keyword trigger dispatcher

// Extract OBS.* TPL*,DPR.* keywords to be placed in FITS header

// optional user declaration: call preprocessing function

// Forwards setup command to sub-system(s)

// Wait for sub-system reply(ies)

// Synchronizes sub-system replies

// Set the global exposure status inactive

// Sets sub-state to IDLE

}

In case of error happens during the SETUP, the exposure is cancelled. That means that it no longer exists and cannot be started. Should the setup sent to a running exposure fail, the exposure remains active of course- see 9.4.3.1.

When SETUP includes setup keyword of subsystem which is not included in the given mode BOSS logs the case on the logmonitor, but no error is returned.

Note that the parameters specified in the SETUP command refers to the OS exposures. BOSS modifies the setup parameters before forwarding it to the subsystems if necessary.

9.4.3.1 Allow SETUP while exposure is running

As default BOSS allows SETUP while exposure is running.

The situation is represented by the substate OBSERVING|SETUP which can be monitored by the databasepoint: : <alias>xxo:status.substateui. (see 9.7.2).

Users can restrict this option (when applicable) calling the function:

AllowSetupWhileExpRunning(ccsFALSE);

e.g. in the constructor of the overloaded bossSERVER class.

Note: Sending SETUP to a finished/failed/aborted/cancelled exposure is not allowed.

When the SETUP sent to a running exposure (e.g. altering the integration time) fails the users are informed by an error message, but the exposure is not affected by boss.

9.4.3.2 Repeat exposures

When same or similar exposures have to be carried out many times, it is worth to use the ‘the repeate exposure’ functionality to avoid superfluous setup imposed by e.g. the INS.MODE keyword.

Repeating exposure of course only makes sense when exposure has been previously set up successfully (otherwise error is returned). It is allowed to alter the setup of the repeated exposure by consequence SETUP commands.

msgSend "" xxoControl SETUP "-expoId 0"

During the above setup no setup keyword is sent to the subsystems, but a new expoId is generated.

Note that as the new setup starts with an empty header TPL,OBS,DPR,OCS keywords must be sent again in order to place them in the fits header in a consecutive setup.

During START the previous exposure is repeated.

Examples of repeating exposure:

A) Normal case

SETUP –expoId 0 –function INS.MODE GUIDING …

START -expoId 1

WAIT -expoId 1

SETUP –expoId 0

SETUP –expoid 0 –function TPL*,OBS* ..

START -expoId 2

WAIT -expoId 1

B) Pre declaration of exposures

SETUP –expoId 0 –function ….

SETUP –expoId 0

START -expoId 1

START -expoId 2

START -expoId 3

Caution: Pre declared repeated exposures have to be started in order.

C) Special case

In a special case when one sets up a new exposure while an other is running, the expoId and/or detId should be always specified for the other commands sent to the exposures.

E.g.:

SETUP –expoId 0 –function INS.MODE OPT_IMAGING …

START –expoId 1

SETUP –expoId 0 - function INS.MODE OPT_IMAGING …

START –expoId 2

WAIT expoId 1 // wait for the exposure 1

In case the user forgets the specify the expoId (or optionally the detId) for the command WAIT, the default expoId (i.e. for the last exposure is 2) takes places.

9.4.3.3 Default mode

The setup of a mode (INS.MODE) can be omitted when there is only one mode specified in the configuration.

When default mode is applied (i.e. the mode is not specified in the setup) the setup parameters of the mode are included in the setup until the first successful setup.

In the following setups the INS.MODE setup parameters will be only included if INS.MODE has been included in the setup or the global state of the instrument has been changed before.

In the special case of ‘one mode’ setup without parameter -functions is accepted for first setup:

E.g.: SETUP -expoId 0.

9.4.3.4 Setup bypassing exposures

As default boss automatically sets up a new exposure, or request an existing exposure for the SETUP.

In special cases the SETUP may not correspond to any exposures (e.g. there is no detector connected to the OS). In this case the parameter ‘–noExposure’ is applicable (for both OS and SOS) as the example below shows:

SETUP -noExposure -function INS.LAMPi.ST F

Functionality must be used with extreme caution not to interrupt running exposures!!

The case when neither the parameter -expoId nor the parameter –noExposure is supplied for the SETUP is extremely discouraged (nevertheless as default this would be understood as –noExposure).

Instrument mode:

When parameter 'noExposure' is given it is NOT compulsory to declare the instrument mode in the setup. However when INS.MODE keyword is found amongst the setup keywords, it is treated the same way regardless the parameter -noExposure is given or not in the setup. I.e.: The setup keywords belonging to the instrument mode as declared in the configuration file are sent.

Pre and Post processing functions:

The SetupPreProc() and SetupPostProc() functions are also executed during the setup which bypassing the exposures just like in case of a 'normal' setup. When these functions are dependent on the type of the setup, use the variable 'noExposure' as shown below:

ccsCOMPL_STAT xxoSERVER::SetupPreProc(msgMESSAGE &, vltINT32 expoId,void *)

{

if (noExposure) {..}

else {..}

return SUCCESS;

}

For existing instruments it is suggested to reconsider the content of SetupPre/PostProc() functions before applying the functionality of 'noexposure setup'.

9.4.3.5 Re-declaring exposure on CCD/FIERA

TCCD and FIERA detector software can handle only two exposures at a time: one that is running and one is to be prepare to be started. In order to avoid conflicts when a user tries to setup new exposures on BOSS without starting them, (i.e. sending consecutive SETUP commands with expoId 0) including keywords for a CCD, e.g.:

SETUP –expoId 0 –function INS.MODE OPT_IMAGING DET3.WIN.UIT1 10

after the execution of the second SETUP command the first exposure becomes INVALID. This means that it cannot be started. I.e.

START –expoId 4 will result in error.

This functionality was developed to make sure that templates can be always restarted, regardless the number of inactive exposures hanging around as a result of a failed or aborted template.

9.4.4 START Command

START -expoId <INTEGER> -detId <STRING> -at<STRING> Þ -done <STRING>

evhCB_COMPL_STAT bossSERVER::StartCB(msgMESSAGE &msg, void *userData)

{

// Check conditions of command

// If sub-state is IDLE Set sub-state to BUSY

// Get/Check expoId specified in command (as a parameter)

// Get filename

// Get/Check detId specified in command (as parameter)

// Preparation for the exposure:

// Get the detector declared by -detId parameter

// (otherwise detector(s) on the detector list[22])

// Check current exposure status of the given detector

// if exposure filename is not given display a warning log

// if exposure filename is given

// Check if there is enough disc place

// create file

// Set the image filename (by sending a SETUP to dcs)

// Set the status file name for the next exposure

// activate the databasepoint status

// Call pre-processing function

StartPreProcMain()

{ if (isImagefile) StartPreProc();else StartPreProcSpecial();}

// Send command to DCS/OS

// optional user declaration: Call post-processing function

StartPostProc()

// Send subsystem replies

// Short exposure action

}

When an exposure is started the db events attached to the status db attribute of the detector (or detectors) are activated.

(The status db attribute of the detectors is set in the configuration file (See Chapter 7.3). These db events have impact on the observation status, as well as on the releasing the pending wait commands.

In most callbacks the preprocessing and post-processing functions are empty functions. The StartPreProc is an exception, it calls tcsExpStart (during which the tifGetFitsStart process is executed) and the icsExpStart (which sends the EXPSTRT –path <inspath> command to ICS) as show below.

ccsCOMPL_STAT bossSERVER::StartPreProc(msgMESSAGE &, vltINT32 expoId,void *)

{

// send expstart to tcs

if (tcsExpStart(expoId)!=SUCCESS)

{

ErrAdd (bossMODULE_ID, bossERR_START_PREPROC, __FILE_LINE__ );

return FAILURE;

}

// send expstart to ics (to all of them if there are more then one declared)

if ( icsExpStart(expoId)!=SUCCESS)

{

ErrAdd (bossMODULE_ID, bossERR_START_PREPROC, __FILE_LINE__ );

return FAILURE;

}

return SUCCESS;

}

When the user wish to alter the START command overloading the StartPreProc and/or StartPostProc functions he must take into consideration the original functionality of the StartPreProc !

Note that StartPreProc is only called when image name is given for the exposure (i.e. image is created by the exposure. When image is not created the function StartPreProcSpecial (empty as default) is called. Both functions are called by the function StartPreProcMain which calles StartPreProc or StartPreProcSpecial according to the condition. All of these functions can be overloaded when required:

virtual ccsCOMPL_STAT StartPreProcMain(msgMESSAGE &msg, vltINT32 expoId,void *userData);

virtual ccsCOMPL_STAT StartPreProc(msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT StartPreProcSpecial(msgMESSAGE &msg, vltINT32 expoId, void *userData);

9.4.5 WAIT Command

WAIT -expoId <INTEGER> -detId <STRING> -first <LOGICAL> -all -cond <STRING> Þ -expStatus <INTEGER>

WAIT –detId IRDCS

WAIT –expoId 2

BOSS is able to handle more then one WAIT commands simultaneously.

The number of replies to wait command depends on the exposure status.

Only one reply is sent when the exposure is already FINISHED, FAILED or ABORTED.

Two replies are sent when exposure is running when WAIT command is received. The first reply is sent to acknowledge that WAIT command has been received and informs about the status, and last reply is sent when exposure is FINISHED, FAILED or ABORTED or specified condition is fulfilled.

Error reply is sent when exposure has not yet been started or the parameter ‘-expoId’ or ‘-detId’ is invalid. Error reply is sent also when exposure fails or it is aborted by the user.

When the parameter –all is specified the WAIT command refers to all running exposures, and return when all exposures has been finished failed or aborted or satisfy a specified condition.

9.4.5.1 Optimised sequence of exposures

It is possible to specify a condition to alter the circumstance when the final reply is sent to the WAIT command. This is useful for optimizing the sequence of exposures, to allow the handling of new exposures while one is still running. This is especially useful when reading out, transferring or merging status takes too long. The –cond parameter of the WAIT command can have therefore the following values:

CanSetupNextObs [23] Condition when new exposure can be setup without interrupting the currently running exposure. In case of FIERA this condition is fulfilled when all the partial headers are collected from the subsystems and the telescope, i.e. when READING_OUT state has been reached on FIERA.

For IRACE detector this condition is activated only when the configuration keyword is set to

OCS.DETi.OPTSEQ T (see also 7.3) and the condition is fulfilled when TRANSFERRING state is reached

and partial headers are collected.

(For any other type of detectors or when optimized sequence option is disabled, the headers are collected when SUCCESS event is reached, therefore in those cases there is no difference between the condition CanSetupNextObs and CanStartNextObs.)

CanStartNextObs [24] Condition when next exposure can be started. I.e. the currently running observation has been successfully finished, headers from other subsystems has been collected and merging process has been informed to archive the image.

ObsEnd [25] Default condition denoting that the exposure is completed and the image file has been merged with headers and archived.

With the help of parameters ‘–cond’ and ‘–all’ the execution of the observations can be optimized for speed.

SETUP –expoId 0 –file <>,

START –expoId 1

WAIT –expoId 1 –cond CanStartNextObs

SETUP –expoId 0 –function <>

START –expoId 2

WAIT –expoId 2 –cond CanStartNextObs

…

WAIT –all

Optimizing the execution sequence can lead to a queue for the Archiver process, as merging of large data files may not be processed as fast as new files are generated. The queue is handled sequentially by the Main process which sends a new command to the Archiver each time it becomes free. Therefore both process should remain active till the end of the merging, i.e. the neither of the processes should be shut down before OS send reply to command ‘WAIT –all’. The merging can be also monitored on the GUI panel via global status database point : ‘<alias>xxo:exposure.expStatus’ (see also 9.7.2).

In critical situations (e.g. an unforeseen event such as exploding supernova) the Wait command options give way to the setup and start of a new exposure while safely ending a running exposure as fast as possible.

SETUP –expoId 0 –file <>,

START –expoId 1

END –expoId 1

WAIT –expoId 1 –cond CanSetupNextObs

SETUP –expoId 0 –function <>

WAIT –expoId 1 –cond CanStartNextObs

START -expoId 2

WAIT –all

9.4.6 Other exposure control commands

PAUSE -expoId <INTEGER> -detId <STRING> -at <STRING> Þ -done <STRING>

This command suspends the current exposure at a given optional time.

CONT -expoId <INTEGER> -detId <STRING> -at <STRING> Þ -done <STRING>

This command continues a paused exposure at a given optional time.

END -expoId <INTEGER> -detId <STRING> Þ -done <STRING>

This command finishes the current exposure as soon as possible and read out the data. Image file is saved.

If command END is sent when the exposure status is still inactive (i.e. after setting up an exposure but before starting it) the exposure will be cancelled, i.e. cannot be started.

When command END sent to TCCD/FIERA that is looping, the OS (which receives the command) will send a STOP command to the DCS (rather then END command).

Command END is also allowed in state STANDBY in order to allow to end exposure should one of the subsystem go standby during observation.

ABORT -expoId <INTEGER> -detId <STRING> Þ -done <STRING>

The command ABORT terminates all the currently running actions. The exposures are terminated immediately (no image is saved). The abort command replies when reply from the subsystem arrives. As the reply does not mean that the exposure has been already stopped it is recommended to send a WAIT command after ABORT before a new exposure is set up.

STATUS -expoId <INTEGER> -function <STRING> -global<LOGICAL>

Þ -status <STRING>

Get the status of the functions in the list of arguments.

See also the documents on DCS Software for more information about the ABORT, END commands [RD 07], [RD 08], [RD 09].

9.4.7 FORWARD command

FORWARD -subSystem <STRING> -command <STRING> -arguments <STRING>

Þ -reply <STRING>

This command forwards the specified command with specified arguments to the given sub-system. It returns the reply of the sub-system command as a string. When the specified subsystem is set to be ignored the command has no effect. This command should be applied only in special cases when standard BOSS commands are not applicable.

Caution: the max length of the value of parameter ‘–arguments’ is: 256bytes.

Example of forwarding a command:

msgSend "" xxoControl FORWARD "-subSystem IRDCS -command SETUP -arguments \",,DET.DIT 20,,,\" "

For more examples see also: also FAQ 11.4

9.4.8 Commands operating on fits file ADDFITS and COMMENT

ADDFITS -expoId <INTEGER> -detId <STRING> -extnum <INT> -extname <STRING> -info <STRING> ==> -done <STRING>

This command inserts information -specified by keywords- to the FITS header.

If option –extname or -extnum is supplied the keywords specified by –info parameters are placed in the given extension. Please note that in templates the usage of extname (referring the EXTNAME keyword) is recommended as opposed to referring to extension with its serial number in the imagefile (i.e. : 1 to N).

See section 11.5 for examples.

COMMENT -expoId <INTEGER> -detId <STRING> -clear <LOGICAL> -string <STRING>>

Þ-done <STRING>

This command appends a comment to the FITS header of an image, e.g.:

msgSend "" xsoControl ADDFITS "-detId XXXX -info OCS1.INS.FILT 9"

9.4.9 ACCESS command

ACCESS -subSystem <STRING> -mode <STRING> [-info <LOGICAL > ]

Þ -reply <STRING>

The ACCESS command changes the ACCESS mode of the subsystems, i.e. IGNORE or NORMAL. The parameter -subSystem specifies the name of the subsystem the access mode of which is to be changed. Name should be given according to the configuration file. When set to 'ALL' the mode of all subsystems is changed to the specified mode. (Default value ALL.)

The parameter -mode specifies the mode, its value can be set to IGNORE or NORMAL.

If mode of a subsystem is set to be ignored, all commands that are sent to it are ignored.

(Default value NORMAL.)

If the parameter –info is specified the command returns information about the ACCESS mode of all subsystems. This parameter should not be used together with the other parameters.

For example, to set all the subsystems mode to NORMAL mode send message:

msgSend "" xxoControl ACCESS ""

and to return information about all the subsystems send message:

msgSend "" xxoControl ACCESS "-info"

In order to set the access mode of the TCS to be ignored:

msgSend "" xxoControl ACCESS "-subSystem UT0 -mode IGNORE"

9.4.10 Commands VERSION and DEBUG

VERSION Þ-version <STRING>

Returns the version of the boss module and if there is the version of the top-level instrument OS module.

DEBUG -log <INT> –verbose <INT> –action <INT> -timer <INT>Þ -reply <STRING>

Changes the level of the debugging.

9.5 Database and database events

State handling

For each declared subsystem the database point where its state is stored must be know for the OS.

OS attaches database events to the databbase points of the subsystems (the access mode of which is normal). These events have impact on the global state of the instrument.

Exposure handling

In case of DCS subsystems OS attaches database events also to the database points ‘exposure status’ and the ‘newdata’(see Section 7.3). These events invoke the processes that must be carried out after the images have been created. E.g. the image must be merged with the header files produced by other subsystems.

Connection to VOLAC

The ready image files are archived by the VOLAC system. The VOLAC system is informed about new files through the database point: <alias>newData.newDataFileName.

Based on the application-supplied information OS_ROOT, this database point is created automatically.

To achieve this the application’s database (xxo.db) must include the osbEnv.db file (which includes boss.db). It is ensured that the database point ‘<alias>newData’ is only created once, regardless the number of OS-es in the system.

See Template instrument example Chapter 10 (xxo.db)., and Chapter 11.10 (FAQ) for more details.

Life Cycle

The status of the detectors are displayed under the databasepoint:

‘<alias>xxo:subsystems:<subsyst>:lifecycle’ as specified in VLT-SPE-ESO-17240-0385.

Where <subsyst> must be set to the lower case version of the subsystem name,

i.e. in xxoSERVER.class the database point for the ‘IRDCS’ sybsystem is set to ‘irdcs’.

CLASS bossINTERFACE_LIST xxodbSUB_SYSTEMS

BEGIN

ATTRIBUTE bossINTERFACE_IRACE irdcs

END

9.6 The final image

When the image file has been created by the detector, boss merges it together with header files (containing information about the other subsystems e.g. ICS, TCS or the DCS itself). The merging is carried out by the Archiver process.

Each exposure starts with a new empty header, i.e. keywords that are retrieved from the setup are not reserved for the following exposures.

There are several keywords that are placed automatically in the fits header by BOSS retrieving the values from the configuration file or from the setup.

These fits header keywords based on the configuration are:

INSTRUME (according to INS.CON.ID)

ORIGIN (according to OCS.CON.ORIGIN)

INS.DATE (according to OCS.CON.RELEASE)

TELESCOP (according to OCS.TEL.ID)

These fits header keywords based on setup keywords are:

OBJECT (according to DPR.CATG,OBS.TARG.NAME , DPR.TYPE)

if (DPR.CATG=="SCIENCE") then OBJECT = OBS.TARG.NAME)

otherwise OBJECT = DPR.TYPE ( OBJECT is set to "" when keyword is missing)

OBSERVER (according to OBS.OBSERVER)

PI-COI (according to OBS.PI-COI.NAME)

Note that setup keywords starting by OCS.*.* , OBS.*.*, TPL.*.* or DPR.*.* are also automatically placed into the header.

Normally the users do not have to worry about the header merging process nevertheless during the development it is useful to know what temporary files are created (9.6.1 ).

It is also possible to specify additional binary tables (9.6.2).

9.6.1 Partial header files

Given the image filename (by a setup keyword OCS.DETi.IMGNAME) BOSS creates the final image file by merging the image file created by the DCS together with the header files gained from various subsystems. All the files are collected under directory $INS_ROOT/SYSTEM/DETDATA/. The partial header files are removed after successful merging. Supposing that the filename is given as ‘myfile.fits’ the following files are created:

I) header file created by TCS or VLTI :

TCSHDR_<detId> _<expoId>.tcs or

TCSHDR_<detId> _<expoId>.iss

Where detId is the name of the detector that creates the ‘myfile.fits’ image and expoId is the serial number of the exposure. This file is created during EXPSTRT process and finished during EXPEND process.

II) header files created by ICS-es:

myfile_<subsName>_hdr.fits

Where subsName is the name of the ICS subsystem that creates the header.

This file is created during EXPEND. (STATUS command is sent to ICS to retrieve the header.)

III) header files created by FIERA or TCCD :

myfile.fits.det

Created when imagefile is ready.

IV) header file created by BOSS:

myfile_hdr.fits

This file contains the TPL/DPR/OBS keywords which has been included into the SETUP command. It also contains any additional keywords that are added during runtime by the commands COMMENT and ADDFITS.

(Data saved into this file at the end of the exosure.)

The extension of the header files created by the subsystems is declared by the subsystem itself. The boss interfaces adopt this information. See function bossINTERFACE:: GetStatusFits() for more details.

For the archiver process an auxiliary file is created with name: ‘myfile.arf', which is removed[26] after successful handling. This auxiliary file contains the name of the files to be merged, deleted.

Note that when requested (by the configuration keyword OCS.INS.HDRCAT) the archiver process changes the category in the header file as well.

When SOS controls the exposure additional header files might be created. (See section 9.8.6 for more information.)

9.6.2 Binary Tables

In many cases there are additional information in form of binary tables that have to be included into the final FITS file.

Boss has a functionality to append binary tables to the image file automatically, when the following conditions are satisfied:

1) The file containing the binary table must be ready by the time the image file is ready

2) It is saved under $INS_ROOT/$INS_USER /DETDATA

3) It has the same name as the imagefile but extention ‘_btbl.fits’.

4) The file containing the binary table is a proper fitsfile, i.e. contains the binary tables as extentions.

The best is to create the binary tables using module oslx. See manpage of oslxFITS_EXT.

e.g. : myfile.fits will be merged with myfile_btbl.fits

Note that in case of VLTI instruments binary tables (names as: ‘<imgname> .bin<subsystem>’) created by ISS are automatically merged together with the image file.

9.6.3 Handling of multiple files during one exposure

The handling of multiple files during one exposure (e.g. in mosaic mode of IR detector) is supported from JAN2006 release.

In order to merge all the generated files into one file, the configuration has to be updated with the keyword: OCS.DETi.ARCMODE "MERGEALL" (see also 7.3).

The files generated by the given detector will be then merged as follows:

· When the file with the name specified by OS (i.e. determined in the setup by the keywords OCS.DETi.IMGNAME/NAMING/IMGEXT) is not amongst the file generated during the exposure then a new file is created (with the specified image filename). The primary HDU of this file contains the header information collected from subsystems but otherwise no image data, while all the datafiles are appended as extension in the order they were generated.

· When any of the file generated during the exposure corresponds to the user specified image file name, then this file will occupy the primary HDU of the final file and all the others will be appended in the order they were generated.

To ensure that the order of extensions in fits files follow a definite pattern the appended files are sorted in alphabetical order.

Currently the only other option for handling the multi file exposure is the default OCS.DETi.ARCMODE “NORMAL” option. According to this the case of multiple files are treated as single exposure file case, i.e. the header files are merged together with the file whose name matches with the requested name (e.g. the INT file ) during the exposure and only this file is archived (e.g. DIT files are not archived).

There might be different option for handling of multiple files in the future.

9.7 Exposure

The bossSERVER class has a pointer to one instance of the bossEXPOSURE class (See Figure 3).

The bossSERVER class as well as the bossEXPOSURE class have access to the list of subsystems (see Figure 3).

The bossEXPOSURE class is responsible to keep track of the current and past exposures. Boss keeps track of up to 20 exposures. The ‘old’ exposures are removed from the table.

9.7.1 The exposure table

The bossEXPOSURE class keeps track of the current and previous exposures[27]. The exposures are collected in table at the following databasepoint:

<alias>xxo:exposure.currExposureTbl

where xx is the two-letters instrument code.

Table 9 Exposure table

expoId	Mode	Subsystems	Inspath	Detector	filename	State	Expstrt
expo-1	Undefined	TCCD ICS TCS	BLUE	TCCD	myTCCD1.fits	COMPLETED	Done
expo-2	GUIDING	TCCD ICS TCS	BLUE	TCCD	myTCCD2.fits	ABORTED
expo-3	IR_IMAGING	IRDCS ICS TCS	RED	IRDCS	myIR.fits	INTEGRATING	tcs,ics

The exposure table shows the main properties characterizing the exposures that are identified by the expoId.

The last property in the table is the expstart flag that is used by BOSS internally. This flag indicates whether there are processes running that must be finished before the final image can be created. (These processes are typically the EXPSTRT processes that prepare additional information that must be placed in the header.) The expstart flag is emptied when there are no such processes left, and switched to ‘done’ when the final image is created.

The id of the last exposure, the last inactive exposure, and the last invalid exposure are also represented under the database points:

<alias>info.lastExposure - last exposure (with the highest expoId)

<alias>info.lastInacivExp - last exposure that has been set up but has not yet been started

(Set to –9999 when there is no inactive exposure to be started)

<alias>info.invalidExp - exposure that has been automatically set to invalid,

because of a consequent setup of a new exposure

(e.g. trying to setup 2 exposures on the same CCD simultaneusly without starting any)

Initially (at startup) all these values are set to –9999.

The expoId of the last exposure and last inactive exposure are updated during setup and start command sent to the OS.

When there is no more inactive exposures left the lastInacivExp is set to –9999

9.7.2 Exposure status

The expostatus values are collected in the table below for reference:

*Exposure status*	*Value*
*inscEXP_UNDEFINED*	0
*inscEXP_INACTIVE*	1
*inscEXP_PENDING*	2
*inscEXP_INTEGRATING*	4
*inscEXP_PAUSED*	8
*inscEXP_READING_OUT*	16
*inscEXP_PROCESSING*	32
*inscEXP_TRANSFERRING*	64
*inscEXP_COMPL_SUCCESS*	128
*inscEXP_COMPL_FAILURE*	256
*inscEXP_COMPL_ABORTED*	512

On FIERA and TCCD there are additional expostatus values defined as shown in the table below:

*Exposure status FIERA/TCCD*	*Value*
*ccdEXP_LOOP_FINITE*	1024
*ccdEXP_LOOP_INFINITE*	2048
*ccdEXP_DONE*	ccdEXP_COMPLETED \| ccdEXP_FAILED \| ccdEXP_ABORTED
*ccdEXP_RUNNING*	ccdEXP_PENDING \| ccdEXP_INTEGRATING \| ccdEXP_PAUSED \| ccdEXP_READING \| ccdEXP_PROCESSING \| ccdEXP_TRANSFERING
*ccdEXP_LOOP*	ccdEXP_LOOP_FINITE \| ccdEXP_LOOP_INFINITE

BOSS interprets the exposure status values as described in the table below. In addition, boss also has some additional expostatus values:

*Exposure status boss*	*Value*
*UNDEFINED*	0	At the beginning when OS started up, no exposure has been defined. Or when status of DCS is undefined.
*INACTIVE*	1	Exposure has been setup but has not yet been started
*FAILURE*	256	Exposure failed. (Can be caused by many reasons, e.g. exposure on dcs failed, collecting header information failed , archiver process does not exists, merging failed, etc)
*ABORTED*	512	Exposure is aborted by the user. (considered as error)
*bossEXP_RUNNING*	1024	From the moment exposure is started till the end of the expend processes Until archiver process is informed that exposure is finished
*bossEXP_MERGING*	2048	Archiver merges the data.
*bossEXP_CANCELLED*	4096	An exposure that has been set up, but has not yet been started is cancelled by the user (sending command END). Global status is set to ABORTED.
*bossEXP_FINISHED*	2048	Exposure has been finished successfully, header data for merging has been collected.

Note: When boss BOSS encounters a complex exposure status (e.g. ccdEXP_RUNNING) it is interpreted as follows:

If it includes a FAILED member -> FAILED, if it includes a ABORT member -> ABORT

If it includes a PAUSED member -> PAUSED, otherwise RUNNING.

When more then one exposure is running (semi-parallel) the global exposure status is shown (e.g. OBSERVING if one of them is integrating while the other is collecting headers).

9.7.3 Functions accessing the exposure table

The bossEXPOSURE class includes functions that operate on the exposures, and exposure tables. These are used internally. Below the functions, which retrieve useful information about an exposure, are listed.

ccsCOMPL_STAT GetLastExpoId(vltINT32 *expoId);

vltUINT32 GetGlobalExpoStatus();

char * ExpoStatus2Str(vltUINT32 expoStatus);

ccsCOMPL_STAT GetExposure(int expoId, char *mode, char *subsystems, char *inspath,

char *detector, char *filename, char *state, char *expstrt);

vltLOGICAL IsDefined (int expoId);

vltINT32 NoExposures();

ccsCOMPL_STAT GetSubsystems(vltINT32 expoId,char *subsystems)

ccsCOMPL_STAT GetDetector(vltINT32 expoId,char* detector)

ccsCOMPL_STAT GetFileName(vltINT32 expoId,char *filename)

ccsCOMPL_STAT GetInsPath(vltINT32 expoId,char *inspath)

ccsCOMPL_STAT GetExpstartFlag(vltINT32 expoId,char *expstrt)

vltLOGICAL CheckDetector( vltINT32 expoId, char *detId);

vltLOGICAL IsDetectorOnDetectorList( vltINT32 expoId, char *detId);

vltINT32 GetNumberOfDetectors(vltINT32 expoId);

For more information on other functions, see manpage of bossEXPOSURE.

9.7.4 Main steps of exposure

An exposure consists of the following main steps:

a) Setup of an exposure

Each exposure is identified by a unique number (expoId) during the setup.

b) Start of an exposure

- Preparation for starting the image

(e.g. setting the image file name)

- ‘expstart action’: Exposure start action during which ICS and TCS (on the subsystem list) are informed that an exposure is about to start.

c) Observation

- boss monitors the events (e.g. exposure status) generated by the subsystems.

d) End of exposure process

- ‘expend action’: ICS and TCS (on the subsystem list) are informed that exposure has been finished. (Note that when exposure is aborted, STOP command is sent to ICS, otherwise EXPEND command is sent).

- ‘merge action’: Preparation for merging the header files together

with the image file (informing the archiver process which files to merge)

- ‘image handling action’: handling and archiving the imagefile (done by a separate process,

but synchronsed with the main process)

- Reply is sent to pending wait commands

The steps of the exposures re also reflected by the substate of OS. (see also 6.4).

The substate of the OS is monitored through the database point: '<alias>xxo:state.substateui' :

The substate values are[28]:

*Substates of BOSS*	*Value*
*UNKNOWN*	0
*NOT_RUNNING*	1
*LOADED*	2
*IDLE*	4
*BUSY*	8
*SETUP*	16
*OBSERVING*	32
*PAUSED*	64
*OBSERV/BUSY*	40
*OBSERV/SETUP*	48
*OBSERV/PAU*	98
*OBS/PAU/SET*	114
*OBS/EXPSTRT*	160
*OBS/EXPEND*	288
*OBS/MERGE*	544

Complex sub-state values are formed from OBSERVING|SETUP to represent the situation when setup is sent during a running exposure. Sub-states OBS/EXPSTRT, OBS/EXPEND and OBS/MERGE represents the situation when OS executes an action while the exposure is running. (Note that often expend and merge action are still running after DCS has been finished the exposure. In this cases the sub-state indicates that the OS is still carries out actions concerning the exposure).

The complex sub-state OBSERV/BUSY denotes the case when OS handling a command while observation is running.

The complex sub-state OBSERV/PAU happens during semi-parallel exposures when one of the exposure is running and the other is paused. If a setup command is sent at this time the sub-state should change to OBS/PAU/SET.

9.7.5 Synchronization

The various actions (expstart, expend, merge, explained in the previous section 9.7.4) during the exposure must be handled with care as they are dependent on each other, on the exposure status and new data event. BOSS keeps track of the status of these steps and events via an internal synchronization class, which can be enquired for information at any time.

This internal class checks also the conditions whether an action regarding to an event is executable or not. The following conditions apply to the various steps:

Expstart action: The expstart action is executed before (as default) or after START command is sent to the DCS. It can be executed when DCS is idle, i.e. when previous exposure if any has been already finished, failed or aborted. If this condition does not apply error is returned.

Expend action: This action is executed when expstart action has been carried out successfully and READING_OUT status has been reached or passed. Error is returned if expstart action has previously failed. (Internal error is reported should the merge action occur before this step.)

The header is requested from all the non ignored subsystem belonging to the given MODE. Should error happen while collecting the headers OS tries to continue to collect the headers from the rest of the subsystems and report the error at the end of the process.

Merge action: This action is executed after expend is done and the exposure finished successfully and new image file has been created. This synchronization is necessary to make sure that when exposure has finished successfully the new image file is ready. This can happen when integration time is very short.)

When a subsystem status changes or it creates a new image file the event is captured by the OS and checks whether the prerequisites of the corresponding actions are satisfied. If yes it executes the action otherwise sets a flag to mark that the action must be executed later. At the end of the start procedure a special check is included to handle short exposures (i.e. when due to short integration time the exposure is already finished).

The synchronization makes sure that the actions are only carried out once.

Some user scheduled commands during the exposure (e.g. SETUP command if allowed 9.4.3.1, or instrument specific command) might happen in parallel to the internal request from OS to collect header information. To avoid collision of commands sent to the ICS, OS checks the substate of ICS before invoking its internal command. Should ICS be in a BUSY state, OS waits till ICS is free again or the given timeout is reached and only and only when ICS is IDLE will requests the header information. The case is logged but not considered as error. (Please note however that this sort of command collision might indicate some problem in scheduling the template.)

See also configuration of substate: 7.5.

9.8 Super Observation Software (SOS)

SOS is an OS which controls other OS-es.

The example in Figure 6 shows an SOS which controls two instruments XXXX and YYYY (i.e. two OS-es) besides its own ICS and the Telescope.

Figure 6 Example for SOS

Start up of SOS

First start up the subsystems and finally the SOS.

Structure of SOS

It is not recommended to design an SOS with a direct connection to DCS[29].

It is the user’s responsibility to ensure that there is only one TCS/VLTI (with access mode normal) in the whole SOS structure.

It is suggested to place the TCS at top level, but other arrengments are also possible. For test purpose or standalone operation of the sub OS-es, it is allowed to include TCS in the configuration of more then one OS-es, however their access mode have to be set to ‘ignored’ when SOS is in charge of the controlling the system.

SOS exposures

It is allowed to take test exposures with the sub-OS-es before SOS has been started up. Exposures should not be taken directly by the sub-OS–es while SOS is ONLINE.

Should you wish to test a sub-OS without its Super OS, set the SOS to STANDBY or shut it down. SOS cleans up its sub-OS-es when its state is set to ONLINE.

Parallel exposures[30] are not supported at SOS level. This means that when parallel exposures are required they has to be specified as semi-parallel exposures.

9.8.1 Configuration of OS subsystem

The configuration of an OS subsystem follows the pattern of the configuration of other subsystems (Chapter 7.). See example below:

# Configure the XXXX instrument

OCS.OS1.NAME "XXXX" # name of the OS subsystem

OCS.OS1.ACCESS "NORMAL" # access mode of the OS subsystem

OCS.OS1.ENVNAME "wbos" # environment where proc. is running

OCS.OS1.PROCNAME "xxoControl" # name of the OS process

OCS.OS1.KEYWFILT "OCS1.*.*.*.*.*.*" # keywords to be forwarded to subsyst

OCS.OS1.TIMEOUT 6000 # timeout for the process

OCS.OS1.DBSTATE "<alias>xxo:status.state" # db address of 'state'

# Configure the YYYY instrument

OCS.OS2.NAME "YYYY" # name of the IRACE detector

OCS.OS2.ACCESS "NORMAL" # access mode of the IRACE detector

OCS.OS2.ENVNAME "wbos" # environment where proc. is running

OCS.OS2.PROCNAME "yyoControl" # name of the IRACE detector process

OCS.OS2.KEYWFILT "OCS2.*.*.*.*.*.*" # keywords to be forwarded to subsyst

OCS.OS2.TIMEOUT 6000 # timeout for the process

OCS.OS2.DBSTATE "<alias>yyo:status.state" # db address of 'state'

# Configure the Instrument modes

OCS.MODE1.NAME "SOS_TEST" # name of the instrmode

OCS.MODE1.SETUP "-function OCS1.INS.MODE IR_IMAGING" # setup the mode

OCS.MODE1.SUBSYST "XXXX" # subsystems involved in the given mode

OCS.MODE1.PATH "" # instrument path

OCS.MODE2.NAME "TWO_OS" # name of the instrmode

OCS.MODE2.SETUP "-function OCS1.INS.MODE IR_IMAGING OCS2.INS.MODE YY_TEST" # setup the mode

OCS.MODE2.SUBSYST "XXXX YYYY" # subsystems involved in the given mode

OCS.MODE2.PATH "" # instrument path

9.8.2 Hierarchical setup keywords

In the SETUP command (which are sent to the SOS) the keywords must be given hierarchically. All keywords that are intended to setup a parameter of a subsystem of a subsystem must have a prefix: OCSi[31].

The index of this prefix must correspond to the index of the category of the given OS as declared in the configuration file!

For example when the instrument XXXX is assigned by the OS1 category in the configfile, i.e.

OCS.OS1.NAME "XXXX" ,

then to set up the integration time of the DET1 subsystem of the XXXX instrument the keyword

OCS1.DET1.DIT

must be used in the setup command.

In principle to set up an SOS parallel exposure, one can send the following setup command to the SOS process (note that this is not yet supported):

SETUP -expoId 0 -function INS.MODE TWO_OS OCS1.OCS.DET.IMGNAME xxxx.fits OCS1.DET1.DIT 2 OCS2.OCS.DET.IMGNAME yyyy.fits OCS2.DET1.WIN1.UIT1 10.0

The SOS (or more precisely the interfaces of the XXXX and YYYY instruments) then will cut off the prefixes and send to XXXX:

SETUP –expoId <id> -function OCS.DET.IMGNAME xxxx.fits DET1.DIT 2 INS.MODE IR_IMAGING

and to YYYY:

SETUP –expoId <id> -function OCS.DET.IMGNAME yyyy.fits DET1.WIN1.UIT1 10.0 INS.MODE YY_TEST

9.8.3 Dictionary for SOS

As long as only the hierarchical keywords and the standard configuration keywords are used, there is no need to supply additional dictionary at SOS level.

9.8.4 SOS interaction

The exposure controlled by an SOS has the same main steps (9.7.4) as a normal OS, however because of the hierarchical structure the interactions are more complex.

Figure 8 shows the interaction diagram of command START, when SOS controls three OS-es, one ICS and the TCS and in the given mode all subsystems are on the subsystem list. Two of the OS subsystems (OS1 and OS2) have one detector and an ICS connected to them, while OS3 controls only an ICS. (Figure 7 shows the structure of the SOS.)

Figure 9 shows the image data ready event for the same instrument as shown in …., however in a different mode. In the mode depicted OS2 is not on the subsystem list, therefore it does not take role.

The image taking OS is OS2, and data is collected from OS3.

Figure 7 SOS controlling three OS-es, one ICS and the TCS.

9.8.5 Command handling

9.8.5.1 The parameter subSystem

The commands STANDBY, ONLINE, OFF, STATE support the parameter ‘-subSystem’.

This parameter is used to forward the command to the specified subsystem ( i.e. to its control process).

In case of SOS the structure of this parameter reflects the hierarchy of the instrument and follows the following pattern:

<subSystem_1>.<subSystem_2>.<subSystem_3>....

Note subSystem_1, subSystem_2, subSystem_3 corresponds to the name of a subsystem. The subsystems are separated by dot.

Thus, when BOSS encounter the parameter –subsystem it first sends the command to subsystem <subSystem_1>, which then sends the command to subsystem <subSystem_2> and so on, as the example below shows:

When SOS receives a command:

ONLINE -subSystem "XXXX.IRDCS"

it sends a command :

ONLINE -subSystem "IRDCS"

to the subsystem 'XXXX', which in turns sends the following message to the IRDCS subsystem:

ONLINE

When the ONLINE command is sent to SOS without any parameter, it sends ONLINE command to all of its non-ignored subsystems. In turn, the sub-OS-es also send ONLINE command to their subsystems, and therefore the command is successful only when the whole system is set to online.

9.8.5.2 The parameter detId

The commands START, WAIT, PAUSE, CONT, ABORT support the parameter –detId.

This parameters normally identify the detectors. From SOS point of view the sub-OS-es, (i.e.XXXX and YYYY) are also considered as detectors as they are creating images.

Therefore one can send the following commands to the SOS:

START –detId YYYY

WAIT –detId YYYY

When a sub-OS does not have a detector subsystem the (default) START command would fail.

Should this sub-OS require to do some action (eg expstart) the StartCB should be overloaded.

9.8.5.3 Internal commands

SOS uses some internal private commands to enhance intercation with its sub OS-es.

These are:

CLEAN

Resets the OS and cleans up its exposure table.

When SOS receives an ONLINE command it also sends a CLEAN command to all its sub-OS-es. It is usefull when sub-OS-es are operated in a stand alone mode (e.g. for test purpose.)). SOS should be set to STANDBY state before its sub-OS is operated in a standalone mode.

GETHDR

Gets header information from OS.

Sent by SOS when header information required from OS that does not take the image.

EXPEND

Carries out expend action. Called when exposre has been failed or no image is created during an SOS exposure, or

9.8.6 Creating the finale image file by SOS

As default the top level OS (i.e. the SOS) merges all the files and informs VOLAC. When an OS receives the START command from an SOS as default it does not merge/archive the image but informs SOS when image file and the header files are ready. (To change this behavior see section 9.8.6.3)

SOS is informed that a file has been created by one of its subsystem through the database point ‘osNewData’ of its subsystems. (This db point is placed directly under the OS root point, e.g.: ‘<alias>xxo.osNewData’.)

9.8.6.1 Collecting data from other OS

When SOS receives an event from its sub OS, informing that an image file has been produced, SOS sends a command to the sub-OS-es (from which header is requested) to collect their fits headers.

The OS –es from which headers are requested must be given by the GetListOfOsCreatingHdr() function in the server class.

Note that boss sends GETHDR command to the OS-es that are on the list given by function GetListOfOsCreatingHdr,

and EXPEND command to the ones that are not on this list but on the subsystem list (declared in the selected instrument mode). Later is to make sure that all the ICS-es are informed that the exposure has been finished.

SOS also informs TCS and ICS that are directly connected to SOS to retrieve their header data.

After all the individual header files are ready, they are merged together with the image file. As default this is done by the archiver process of SOS.

In some cases when the sub-OS-es are in different environment, it is suggested to reconsider on which environment the final merging should be done[32].

When SOS handles the exposures the in addition to the files generated by the image taking OS (see section 0) some additional headers are created. When the image created by a sub-OS is named ‘myfile.fits’ the following additional temporary files[33] are created:

1) header file(s) from OS-es from which header information is requested:

myfile_<subsName >_hdr.fits

2) Binary table(s) (if any) from OS-es from which header information is requested:

myfile _< subsName>_btbl.fits

3) SOS also gets header files from its own ICS/TCS

These headers named in the same way as described in section 0:

4) SOS header file

myfile _<insId>_hdr.fits

containing TPL/DPR/OBS keywords and other keywords added by commands ADDFITS or COMMENT

5) Binary table at SOS level:

myfile_<insIdo>_btbl.fits // e.g. myfile_xso_btbl.fits

It is best to use the CreateBtblFile(char* btblname) –to save the btbl with the default name.

(for more info please see below)

6) User declared header or btbl files

Using the function GetSosUserFiles() up to 5 additional (header or binary table) files can be specified to be merged with the image file.

SOS then adds these additional files to the auxiliary ‘*.arf’ file created by the image taking sub-OS and sends ARCHIVE command to the Archiver process. Archiver process of SOS then merges all the files and informs VOLAC.

9.8.6.2 Multiple ICS headers

The ICS-es creates headers which contain keywords INS.*.* . This can cause problem when more then one ICS headers are to be merged together with the mage file.

In order to differentiate the INS keywords of the different ICS-es in the final fitsheader , the OCS.INSi.HDRCAT keyword must be specified in the configuration file.

The category ‘INS’ in the keywords ‘INS.*.*’ is then simply replaced by the specified string. The keywords created this way (of course) must appear in the dictionary (or dictionaries) of the given subsystem. In case additional dictionaries are needed for the indexed version of the keywords they must be given in the configuration of the subsystem as well.

See example of the configuration of an ICS subsystem below:

OCS.INS1.NAME "ICS"; # name of subsystem

OCS.INS1.DICT1 "XXXX_ICS"; # dictionary of subsystem

OCS.INS1.DICT2 "<any additional dic>" # dictionary of subsystem

OCS.INS1.ENVNAME "wbos"; # environment where proc. is running

OCS.INS1.PROCNAME "xxiControl"; # name process

OCS.INS1.HDRCAT "INS3" ; #category of ICS keywords

OCS.INS1.DBSTATE "<alias>XXXX:ICS:PROCESSES:WS:icsControl.state";

OCS.INS1.KEYWFILT "INS.*.*.*.*.*.*"; # keywords forwarded to subsystem

OCS.INS1.TIMEOUT 60000; # timeout for the process (seconds)

The suggested way is simply supply an index for the category INS, e.g.:

OCS.INSi.HDRCAT “INS3”;

This will change e.g. keyword ‘INS.LAMP1.ST’ to ‘INS3.LAMP1.ST’.

A new prefix can be also supplied. E.g. to change all the INS.*.*.* keywords to XXXX.INS.*.*.* ('INS.LAMP1.ST’ to ‘XXX.INS.LAMP1.ST’) in the final fits header apply the following:

OCS.INSi.HDRCAT “XXX.INS”;

Note, that in this case all the “XXX.INS.*.*.’ keywords must appear in the dictionaries of the ICS.

(Dictionaries must be approved by DMD.)

9.8.6.3 Set SOS not to merge the partial files

When a sub-OS is on other workstation, it might be advantageous that the Sub-OS merges the data instead of the super OS (e.g. instrument FLAMES-UVES).When SOS newdata event arrives and SOS should just get the data from other OS-es but should not merge the files overload the function MergeOsFiles as shown below:

ccsCOMPL_STAT xsoSERVER::MergeOsFiles(char * filename, vltINT32 expoId,

char *osname )

{

if(strcmp(osname,”UVES”)!=0)

{

if(bossSERVER::MergeOsFiles(filename, expoId, osname)!=SUCCESS)

{ return FAILURE; }

}

else

{

// (1) transfer files toUVES

// (2) tell Uves that they are ready to be merged

}

return SUCCESS;

}

Note: osname is the name of the OS which has generated the db event, i.e. the image file.

Above function is called during the image dta event.

When image data is ready by a sub OS and no further information is requested from SOS simply call the Archive(ccsTRUE) function of the SERVER class of the particular OS which should take care of the archivation.

9.8.7 Not-BOSS-based OS as a subsystem of SOS

The OS subsystem does not have to be based on BOSS. As long as it behaves according to the INS Common Software Specification [AD 07], BOSS can handle it supposing that the necessary information (see Table 7.2) about the process is correctly supplied.

Nevertheless it is necessary to supply an appropriate interface and supply the database points required.

(See section 11.14 for more information.)

Oslx supports functions are available to work on fits files (e.g. to change category, or merge binary tables). See manpage of the class oslxFITS_EXT.

9.9 Startup of Main process

9.9.1 Command line options

On the command line (as declared in BOSS) the following options are supported for the Main process:

-l <level> set standard log level

-v <level> set verbose log level

-a <level> set action log level

-t <level> set timer log level

-h print this help

-version print the version number of the software

-noDate turn off the display of date in verbose log messages (written to stdout)

-noFileLine turn off the display of file name and line number in verbose log

messages (written to stdout)

-noExit when applicable, avoid that application exits in case of a problem

when starting it up.

-c <file> specify application configuration file

For example set the verbose level[34] to the highest (useful for debugging) as follows:

xxoControl –v 5 –l 2 -noDate

For the Main process to be operational the ARchiver process should be started as well. The existence of the Archiver process is checked by the Main process when the instrument is set to ONLINE and also at the start of the image taking exposures.

Given a correct configuration it is possible to startup the default Main process without any additional C++ code, for more details see 9.9.2

9.9.2 Default Startup

In the special case when the default functionality of BOSS satisfies the requirement of an instrument OS, the C++ classes and header files in Table 10.1 can be omitted. In this case the instrument OS is started up using the ‘default startup’ functionality:

% bossControl <InsName> &

% bossArchiver <InsName> &

Where ‘InsName’ is the name of the instrument corresponding to the configuration keyword INS.CON.ID.

During the auto start the OS process created is: '<pr>oControl' and the archiver process is: bossArchiver_<pr>o

where <pr> is declared by the cfg keyword:INS.CON.PREFIX.

For the ‘auto start’ functionality the following cfg keywords must be set when other then default:

OCS.CON.OSDBROOT "<alias>xxo" ; # instr OS db point

OCS.<CAT>.DBROOT "<alias>XXXX:<insName>"; # subsystem dbroot

OCS.<CAT>.DBIFROOT "<alias>xxo:subsystems:<subsname>; # subsystem interface db;

For more details on the above configuration keyword see section 7.1, 7.2.

EXAMPLE: start up the OS processes of XXXX

% bossControl XXXX &

% bossArchiver XXXX &

The functionality can be also be used to test for errors in the overloads.

In order to debug the code several options are available, please see

9.10 Archiver process

The archiver process handles the supplementary files (*.arf) generated by the main process containing information about which files are to be merged together. See also section 6.1 on processes of BOSS.

These files are stored under INS_ROOT and removed after their successful handling, unless the process has been started up in a debug mode.

The files to be merged, deleted or archived are appear as a list of files after specific keywords, e.g.: APPENDEXT, APPENDBIN, MERGE, APPEND, ARCHIVE, DELETE.

The communication between the main process and archiver, the format of the supplementary file, and the image handling is kept private. In case more files are necessary to be merged together with the image files the user are advised to apply the naming scheme and overload functions

CreateBtblFile(), GetSosUserFiles() (see also 9.8.6, 9.6.1, 9.6.2).

For experienced users it is also possible to work directly with the arf file pointer (See also section 10.1.1 function ApplImageHandleProc()), however it is advisable to contact the BOSS developer before doing so.

In an unlucky event of the archiver process is killed (due to e.g. computer crash) there might be unhandled (and un-archived) image files left under INS_ROOT. In this case it is possible to restore these files after restarting the process. For each *.arf file under INS_ROOT/SYSTEM/DETDATA, running the following command:

msgSend “” bossArchiver_xxo ARCHIVE “-file imageFilename_00XY.arf”

The functionalities of the Archiver process cannot be overloaded, any additional features therefore should be requested via SPR.

9.10.1 Startup of Archiver Process

The command line options of the Archiver process should be used only for test and maintenance purpose:

-l <level> set standard log level (max 2) - logs are written to vlt logFile

-v <level> set verbose log level (max 5) - logs are written to stdout

-debug The *.arf file used in the ARCHIVE command will not be renamed,

but deleted.

-perftest logs on stdout the time of each steps of the archiver process.

E.g. the Archiver process can be started up as:

% bossArchiver XXXX -perftest &

9.10.2 Command queue

When the sequence of commands is optimised to carry out exposures as fast as possible (see –cond option for command WAIT in section 9.4.5) it often happens that the requests from the Main process come faster then they are processed by the Archiver process. In such case BOSS takes care of queuing up the commands for the Archiver. The queue is processed sequentially i.e. in the order the imagefiles have been generated. Should error happen while processing the ARCHIVE commands in the queue all errors are reported in the final reply given to ‘WAIT –all’. The errors are also logged during the execution which should be checked in case the number of errors exceeds the size of the error stack.

9.10.3 Performance of Archiver process

The merging process can be time consuming, especially when dealing with large files. In order to check the total merging time you can execute the following unix commands:

% sync

% time msgSend "" bossArchiver_<xx>o ARCHIVE "-file <arfile>"

% time sync

The –perftest option can be used to evaluate the performance of the subtasks (e.g. Merging headers, extentions). When using this option please note that requesting higher log and verbose level can alter the performance. (E.g. increasing the loglevel via option '-l 2' will log the data in the vltlogfile, which might reside on a different disk).

As mentioned earlier the <arfile> (which is a supplementary file generated by the Main process) only kept temporarily during a successful exposure. For test purpose (testing the ARCHIVE command) one can reserve the <arfile> and the all the partial files by killing the bossArchiver during the exposures.

The performance of merging of the merging 16 files with size 16804800 on linux platform (case for instrument VISTA) has been tested and compared at different level of the vlt software and also using a simple unix command:

- boss Archiver

- oslx oslxFITS_EXT

- cfitsio (NASA product)

- linux cat command

	cat	oslx	cfitsio	boss
Mean	8.5	9.6	9.8	9.7
Min	8	9.15	9.55	9
Max	9	12.41	10.15	10

The above test results include the time for flashing the system buffer after command response (via sync command of unix) to ensure that all data are properly saved on the disk.

(The response time of boss average 2.34 sec real time.) During the tests no other processes were running.

The results shows that there is no major difference between the performance at various level of vlt sw, cfitsio or unix cat operation. Therefore users should take into account the limited speed for the merging and select the instrument WS platform accordingly.

10 Observation Software Based on BOSS

Any instrument OS that is based on BOSS must have a configuration file, a Server class that is based on the bossSERVER class, and database declaration where the root points of the individual subsystems are declared.

Table 10.1 shows the files that are therefore necessary to include into the modules of all instrument OS through the example of the template instrument OS [RD 01].

Besides these files the configuration of the OS (together with the configuration of the ICS and start up options) must be supplied in a separate module (e.g. xxmcfg).

Table 10.1 The files that must be included in the OS (module xxo)

src

Include

cdt

dbl

Makefile

XxoControl.C

XxoSERVER.C

xxoSERVER.h

xxoPrivate.h

XxoControl.cdt

xxoSERVER.class

xxo.db

Most of the contents of these files have been already discussed in the previous chapters:

xxoControl ¾ 9.1 Initialisation

xxoSERVER.C / xxoSERVER.h ¾ 9.2 The Server class

xxoSERVER.class/ xxo.db ¾ 9.5 Database and database events

xxoPrivate.h

(xxmcfgINS.cfg ¾ 7 Configuration )

Any additional property of the instrument that does not exactly follows the standard behavior discussed in this document is considered as a specialty of an instrument that is the user’s responsibility to develop.

In the next sections there are some guidelines how to develop additional features that are most likely to occur, e.g. additional keywords, commands, database points.

The developers of an OS are recommended to first install and run the template instrument [RD 01]. This is to gain better understanding of how it works. Than they should apply the ‘translation’ operation described in the Template instrument user Manual [RD 01] in order to adopt quickly the main structure of the OS-es. This should speed up the implementation, and free the users to develop the OS-es from scratch.

BOSS takes care of the standard OS behavior which in many cases does not entirely fulfills the requirements of a particular instrument. In this chapter, directions are given to extend boss to handle additional properties.

10.1 Function overloading

There are functions that are designed to be overloaded, these are listed in section 10.1.1 and there are countless other functions that although not restricted from overloading are really meant for private use. Please read section 10.1.2 before planning to do such overloads.

Below you find some points that you should consider when adding new functionalities to BOSS:

- Is the problem general (i.e. might be useful for future or existing projects)

- Minimize the amount of code by using available functions. Understand what the functions you are calling does. Should you call an internal function (which might be designed to be called only once) please check whether a counter function is necessary and exists (e.g. init-reset).

- Handle all possible errors. Do not to rely on that BOSS automatically takes care of the error handling. Apart from checking the return status of the function the interior of the function should be robust (and be able to handle errors which can occur at any level).

- In case of additional event handling consider the possibilities that events may not happen in fixed order, or some may not happen at all.

- If you don’t know ISF, you can skip this point. If you know it, please do not copy ISF based code or double check its content for error handling and also the content of the boss function you are overloading. Be aware that ISF is practically unchanged while BOSS is continuously enhanced with new features.

- Consider maintainability, add debug logs and document the reason for the overload.

- Test Test Test A working program is one that has only unobserved bugs (Murphy)

Please submit an SPR should you require changes in BOSS to support the development of special or existing functionalities.

10.1.1 Functions to be overloaded

The functions of bossSERVER class listed below are designed to be overloaded to add specific instrument functionalities.

Except the StartPreProc and SubsystemInterfaces (9.2) functions they are all empty functions.

virtual ccsCOMPL_STAT AppConfigure(ctooCONFIG *)

virtual ccsCOMPL_STAT SubsystemInterfaces()

virtual ccsCOMPL_STAT InitPostProc();

virtual ccsCOMPL_STAT OnlinePreProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT OnlinePostProc (msgMESSAGE &msg);

virtual ccsCOMPL_STAT StandbyPreProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT StandbyPostProc (msgMESSAGE &msg);

virtual ccsCOMPL_STAT OffPreProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT OffPostProc (msgMESSAGE &msg);

virtual ccsCOMPL_STAT StateCmdPostProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT SetupPreProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT SetupPostProc (msgMESSAGE &msg, vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT StartPreProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT StartPreProcMain (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT StartPreProcSpecial (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT StartPostProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT AbortPostProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT PausePreProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT PausePostProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT ContPreProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT ContPostProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT EndPreProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT EndPostProc (msgMESSAGE &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT ExpoStatusEvtPreProc (evtEVENT_MSG &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT NewDataFileEvtPreProc (evtEVENT_MSG &msg, vltINT32 expoId, void *userData);

virtual ccsCOMPL_STAT OsNewDataEvtPreProc (evtEVENT_MSG &msg, vltINT32 expoId,

char * osName, char * osNewDataFileName, void * userData) ;

Functions for additional file handling (see also sections: 9.6, 9.6.2 and 9.8.6):

virtual ccsCOMPL_STAT CreateBtblFile(vltINT32 expoId,char* btblFileName);

This function is called after the exposuse has been finished (i.e. image is ready). When the instrument creates a binary table it has to be saved with the name 'btblFileName' (given as argument of this function) in order to OS merge it automatically with the image file. (This function can be also used to check the existence or completeness of the btbl file when necessary.)

virtual void GetSosUserFiles(char* filename, char** userfiles);

Maximum 5 files with max length 64 can be supplied by the users. These files are automatically merged with the imagefile and then removed. No error is given when file does not exist. Users must check the existence of files e.g. overloading NewDataFileEvtPreProc, OsNewDataEvtPreProc or CreateBtblFile. When specifying new filenames make sure to follow the conventions:

The binary table files must end with: _btbl.fits

Incomplete header files must end with: _hdr.fits

As default the filename array contains one file: filenamebase_xso_btbl.fits

virtual ccsCOMPL_STAT ApplImageHandleProc(vltINT32 expoId, char * filename,

bossARF_MGR* arfMgr);

For Advanced users only. Contact the developer of BOSS before overloading this function.

Image file for standalone OS or bottom level OS in an SOS structure.

The additional files can be added to the image file (specified by 'filename' generated during the exposure specified by 'expoId') via the pointer to the arf file using functions of bossARF_MGR.

BOSS checks of the returned value of these functions and returns error should they fail. However it is the developer’s responsibility to add adequate information to the error stack where things might go wrong. It is also helpful to add debug logs.

10.1.2 Overload of non empty functions

It is highly recommended that during the implementation only the specific functions listed in 10.1.1 are overloaded following the instructions in the following sections. Overloading non empty functions without a careful consideration of the content of the original function and possible modification on them has the danger that the instrument will not benefit from improvements of future releases. A possible change in design might disqualifies such overload despite that all effort is made for keeping the application back compatible. Please pay extra attention to the points at the beginning of the section 10.1.

You are recommended to contact the maintainer of the BOSS before implementing a complex functionality.

10.2 Additional configuration keyword

When an instrument cannot be configured by the existing keywords in the BOSS dictionary, the new configuration keywords must be declared in the dictionary[35] of instrument and the additional configuration procedure has to be specified (overloading function bossSERVER::AppConfigure).

More application configuration keywords can be added similarly as the example below shows.

STEP 1.: Declare configuration keyword in the dictionary of the instrument.

Typically the configuration keywords should be specified in the dictionary named ESO-VLT-DIC.<INSNAME>_OS.

Parameter Name: OCS XXX CONKW

Class: config

Context: XXXX OS

Type: string

Value Format: %s

Unit:

Comment Field: xxo example configuration keyword

Description: An example configuration keyword for the template instrument.

The following dictionaries are read by the OS automatically: OSB,OBS,TPL,DPR, <INSNAME>_OS if exists (or dictionary name as specified by bossSERVER deprecated constructor function argument).

STEP 2.: Add additional dictionary to the configuration

As the configuration file is handled by the configuration tool (ctoo) the dictionary (which contains the additional configuration keyword) must be also set in the xxmcfg module as follows:

xxmcfgCONFIG.cfg:

CONFIG.SET1.DICT "ICB_CFG OSB STOO_CFG XXXX_OS";

See more information about ctoo and stoo in the documents: Startup tool [RD-11]; Configuration tool [RD-10]. For more information on dictionaries see section 6.6.

STEP 3.: Define the keyword name in the xxo/include/xxoPrivate.h (optional).

#define xxoConfigKeyword "OCS.XXX.CONKW"

STEP 4.: Implement the configuration procedure.

xxoSERVER::AppConfigure(ctooCONFIG *cfgptr)

{

oslxKEYWORD keyw;

// Whem is not found in the configuration

if (cfgptr ->Get(xxoConfigKeyword, &keyw) == SUCCESS)

{

//save the value into a variable

strcpy((char*)cfgval_, keyw.ValueString());

slxStripQuotes ((char*) cfgval_);

// implementation of other procedures depending on this variable

// …

}

// Whem keyword is not found in the configuration

else

{

// use default values

ErrStackReset ();

strcpy((char*)cfgval_,”DEFAULT_VALUE”);

// or return an error if keyword is compolsary

//return FAILURE;

}

// add next configuration keyword if there are more

if (cfgptr ->Get(xxoConfigKeywordi, &keyw) == SUCCESS)

{…}

return (SUCCESS);

}

10.3 Additional setup keyword

In the example below two new setup keywords are declared and when they found the same example is executed.

STEP 1.: Declare the new keywords in the dictionary

Parameter Name: OCS XXX SETKW1

Class: setup

Context: XXXX OS

Type: string

Value Format: %s

Unit:

Comment Field: xxo example setup keyword

Description: An example setup keyword for the template instrument.

Parameter Name: OCS XXX SETKW2

...

STEP 2.: Declare the keyword in xxo/include/xxoPrivate.h (optional):

#define xxoSetupKw1 "OCS.XXX.SETKW1"

#define xxoSetupKw1 "OCS.XXX.SETKW2"

STEP 3.: Implement the callback that must be executed when the given keyword (or given keywords) found in the setup.

evhCB_COMPL_STAT xxoSERVER:: NewSetupKwCB (const msgCMD, const oslxKEYW_FILTER &,

oslxSHORT_FITS &keywordList, void *)

{

ExtDbgLog("xxoSERVER::NewSetupKwCB ()");

vltINT32 numberOfKeywords = keywordList.NoExtractedKeywords();

vltLOGICAL init = ccsTRUE;

//#= For each extracted keyword

for (int i=1; i <= numberOfKeywords ; i++)

{

if (keywordList.NextExtractedKeyword(init) != SUCCESS)

{

return (evhCB_NO_DELETE | evhCB_FAILURE);

}

init=ccsFALSE;

oslxKEYWORD &keyword=keywordList.CurrKeyword();

if (strcmp (keyword.Keyword(),xxoSetupKw1) == 0)

{

// implementation of the process that should be executed

// when keyword ‘xxoSetupKw1’ is given in the setup

}

else if(strcmp (keyword.Keyword(),xxoSetupKw2) == 0)

{

// implementation of the process that should be executed

// when keyword ‘xxoSetupKw2’ is given in the setup

}

}// end of for loop

}

STEP 4. Attach the function to be executed when the new keyword is found in the setup command using the protected variable :

ixacKEYW_HANDLER *keywHandlerPtr; /* Keyword trigger handler */

of the bossSERVER class as shown in the example below.

#include "ixac.h" // for ixacKFILT_OBJ_TRIGGER

xxoSERVER::InitPostProc()

{

ixacKFILT_OBJ_TRIGGER trigger(this);

oslxKEYW_FILTER keywFilter;

keywFilter.Clear();

keywFilter.AddFilter(xxoSetupKw);

keywHandlerPtr->AddTrigger("", keywFilter, trigger.Proc

((ixacKFILT_TRIGGER_METHOD)&xxoSERVER::NewSetupKwCB));

}

See the manpage of ixacKEYW_HANDLER.4 for more information.

10.4 Add new command

STEP 1. Declare the additional command 'NEWCMD' in the CDT of the OS instrument.

The application specific CDT (e.g. xxo/CDT/xxoControl.cdt[36] for the template instrument) must always include the standard CDT declared in BOSS, i.e. 'bossServer.cdt'.

#include "bossServer.cdt"

COMMAND= NEWCMD

FORMAT= A

PARAMETERS=

PAR_NAME= expoId

PAR_TYPE= INTEGER

PAR_OPTIONAL= YES

STEP 2.: Define a symbolic constants (optional)

Define a symbolic constants for the new command in the header file 'xxoBOSS/xxo/include/xxoPrivate.h' [37].

#define xxoNEW_CMD "NEWCMD"

STEP 3.: Add callback for the new command inside the InitPostProc function.

xxoSERVER::InitPostProc()

{

// Install callback(s) for command(s)

evhMSG_TYPE_KEY key(msgTYPE_COMMAND);

evhOBJ_CALLBACK callback (this);

evhHandler->AddCallback( key.Command(xxoNEW_CMD),callback.Proc(

(evhCB_METHOD)&xxoSERVER::NewCmdCB));

}

STEP 4. Implement a callback to handle command 'NEWCMD'

evhCB_COMPL_STAT xxoSERVER::NewCmdCB(msgMESSAGE &msg, void *userData)

{

}

It could be useful to take a look at the implementation of commands in the bossSERVER class, that are similar to the specific command 'NEWCMD'. The callbacks for standard commands are implemented in the following files:

boss/src/

bossExpoCtrl.C: ABORT, CONT, PAUSE, START, END

bossAddFits.C: ADDFITS

bossExitCB.C : EXIT

bossExpCB.C: EXPEND, EXPSTART

bossStateCtrl.C: OFF, ONLINE, STANDBY

bossSelftst.C : SELFTST

bossSetupCB.C: SETUP

bossCommentCB.C: COMMENT

bossWaitCB.C : WAIT

bossStateCB.C : STATE

bossStatusCB.C: STATUS

bossForwardCB.C: FORWARD

10.4.1 Send a message

if (Send(Cmd.GetCommand(), Cmd.GetMsgBuf()) != SUCCESS)

{

//#= Handles error

return (FAILURE);

}

10.5 Modifying existing command callbacks

There can be many reasons why the callbacks of the standards commands would need to be modified.

Eg. : Save some data in database.

Send an additional message to a subsystem.

Change the other of the processes in case of START.

Add additional prerequisite (e.g. modes).

It is advisable to use the empty pre- and postprocessing functions of the given command callback. See also section 9.4.2, and 9.4.4 for examples.

Below some useful procedures are introduced .

10.5.1 Declare mode, detector, subsystem, exposure status

The argument of the PreProc() and PostProc() functions are the message (msg) and the exposure id (expoId) .

The example below shows the way to declare the detector of the exposure (detId), the belonging subsystem interface (detSubsystem), and the exposure status (expoStatus).

ccsCOMPL_STAT bossSERVER::ContPreProc(msgMESSAGE &msg, vltINT32 expoId, void *)

{

ExtDbgLog("bossSERVER::ContPreProc()");

// Declare instrument mode of the exposure

VLTBYTES64 mode;

memset((char *)&mode, '\0', sizeof(mode));

if(exposurePtr->GetInsMode(expoId,(char*)mode)!=SUCCESS)

{ ErrAdd(..);return FAILURE;}

// Declare detector of the exposure

vltBYTES64 detId="";

if(exposurePtr->GetDetector(expoId,(char*)detId) !=SUCCESS)

{ ErrAdd(..);return FAILURE;}

// declare subsystem interface of the detector

bossINTERFACE_DCS *detSubsystem=NULL;

detSubsystem=(bossINTERFACE_DCS*)subSystemList.GetSubSystem((char*)detId);

if(detSubsystem==NULL)

{ ErrAdd(..);return FAILURE;}

// Get exposure status

vltINT32 expoStatus;

expoStatus =detSubsystem->GetExpoStatus();

if(expoStatus== inscEXP_UNDEFINED)

{err handling..}

// implement pre pocessing

// ...

return SUCCESS;

}

10.6 Operation bypassing the OS/SOS

Experience showed that control of subsystem bypassing the OS/SOS is often required.

Typical examples are listed below:

Start or stop a looping with technical CCD directly from its panel.
Commands sent via FORWARD command ( Although the FORWARD command is sent to OS the command specified by the parameter bypasses the OS. The OS reports only the reply for the given command.)
Commands sent directly to subsystems. This occurs in case of SOS, for example when BOB sends commands directly to the subOS for calibration while SOS observation takes place on an other subOs simultaneously (e.g. FLAMES).

These actions result in unexpected events for BOSS. The events coming from a subsystem that is not directly controlled by the OS or SOS are ignored. Their status are also not included in the global status either. In the global status only the status of the ‘active’ DCS or OS subsystems are included, which has been set up and started by through the OS.

11 FAQ and Troubleshooting

11.1 Manual start up of BOSS OS

See a proper startup example below :

> xxoControl &

> bossArchiver XXXX &

In case of any problem (that cannot be identified by error or log messages) the highest debug options for the control process should be set as follows:

xxoControl -v 5 -l 2 > mydebug.report &

11.2 Parameter ‘-expoId’ in the commands

Question:

Does the expoId need to be declared all the time in the commands?

Answer:

In the SETUP command the expoId always has to be declared! Even in a special case when no detector subsystem is involved in the instrument.

In the first SETUP command the expoId must be 0. This returns a new expoId with which one can refer to the given exposure.

In the other commands it is not compulsory to supply the expoId, nevertheless when there are more then one exposure has been set up at a time it is strongly recommended to supply either the expoId or the detId.

ExpoId can be omitted when there is only one exposure is set up at a time, as the following example shows:

>msgSend "" xxoControl SETUP "-expoId 0 -function DET1.DIT 10 INS.MODE IR_IMAGING OCS.DET.IMGNAME myfile.fits"

>msgSend "" xxoControl START ""

>msgSend "" xxoControl ABORT ""

11.3 Subsystem list or instrument mode is not declared in the setup

Question:

Trying to setup and start a single exposure without saving an image with TCCD such as:

> msgSend "" xxoControl SETUP "-expoId 0 -function DET2.WIN1.UIT1 10"

> msgSend "" xxoControl START "-expoId 1 -detId TCCD"

This returns error saying that subsystem list is not declared.

How the subsystem list has to be declared?

Answer:

The subsystem list should be always given for an exposure. It has to be given by the instrument mode i.e. by keyword INS.MODE. The subsystem list for the given mode is given by the OCS.MODEi.SUBSYST keyword in the configuration file. Following solves the problem:

> msgSend "" xxoControl SETUP "-expoId 0 -function DET2.WIN1.UIT1 10 INS.MODE GUIDING"

> msgSend "" xxoControl START "-detId TCCD"

Note that during start it is sufficient to enter either the expoId or the detId.

11.4 Usage of command STATUS

Question:

How can I send a STATUS command to a subsystem through the OS process?

Can you give me an example: STATUS -expoId <some value> -function <some value> ...

Answer:

1.) Execute an exposure.

2.) To get information from ICS you can send to the OS process the status cmd directly:

>msgSend "" xxoControl STATUS "-expoId 1 -function INS.DPOR.ST"

MESSAGEBUFFER:

INS.DPOR.ST "F"

3.) To get information from DCS forward the STATUS command as follows:

>msgSend "" xxoControl FORWARD "-subSystem IRDCS -command STATUS -arguments 1,DET.DID"

MESSAGEBUFFER:

DET.DID "ESO-VLT-DIC.IRACE-1.0"

In case of technical ccd:

>msgSend "" xxoControl FORWARD "-subSystem TCCD -command STATUS -arguments 1,DET.MODE"

MESSAGEBUFFER:

128,DET.MODE 3

The parameter -subSystem is the name of the subsystem (as declared in the xxmcfgINS.cfg file).

The parameter -arguments is composed from the parameters of the STATUS command of the ccd.

(i.e. expoId, function in this case)

Take a look at the declaration of the STATUS command in the CDT of TCCD also

($VLTROOT/ccdconCI.cdt), and the declaration of the FORWARD command in BOSS cdt ($INTROOT/osbControl.cdt)

11.5 Usage of command ADDFITS

Question:

How the ADDFITS command is used?

Can you give me an example: ADDFITS -expoId ....

Answer:

This command can be executed after the exposure has been setup and while it is running. e.g.:

> msgSend "" xxoControl SETUP " -expoId 0 -function INS.MODE OPT_IMAGING

OCS.DET.IMGNAME myfile.fits"

>msgSend "" xxoControl ADDFITS "-info OCS.CON.RELEASE \" My additional info\" "

>msgSend "" xxoControl START "-expoId 3"

>msgSend "" xxoControl ADDFITS "-expoId 3 -info OCS.CON.ORIGIN \" myvalin\" "

The keywords given as via the parameter ‘-info’ will be than placed in the header of the image file. Note that the expoId is not a compulsory parameter for ADDFITS.

11.6 Add additional keyword to the fits header

11.6.1 Example-1: Add keyword to OS image

In any of the PreProc() function (START or SETUP) to do the following:

ccsCOMPL_STAT xxoSERVER::StartPreProc(msgMESSAGE &msg, vltINT32 expoId,

void *)

{

ExtDbgLog("xxoPreProc::StartPreProc()");

oslxKEYWORD keyword;

keyword.Keyword("INS.SPEC.KW");

keyword.Type(slxSTRING);

keyword.ValueString("XXXX");

bossFITS_HEADER *headerPtr;

headerPtr=exposurePtr->GetHeader(expoId);

if (headerPtr==NULL)

{

ErrAdd (bossMODULE_ID, bossERR_GENERAL, __FILE_LINE__, "Could not get header");

return FAILURE;

}

if(headerPtr ->CreateStoreFits(keyword)!=SUCCESS)

{

ErrAdd(..);

return FAILURE;

}

// other actions if necessary

// …

return SUCCESS;

}

The keyword must be specified in the dictionary. It is possible to declare more then one dictionary for a subsystem, e.g.:

OCS.DET2.DICT1 "CCDDCS"; # For dictionary : ESO-VLT-DICT.CCDDCS

OCS.DET2.DICT2 "CCD"; # For dictionary : ESO-VLT-DICT.CCD

Caution: in case the setup pre or post processing functions are overloaded it must be taken into account that the argument expoId in the function denotes either the next exposure (if ‘-expoId 0’ was specified in the command) or an exposure that might have been already started. Therefore probably some additional check for the special action is necessary.

11.6.2 Example-2: Add keyword to SOS image file

In case of SOS additional keywords can be added at any level overloading functions in the server class of the SOS or in sub-OS similarly to a non SOS, e.g.:

ccsCOMPL_STAT fpoSERVER:: ExpEnd(char* filename, vltINT32 expoId, char *detId)

{

ExtDbgLog("fpoSERVER::Expend");

// check the mode or the detector if necessary (see 10.5.1)

// specify the keyword to be added

oslxKEYWORD kw;

kw.Keyword("INS.OBSPLATE");

kw.Type(slxINTEGER);

vltINT32 obsplate;

dbRead (&obsplate, "<alias>fpFlames.fpFitsPlate");

kw.Integer(obsplate);

//retrieve the header belonging to the exposure

bossFITS_HEADER * hdr;

hdr=exposurePtr->GetHeader(expoId);

if (hdr == NULL)

{

ErrAdd(..);

return FAILURE;

}

if(hdr->CreateStoreFits(kw)!=SUCCESS)

{

return FAILURE;

}

/* call the original function*/

return bossSERVER::ExpEnd(filename,expoId,detId);

return SUCCESS;

}

Note that keywords can be added also via command ADDFITS to SOS as well, as the example below show:

msgSend "" xsoControl ADDFITS "-detId XXXX -info OCS1.INS.FILT 9"

11.7 Dictionary for OS

Question:

On which dictionary should the instrument specific OS be based?

Answer:

None has to be compulsorily declared. The dictionary of BOSS (ESO-VLT-DIC.OSB) is always loaded automatically.

Additional keywords can be supplied by loading the dictionary of your own process. Place the additional keywords (if there are any) in a separate dictionary named ‘ESO-VLT-DIC.XXXX_OS’,

Where XXXX is the name of the instrument. This dictionary is automatically loaded if exists.

When you require to declare new keywords, it is strongly recommended to follow the steps described in section 10.3.

It is possible that you do not need additional dictionary at all.

11.8 Parameter ‘-detId’ in command

Question:

What should be used for the detId parameter in the START command i.e. which keyword value and from which *.cfg file should be taken? Can you give an example?

Answer:

In general, the detId must be the name of one of the DCS (or OS) subsystems that is declared in the configurations file, e.g.:

OCS.DET2.NAME "TCCD"

Normally you don't have to specify detId, only expoId for the START command.

Using the –detId parameter can be useful when one cannot keep track of the expoId.

> msgSend "" xxoControl SETUP "-expoId 1 -function INS.MODE GUIDING

> msgSend "" xxoControl START "-detId TCCD"

The parameter -detId can be also useful when there are more then one DCS-es involved in the exposure. During the setup you have to declare the subsystems (by specifying the INS.MODE keyword in the first SETUP) The subsystem list must include the DCS or DCS-es with which the exposure is taken. Note that for single exposures there is no reason to declare more then one DCS on the subsystem list. Nevertheless in case of semi-parallel exposures all the DCS wich are allowed to be started in the given mode should appear on the subsystemlist as well)

Please see a complete example below:

1. first remove the existing fits file)

cd $INS_ROOT/SYSTEM/DETDATA

% rm -fr ccdImageLcuSim.fits

2. setup an exposure with two detectors

> msgSend "" xxoControl SETUP " -expoId 0 -function INS.MODE IR_SPECTROSCOPY

OCS.DET.IMGNAME ccdImageLcuSim.fits"

MESSAGEBUFFER:

where the mode IR_SPECTROSCOPY is specified as follows:

OCS.MODE3.NAME "IR_SPECTROSCOPY" # name of the instrmode

OCS.MODE3.SETUP "-function INS.MIRR1.NAME IRED INS.DROT.POSANG 10.0" # setup of mode

OCS.MODE3.SUBSYST "IRDCS TCCD ICS UT0" # subsystems involved in the given mode

OCS.MODE3.PATH "INFRARED" # instrument path (EXPSTRT, EXPEND)

3. Start the technical ccd

msgSend "" xxoControl START "-detId TCCD"

11.9 Place of pre-processing functions

Question:

What is the right place (file) in the 'yyo' module to do preprocessing of the START command. yyoControl has to write into LCU DB prior to sending START command to CCD WS process.

Answer:

Please place the function ‘yyoSERVER::StartPreProc()’ it in file ‘yyoExpoCtrl.C’ (as the overloaded function ‘bossSERVER::StartPreProc()’ can be found in in ‘bossExpoCtrl.C’).

11.10 Instrument with no detector

As default BOSS epects that there is a detector subsystem in each mode.

When there is no detector in the system overload the StartCB function to contain only the

- condition for executing the command.

- the process that need to be carry out in this case.

11.11 Data base point ‘NewData’

Question:

Is it true there will be ONLY ONE newData point in the database even if there are more than one instrument produces data?

Answer:

Yes all the OS-es use the same newData db point. When an OS has finished creating an image

It writes the datafile name into this attribute to inform VOLAC to archive the image.

There is no restriction how many OS writes into this dbpoint, and whether or not there is connection between the OS-es through a super OS.

The best is to place the OS-es under a common root. (It is enough to define OS_ROOT once)

e.g.

INSTRUMENT

|-----------newdata

|-----------OS1

| |

| ---subsystems

| |

| -----ICS1

| |

| ------FIERA

|-----------OS2

| |

| ---subsystems

| |

| -----ICS2

| |

| ------IRDCS

| -----------SOS

| |

| ---subsystems

| |

| -----OS1

| |

| -----OS2

11.12 Additional Action when Exposure fails, succeeds or aborted

Add an Instrument specific action. E.g. when it is required to send a command to a subsystem each time exposure fails, succeeds or aborted, overload the empty function:

bossSERVER::ExpoStatusEvtPreProc(msg, expoId, userData)

The following example shows also how to retrieve this information about the global status, and the source of the event (specifying the DCS/OS) and whether or not file imagefilename is specified for the exposure.

Note:The status values depend on the actual DCS (See also section 9.7.2 )!

ccsCOMPL_STAT mySERVER::ExpoStatusEvtPreProc(evtEVENT_MSG &,

vltINT32, void *)

{

ExtDbgLog("bossSERVER::ExpoStatusEvtPreProc()");

//#= Declare the new status value that generated this message

vltUINT32 newExpoStatus;

const char * cp;

cp = (msg.EventInfo()).scalar.newValue;

memcpy((char *)&newExpoStatus,cp,sizeof(vltUINT32)) ;

TestLog ("The new status is %d",newExpoStatus);

//#= global status

//exposurePtr->UpdateObsStatus(newExpoStatus);

//vltINT32 obsStatus = exposurePtr->GetGlobalExpoStatus();

//#= declare the name of the detector which is associated with this message

//vltBYTES64 detId="";

//if(exposurePtr->GetDetector( msg.AttrName(),(char*)detId)!=SUCCESS) { handle error };

//# declare filename associated with the exposure

//vltBYTES256 filename="";

//if (exposurePtr->GetFileName(expoId, (char*)filename)!=SUCCESS) {handle error};

if ( (newExpoStatus == inscEXP_COMPL_FAILURE) ||

(newExpoStatus == inscEXP_COMPL_ABORTED) ||

( newExpoStatus == inscEXP_COMPL_SUCCESS ) )

{

// Additional user declared processes

}

return SUCCESS;

}

Additional SOS Action when Exposure fails, succeeds or aborted

In case of SOS the same function ‘ExpoStatusEvtPreProc’ can be overloaded , but there other options too depending on the problem.

E.g. ‘ExpendCB’ can be overloaded. When a sub-OS has finished/failed or aborted SOS sends an EXPEND command to the otherOS-es on the subslist.

11.13 Interface for subsystem that does not fall into any of the given categories

As default when OS receives a command START it sends START command to DCS and EXPSTART command to ICS/TCS.

When exposure is finished and image is created OS sends EXPEND and STATUS to ICS. Otherwise when exposure failes/aborted OS sends EXPEND/STOP command to ICS.

Interface

When the subsystems should not be treated according to DCS or ICS a new interface has to be created inheriting from class bossINTERFACE , e.g.:

mcoINTERFACE_STRAP::mcoINTERFACE_STRAP(const dbSYMADDRESS dbPoint,

char * srvId) :

bossINTERFACE(dbPoint, evhDB_COMMAND_CLASS)

{

//#= set the category to be OS

SetCategory(strap_SUBSYS);

}

A new category for this interface has to be spacified. The reserved categories are:

#define bossICS_SUBSYS 0x1 // ICS sub-system

#define bossDCS_SUBSYS 0x2 // DCS sub-system

#define bossTCS_SUBSYS 0x4 // TCS sub-system

#define bossOS_SUBSYS 0x8 // OS server

After specifying the new interface, you must add it to the list of interfaces in the function

SubsystemInterfaces().

Default behaviour

When the subsystem (ie. its interface) does not fall into the pre-declared categories, BOSS still takes care of the following automatically:

1) state of the subsystem is taken into account when global state is evaluated

2) SETUP keywords that mach the pattern given by the configuration keyword OCS.<CAT>.KEYWFILT will be forwarded to the subsystem.

Any additional functionality must be included into function overloads.

Declaration of the subsystem on the configuration file

In the configuration file you might wish to declare a new keyword category for the subsystem (in which case the keywords must be declared in the dictionary of the OS)

OCS.STR.NAME "STRAP";

OCS.STR.DICT "STR";

OCS.STR.ENVNAME "wbos";

OCS.STR.PROCNAME "strapControl";

OCS.STR.KEYWFILT "STR.*.*.*.*.*.*";

OCS.STR.TIMEOUT 1000;

OCS.STR.DBROOT "<alias>strap";

OCS.STR.DBSTATE "<alias>strap.opState";

In the above example the dictionary 'STR' must contain the SETUP keywords that are forwarded to the 'strapControl' process.

Add additional functionality

Send a command during start command to the 'strap' process

Should you need to inform the subsystem about the event when the exposure is started you must overload the StartPreProc function. (See also chapter 9.4.4 for the default StartPreProc implementation.)

ccsCOMPL_STAT mcoSERVER::StartPreProcSpecial(msgMESSAGE &msg, vltINT32 expoId,

void *userData)

{

ExtDbgLog("mco SERVER::StartPreProcSpecial()");

if (mcoIf->Send("STRAPCMD","") != SUCCESS)

{

ErrAdd (mcoMODULE_ID, …. );

return (FAILURE );

}

return SUCCESS;

}

11.14 What to do when OS subsystem of SOS is not based on BOSS

Database

In the configuration file make sure that the database points for state, exposure status and newdata are correctly set (see 7.6).

OS new data dbpoint has to be created (if not exists) and refreshed when image file is ready in order SOS carries out the exposure end processes (if required).

As default SOS requires the *.arf file generated by the sub-OS to merge imagefile with other files.

When image file is created by non-BOSS based OS this file does not exists, therefore the ‘exposure end’ process of the SOS must be overloaded.

Interface for non BOSS based OS

A new interface for the OS based om bossINTERFACE_OS has to be developed.

BOSS ensures that the expoId of the SOS exposure is the same as the expoId of its sub-OS which is included in the exposure. When the sub-OS does not follow this strategy the expoId conversion in the interface must be solved.

Handling of Internal SOS-OS Commands

There are some internal commands to support communication between SOS and OS. These are : CLEAN and GETHDR.

The designer of the SOS should decide whether these commands are useful for the non-based sub-OS

In which case implement the callbacks for them.

When these BOSS auxiliary commands can be avoided, the simplest way to avoid them is to overload the function Send() of the interface of the sub-OS in the following way:

ccsCOMPL_STAT xxoINTERFACE_MYOS::Send(const msgCMD command,

const char *parameters, msgLENGTH parametersLen,

vltLOGICAL timeoutFlag, vltLOGICAL paramCheck)

{

ExtDbgLog ("bossINTERFACE_MYOS::Send() command %s to %s ",command, name_);

// do nothing when the command is CLEAN or GETHDR

if(strcmp(command,bossCLEAN_CMD)==0 ||

command, bossGETHDR_CMD)==0 )

{

return SUCCESS;

}

else

{

return bossINTERFACE:: Send(command, parameters,

parametersLen, timeoutFlag, paramCheck);

}

11.15 TCS in the SOS structure

Question :

What happens if TCS is included more then once in the configuration files of an SOS structure?

Answer:

It is a pre-condition of SOS that there is only one TCS in the whole system and only one OS (typically at the top level) has an access to it.

A ‘stand-alone’ OS can have all sort of TCS access e.g.:

- TCS access NORMAL

- TCS access IGNORED, or

- no TCS declared at all.

It is also allowed (however not recommended) to include TCS in the configuration of more then one OS-es in the hierarchy of an SOS, with the limitation that only (maximum) one OS have NORMAL access to TCS (and the rest must be set to IGNORED).

The side effect of having more then one access to the TCS would cause that the TELESCOP keyword will appear more then once in the fits header. An other problem is –that when the TCS appears with the same configuration name in different configuration file- that the TCS header file is created more then once (i.e. as many times it appears in the configuration with normal access) with the same name, merged more then once and later tried to be deleted more then once, which of course leads to error (as there is only one file).

11.16 File merging

Question:

When producing the final FITS file which contains File1+Header1+Bin1, is this done as a copy ?

Answer:

From APR2004 temporary copy of fitsfiles are no longer created in order to improve speed.

However before APR2004 version of BOSS, yes a temporary copy of the fitsfile was created. It is a facility of oslxFITS_EXT to select whether a temporary file is created during LoadImageFile(), i.e. during an update of a file. For safety (i.e. in order not to loose data in case something goes wrong) boss created a temporary copy of the image file, and the original file was replaced (and the other header files removed) only when the merging was successful.

Question:

Is the SOS busy until the enf of the merging? i.e can we start a new exposure during merging ?

Answer:

The time-consuming file merging is always done by a separate process (bossArchiver_<xx>o).

Nevertheless since APR2004 as default the merging has become part of the exposure circle therefore it delays the execution of the next exposure. If this delay is not acceptable it is possible to run an optimized sequence of command setting parameter –cond for the WAIT command parameters (see 9.4.5).

Nevertheless even in this optimized case, there is still a slight (noticeable) delay after the DCS has created the image. OS when informed that DCS image is ready, gets the header from the other subsystems (given on the list). Then creates a supplementary file (where information about files to be merged is stored), and then sends a command to the archiver process to process this (supplementary) file. Some internal cleaning is also done, to prepare for the next exposure.

In addition -in case of SOS- headers are also collected from other OS-es (via command GETHDR). All these are of course also consume time.

Question:

Is there enough space reserved in File1 for Header1?

Answer:

The fitsfile is processed by oslxFITS_EXT which is based on 'cfitsio' from NASA. Problem is solved within cfitsio routines. For more info on cfitsio look up the following web site: http://heasarc.gsfc.nasa.gov/docs/software/fitsio/fitsio.html

11.17 Add Special Online Action

In order to execute your special ONLINE actions the following three ways are available:

a) Action during startup when global state is online

If you only need to execute a procedure only once during startup in the case when the system is online overload the function InitPostProc as follows:

ccsCOMPL_STAT xxoSERVER:: InitPostProc()

{

/*This is only called once at startup*/

printf("TEST-InitPostProc\n");

vltINT32 state = subSystemList.GetOverallState();

if (state==bossSTATE_ONLINE) // evhSTATE_ONLINE

{

ActionLog(1,"XXXX:InitPostProc:ONLINE ACTION at START UP*****");

//implement special online action

}

return SUCCESS;

}

b)Action regarding the change in the global state.

To make sure that every time when the global state changes to online a special online action is executed overload the function StateEvtCB().

The function StateEvtCB() is executed when the state of one of the subsystems changes. However this function will not be called when everything is online and you send an ONLINE command. Note that this function is also called during startup.

evhCB_COMPL_STAT xxoSERVER::StateEvtCB(evtEVENT_MSG& event , void *userdata)

{

ExtDbgLog("bossSERVER::StateEvtCB(%s)", event.AttrName() );

vltINT32 state = subSystemList.GetOverallState();

printf("STATE_CB\n");

printf("THE STATE IS:%d\n",state);

if (state==bossSTATE_ONLINE) // evhSTATE_ONLINE

{

printf("XXXX: StateEvtCB : ONLINE ACTION \n\n");

// implement special online action here

}

return (bossSERVER::StateEvtCB(event,userdata));

}

c ) Procedure as part of ONLINE command

When you need to execute a procedure when ONLINE command is sent overload the functions

ccsCOMPL_STAT bossSERVER::OnlinePostProc(msgMESSAGE &msg)

ccsCOMPL_STAT bossSERVER::OnlinePreProc(msgMESSAGE &, void *)

as explained in earlier chapters.

12 Installation Guide

The boss package is part of the VLT Common Software Delivery. [RD 05]

13 Maintenance

BOSS is maintained through SPRs. Should you find any problems or have any request please submit an SPR specifying the follwing data:

Package : INS-OS base modules

Module: boss

Please also supply the version of boss used. You can always check the version by sending command VERSION to an active control process. E.g: “”

> msgSend “” xxoControl VERSION “”

In case of problems debug information of boss can be very useful:

Debug file (containing the name of functions called with additional data) cen be generated by starting up the server process as follows:

% xxoControl –v 5 –l 2 > xxo.dbg

% bossArchiver XXXX

Should you need a higher version of boss then included in the last release, you should always check the information given in the files below before compiling boss:

1) boss/Changelog

Indicates the changes in the new versions.

2) boss/BackCompNotes_<RELEASE> -

Indicates module version dependency i.e. which other modules you need to retrieve

and install before compiling the new version of boss.

Should back incompatible change occur in boss, you will find a note about it in this file too.

Caution : Never take a version the history logs or the Changelog of which says ‘under development’ or ‘under test’.

Module versions:

MAR2001: boss 1.35.1.3, osb 1.12, bossvlti 1.2, ixac 1.37, ibac 1.26

MAR2002: boss 1.81, osb 1.20, bossvlti 1.5, ixac 1.43, ibac 1.29

APR2003: boss 1.106, osb 1.24, bossvlti 1.5, ixac 1.45, ibac 1.29

APR2004: boss 1.129, osb 1.28, bossvlti 1.6, ixac 1.46, ibac 1.30

14 Reference

Below only the man pages of the most relevant classes: bossSERVER, bossARCHIVER, bossEXPOSURE, bossINS_MODE, bossINTERFACE_DCS, bossINTERFACE_CCD can be found.

The users are welcome to take a look at the manpages of other classes (see Figure 3) online.

14.1 Manpage of the bossControl

bossControl

NAME

bossControl - Observation Software Server

SYNOPSIS

bossControl <INS_NAME> [-v <level>] [-l <level>]

DESCRIPTION

The program 'bossControl' starts up the default OS server process of the

instrument specified by its name <INS_NAME>.

This process handles all the standard OS commands and performs the corresponding

default actions. The process is fully operational.

Before an instrumnt OS is started up by 'bossControl' its configuration file,

CDT and database must exits. (see details in document on BOSS,XXXX)

During the startup boss creates the default interfaces for the subsystems given

in the configuration file.

For DCS-es the interfaces are created according to the configurtion kw

OCS.<DETi>.TYPE. For subsystems with category INSi, interface ICS is created,

and TCS interface is created for TELESCOPE.

During default startup, boss declares the default 'database root'

for the OS server process as: ':Appl_data:<INS_NAME>:OS'.

When the db address of the OS process is different then the default,

use the OCS.CON.OSDBROOT configuration keyword to set the appropriate value.

The default database root for each subsystem interface is:

'<dbRoot>:subsystems:<subsname>'.

Where <subsname> is the lower case version of the name of the

subsystem as specified by the keyword "OCS.<CAT>.NAME" in the cfgfile.

E.g. when the NAME of the susbsytem is IRDCS, the dbaddress of its interface

expected as default is : '<dbRoot>:subsystems:irdcs'.

Exception:In case of TCS/VLT systems (The name is e.g. UTi) the default db

address of its interface is: '<alias>xxo:subsystem:tcs'.

When the dbaddress of the interface is different the default,

use the OCS.<CATi>.IFDBROOT keyword in the configuration file.

VLTI currently not supported. Set the ISS access to be ignored during tests,

for the auto start up of vlti instruments.

Most instruments do have some additional (non-default) properties.

The 'default startup' functionality can be used to check errors in the

overloaded functionality.

FILES

Configuration files are stored under directory:

$INS_ROOT/SYSTEM/COMMON/CONFIGFILES.

During start up the configuration file identified by <INSNAME>

(i.e.by the INS.CON.ID configuration keyword) is loaded.

(see documentation on ctooCONFIG for more information)

EXAMPLES

Normal startup (using default values) n");

% bossControl XXXX

% bossArchiver XXXX

For debugging (creating debugfiles with highest debug level)

% bossControl XXXX -v 5 -l 2 > xxo.dbg &

% bossArchiver -n bossArchiver_xxo -dbRoot '<alias>xxo'-v 5 -l 2 > xxoarf.dbg &

(The archiver process really need debaugging.)

### generated by docDeroff ###

14.2 Manpage of the bossSERVER class

bossSERVER

NAME

bossSERVER - Instrument server main class

SYNOPSIS

#include "bossSERVER.h"

bossSERVER myServer;

PARENT CLASS

bossDB_TASK --> evhTASK -->evhSIMPLE_TASK

--> fndOBJECT,eccsERROR_CLASS

DESCRIPTION

This class gives a default implementation of the features of an instrument

server (e.g. Observation Software) which is in charge of handling the

requests from outside and control one or more sub-system servers. This

includes:

o handling the standard commands: ABORT, ADDFITS, COMMENT, CONT, END,

FORWARD, OFF, ONLINE, PAUSE , SETUP, STANDBY, START, STATE, STATUS,EXIT, PING,

and WAIT. The commands DEBUG, VERBOSE are also

handled by inheritance from ixacTASK (see ixacTASK(4)).

o handling incoming Setup Files and setup keywords, checking of

individual keyword (correctness of values) and of the whole keywords

(completeness and consistency) and forwarding them to the appropriate

sub-system,

o handling Application Configuration File to configure and set-up

preferences for Server,

o handling of instrument modes,

o handling of states and sub-states, state transitions, as well as state

alignment according to the sub-systems,

o handling of sub-system communication: sending synchronous and

asynchronous commands, synchronization of replies,

This class is the core class for building OS servers.

The OS-es must have a class inheriting this class, and oveloading the functions

to declare their special behavior. There are functions that are designed to be

overloaded (see below).

Note: most of the commands supported by bossSERVER class have a <subSystem>

parameter, which is used to forward the command towards software (i.e

sub-systems) implicated in the control of the instrument. The structure

of this parameter is similar to a Short-FITS keyword i.e fields delimited by

the character '.', where each field corresponds to the name of one

sub-system. In this way, the <subSystem> parameter is representative of the

sub-system hierarchy of the instrument. The general scheme of the parameter

<subSystem> used by BOSS is:

<subSystem 1>.<subSystem 2>.<subSystem 3>....

Thus, when the <subSystem> parameter is specified, the command is sent to

the <subSystem N> which will send the command to the <subSystem N+1>, and so

on. Each time the command is forwarded, the <subSystem> parameter is

modified to suppress the field which corresponds to the name of the

sub-system to which the command is sent. An example of this scheme is

"OS1.ICS", where the command is first sent to 'OS1' sub-system, which will

send it to its 'ICS' sub-system. The command is forwarded in this way:

1. The command '<command> -subSystem "OS1.ICS" ...' is received.

2. The command '<command> -subSystem "ICS" ...' is sent to the 'OS1'

sub-system.

3. Then, the command '<command> ...' is sent by 'OS1' sub-system to the

'ICS' sub-system.

The identification of a sub-system is based of its name which is returned by

the GetName() method of the bossINTERFACE(4) class.

The HasDestSubSystem() and GetDestSubSystem() can be used to manipulate the

<subSystem> parameter.

Some other command have the parameter -detId which is used to identify detectors.

! Please note that it is not yet developed for super OS. And therefore it is not (yet)

alike to the parameter -subSystem.

PUBLIC METHODS

bossSERVER(const dbSYMADDRESS dbPoint,

const char *version = "No module version set");

virtual ~bossSERVER();

Constructor/Destructor.

virtual ccsCOMPL_STAT Init(char *dictionary, char *alias, char *instrumentId,

char *keyDbMap);

Performs initialization of the Instrument server, it mainly includes:

o loading of dictionary and alias table of the server.

o loading of the Keyword<-->DB map file

o installation of specific server callbacks

o configuration of the server (see Configure() method below)

o install callback to handle state alignment (if required).

virtual ccsCOMPL_STAT bossSERVER:: InitPostProc()

this function is an empty function designed to be overloaded

when additional initilaisation of the system is required

virtual ccsCOMPL_STAT Configure(char *instrumentId=NULL);

Loads configuration file and configure instrument server accordingly i.e.

configures the sub-system interfaces, loads sub-system dictionaries,

defines instrument modes, then calls keyword handler and the calls

AppConfigure() method.

When no file name is specified, the previous configuration file is

re-loaded.

virtual ccsCOMPL_STAT AppConfigure(ctooCONFIG *appConfig);

This method should be overloaded by the application classes which inherit

from bossSERVER, so as to perform specific application configuration

according to the keywords loaded from configuration file and stored in

ctooCONFIG instance. By default, this method does nothing.

virtual char *GetOsVersion();

Returns the version number of the Instrument Server.

virtual ccsCOMPL_STAT SetMaintenanceMode (vltLOGICAL newValue);

Switches on or off maintenance mode.

virtual vltLOGICAL IsMaintenanceModeActivated ();

Returns true (ccsTRUE) if the maintenance mode is set.

virtual ccsCOMPL_STAT SetAlignState(vltLOGICAL newValue);

virtual vltLOGICAL IsAlignedState();

Handles state alignment with sub-system states.

virtual evhCB_COMPL_STAT CheckStates (const char *command);

Checks if the command can be executed in the current state and sub-state.

It returns SUCCESS when command is allowed (see table below) and FAILURE

otherwise. It may be overloaded in a subclass if it is necessary to modify

command execution checking.

+----------+---------------------------------------+

| Command | Validity |

+----------+---------------------------------------+

| ABORT | Online |

| ADDFITS | Online |

| COMMENT | Online |

| CONT | Online |

| END | Online |

| EXIT | Not in On-line/Observing |

| FORWARD | Always |

| OFF | Not in On-line/Observing |

| ONLINE | Not in Off |

| PAUSE | Online |

| PING | Always |

| SELFTST | Always |

| SETMODE | Always |

| SETUP | Online/Idle |

| STANDBY | Not in On-line/Observing. |

| START | Online |

| STATE | Always |

| STATUS | Online |

| VERBOSE | Always |

| VERSION | Always |

| WAIT | Online |

+----------+---------------------------------------+

virtual ccsCOMPL_STAT NewExpoId(vltINT32 *expoId);

Created a new exposure ID. It simply consits by calling the NewExpoId

method of the bossEXPOSURE instance.

virtual ccsCOMPL_STAT CheckExpoId (msgMESSAGE &msg, vltINT32 *expoId);

Retrieves the exposure Id from the command parameter list. If no exposure

Id has been specified, then it gets the current one. If it is equal to 0, and

the command is the SETUP command, it sets a new exposure Id, otherwise it gets

the current one. And then it check if the exposure Id is valid.

Note that the NewExpoId() and CheckExpoId() methods call the methods

NewExpoId() and CheckExpoId() of the bossEXPOSURE instance. If the server

has to support specific features (e.g. when new

exposure Id is set) then these methods have to be overloaded.

virtual ccsCOMPL_STAT CheckExpoStatus(const char *command,

vltINT32 expoId,char * det=NULL);

Check if the command can be executed according to the exposure status on the

given detector (if specified), otherwise on the list of detectors specified by

the exposure with the given 'expoId".

It returns SUCCESS when command is allowed (see table below) and FAILURE

otherwise. It may be overloaded in a subclass if it is necessary to modify

command execution checking.

+----------+---------------------------------------+

| Command | Valid exposure status |

+----------+---------------------------------------+

| ABORT | PENDING or INTEGRATING or PAUSED or |

| | READING_OUT or PROCESSING or |

| | TRANSFERRING or RUNNING |

| CONT | PAUSED |

| END | Same as ABORT |

| PAUSE | Same as ABORT (except PAUSED) |

| START | UNDEFINED or INACTIVE or SUCCESS or |

| | FAILURE or ABORTED or FINISHED |

+----------+---------------------------------------+

In case of a list of detectors function return success when cmd can be

executed on all the detectors.

virtual evhCB_COMPL_STAT AbortCB(msgMESSAGE &msg, void *userData);

Callback to handle ABORT command.

virtual evhCB_COMPL_STAT AddFitsCB (msgMESSAGE &msg, void *userData);

Callback to handle ADDFITS command.

virtual evhCB_COMPL_STAT CommentCB (msgMESSAGE &msg, void *userData);

Callback to handle COMMENT command.

virtual evhCB_COMPL_STAT ContCB(msgMESSAGE &msg, void *userData);

Callback to handle CONT command (see also ExpoCtrlCmdProc).

virtual evhCB_COMPL_STAT EndCB(msgMESSAGE &msg, void *userData);

Callback to handle END command (see also ExpoCtrlCmdProc)

virtual evhCB_COMPL_STAT ExitCB(msgMESSAGE &msg, void *userData);

Callback which is executed whenever the EXIT command is received.

virtual evhCB_COMPL_STAT ForwardCB (msgMESSAGE &msg, void *userData);

Callback to handle FORWARD command.

virtual evhCB_COMPL_STAT OffCB(msgMESSAGE &msg, void *userData);

Callback to handle OFF command.

virtual evhCB_COMPL_STAT OnlineCB(msgMESSAGE &msg, void *userData);

Sets the state of the local task or of the specified subsystem to ONLINE.

virtual evhCB_COMPL_STAT PauseCB(msgMESSAGE &msg, void *);

Callback to handle PAUSE command (see also ExpoCtrlCmdProc)

virtual evhCB_COMPL_STAT SelftstCB(msgMESSAGE &msg, void *userData);

Callback to handle SELFTST command.

virtual evhCB_COMPL_STAT SetModeCB(msgMESSAGE &msg, void *);

This function handles the access mode to all or specified sub-system

and the maintenance mode.

virtual evhCB_COMPL_STAT SetupCB(msgMESSAGE &msg, void *userData);

Callback to handle SETUP command.

virtual evhCB_COMPL_STAT StandbyCB(msgMESSAGE &msg, void *userData);

Callback to handle STANDBY command.

virtual evhCB_COMPL_STAT StartCB(msgMESSAGE &msg, void *);

Callback to handle START command (see also bossExpoCtrlCmdProc(4))

virtual evhCB_COMPL_STAT StateCB(msgMESSAGE &msg, void *userData);

Returns the current value of the state or sub-state of the local task or

of the specified sub-system.

virtual evhCB_COMPL_STAT StatusCB(msgMESSAGE &msg, void *);

Callback to handle STATUS command.

virtual evhCB_COMPL_STAT TestCB(msgMESSAGE &msg, void *userData);

Callback to handle TEST command.

virtual evhCB_COMPL_STAT WaitCB(msgMESSAGE &msg, void *userData);

Callback to handle WAIT command.

virtual evhCB_COMPL_STAT VersionCB(msgMESSAGE &msg, void *userData);

Callback to handle WAIT command.

virtual ccsCOMPL_STAT ContPreProc (msgMESSAGE &msg, vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT EndPreProc (msgMESSAGE &msg, vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT OffPreProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT OnlinePreProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT PausePreProc (msgMESSAGE &msg, vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT SelftstPreProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT StandbyPreProc (msgMESSAGE &msg, void *userData);

virtual ccsCOMPL_STAT StartPreProc (msgMESSAGE &msg, vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT TestPreProc (msgMESSAGE &msg, void *userData);

Pre-processing functions. Implementation of all methods are dummies to be

overloaded by an bossSERVER subclass.

virtual ccsCOMPL_STAT ExpoCtrlCmdProc(msgMESSAGE &msg, void *);

Handles commands which control execution of exposure i.e. START/END and

PAUSE/CONT commands.

virtual ccsCOMPL_STAT StateCtrlCmdProc(msgMESSAGE &msg, void *);

Handles commands which control state transitions i.e. OFF, STANDBY and

ONLINE commands.

virtual ccsCOMPL_STAT TestCtrlCmdProc(msgMESSAGE &msg, void *);

Handles commands which control test of the instrument functions i.e. TEST

and SELFTST commands.

virtual vltLOGICAL HasDestSubSystem(ixacCMD_PARAM &cmd);

Returns true (ccsTRUE) if a destination sub-system (i.e. '-subSystem'

parameter) is specified.

virtual COMPL_STAT GetDestSubSystem(ixacCMD_PARAM &cmd,

bossINTERFACE **subSystemPtr,

vltLOGICAL &lastDestProc);

Retrieves the name of the destination sub-system ('-subSystem' command

parameter), find it into the sub-system list and if found, suppresses the

field which corresponds to its name from the command parameter.

The 'lastDestProc' is set to true if the destination process is the last

(see above sub-sytem naming scheme).

virtual evhCB_COMPL_STAT ExpoCtrlSyncReplyCB(msgMESSAGE &, void*);

Callback to be executed when replies for the command sent by

ExpoCtrlCmdProc() are received.

virtual evhCB_COMPL_STAT SetupSyncReplyCB(msgMESSAGE &, void*);

Callback to be executed when replies for the command sent by

SetupCB() are received.

virtual evhCB_COMPL_STAT StateCtrlSyncReplyCB(msgMESSAGE &, void*);

Callback to be executed when replies for the command sent by

StateCtrlCmdProc() are received.

virtual evhCB_COMPL_STAT TestSyncReplyCB(msgMESSAGE &, void*);

Callback to be executed when replies for the command sent by

TestCtrlCmdProc() are received.

virtual ccsCOMPL_STAT SetLogLevelCB (oslxKEYWORD &keyword, void *);

virtual ccsCOMPL_STAT SetVerboseLevelCB(oslxKEYWORD &keyword, void *);

virtual ccsCOMPL_STAT SetActionLevelCB (oslxKEYWORD &keyword, void *);

virtual ccsCOMPL_STAT SetTimerLevelCB (oslxKEYWORD &keyword, void *);

Function triggers used to handle keyword events to set logging levels for

the different type of logs (standard, verbose, action and timer).

virtual evhCB_COMPL_STAT ExpoStatusEvtCB(evtEVENT_MSG &msg, void *);

Handles the event messages sent when the database attributes, where the

exposure status are stored, change.

virtual evhCB_COMPL_STAT StateEvtCB(evtEVENT_MSG &msg, void *);

Handles the event messages sent when the database attributes, where the

sub-system states are stored, change.

virtual ccsCOMPL_STAT ExpoStatusEvtPreProc(evtEVENT_MSG &msg,

vltINT32 expoId,

void *userData);

Pre-processing functions for DB events. Implementation of all methods are

dummies to be overloaded by an bossSERVER subclass.

virtual ccsCOMPL_STAT ArchiveImage(vltINT32 expoId);

Send image to the archiver process.

virtual ccsCOMPL_STAT AddSubSystem (bossINTERFACE *subSystemPtr);

Adds the specified sub-system to the list of sub-systems which are under

control of Instrument Server.

virtual bossINTERFACE_LIST *GetSubSystemList();

Gets pointer to the list of 'slave' sub-systems.

virtual ccsCOMPL_STAT GetAndDeleteParameterDetId(msgMESSAGE &msg, char * detId )

declares in the given message 'msg' the parameter 'detId' if ts is exists

and removes it from the message.

virtual void SetOsName(char * osname);

virtual char * GetOsName();

Sets/gets the name of the specific OS application.

virtual AllowSetupWhileExpRunning(vltLOGICAL isAllowed)

Set a flag to allow setup commands while exposure is running.

Best to be placed in the constructor of the overloaded bossSERVER class.

virtual ccsCOMPL_STAT ParseAppOptions(vltINT32 argc, vltINT8 *argv[],

vltINT32 *optind);

Parses the XXXX_OS Observation Software command-line options.

ccsCOMPL_STAT RunFunctionOnDetectors(char * detectors, vltINT32 expoId,void *info,

ccsCOMPL_STAT (* func) (vltINT32,char*,void*,

bossINTERFACE_DCS*,ccsERROR*))

Runs static function 'func' on all the detectors given by the list of 'detectors'.

The parameter 'detectors' must contain the name of the detectors as comma separated list.

Paremeters expoId and info are passed to the function 'func'.

Note: Adding errors to stack (last param in func) is not yet solved, use WarningLog

(instead of errAdd.)

PROTECTED METHODS

virtual void SendReply(msgMESSAGE &msg, vltLOGICAL lastReply = ccsTRUE);

Send reply to the calling process.

PROTECTED DATA MEMBERS

oslxALIAS *aliasPtr;

Pointer to the alias table object

oslxDICTIONARY *dictionaryPtr;

Pointer to the dictionary object

ctooCONFIG *appConfigPtr;

Pointer to the application configuration object

bossINS_MODES *insModesPtr;

Pointer to the instrument modes object

bossEXPOSURE *exposurePtr;

Pointer to the exposure control object

oslxSETUP *setupPtr;

Pointer to the setup object

ibacTIMER_LOGS timerLog;

Pointer to the timer log instance

ixacKEY_DB_MAP keyDbMap;

Pointer to the keyword<->DB map instance

ixacKEYW_HANDLER *keywHandlerPtr;

Pointer to the keyword trigger instance

bossINTERFACE_LIST subSystemList;

List of 'slave' sub-systems which are under control of Instrument Server

PRIVATE DATA MEMBERS

slxFILENAME insConId_;

Instrument ID.

The configuration file is identified by the instrument ID.

The instrument ID is set in the configuration file by the

keyword INS.CON.ID, e.g.: INS.CON.ID "XXXX";

(for more info see document on ctoo, ctooCONFIG)

dbSYMADDRESS dbRef;

Database root point used by the Instrument Server.

const char *version;

Version of the server.

LINE DATABASE

The following database branch is necessary to the instance of bossSERVER:

CLASS bossDB_TASK bossSERVER

BEGIN //

ATTRIBUTE logical maintenance 0 // Maintenance mode (0=OFF, 1=ON)

ATTRIBUTE logical alignedState 1 // State aligned with subsystem states

// (0=FALSE, 1=TRUE)

ATTRIBUTE bossINS_MODES insModes

END //

COMMANDS

Following commands are handled by this class:

ABORT, ADDFITS, COMMENT, CONT, END, EXIT, OFF, ONLINE, PAUSE,

SETUP, STANDBY, START, STATE, STATUS and VERSION.

SEE ALSO

bossExitCB(4), bossAbortCB(4), bossAddFitsCB(4), bossCommentCB(4),

bossContCB(4), bossEndCB(4), bossPauseCB(4), bossStartCB(4),

bossExpoCtrlCmdProc(4), bossExpoCtrlSyncReplyCB(4), bossSetLogLevelCB(4),

bossSetVerboseLevelCB(4), bossSetActionLevelCB(4),

bossSetTimerLevelCB(4), bossSetModeCB(4),

bossSetupCB(4), bossSetupSyncReplyCB(4),

bossSetAlignState(4),

bossIsAlignedState(4), bossStateEvtCB(4), bossStateCB(4), bossOffCB(4),

bossStandbyCB(4), bossOnlineCB(4), bossStateCtrlCmdProc(4),

bossStatusCB(4), bossTestCB(4), bossSelftstCB(4),

bossTestCtrlCmdProc(4), bossTestCtrlSyncReplyCB(4)

### generated by docDeroff ###

14.3 Manpage of bossAbortCB, bossStartCB, bossPauseCB…

bossAbortCB

NAME

bossAbortCB, bossContCB, bossEndCB, bossPauseCB, bossStartCB,

bossContPreProc, bossEndPreProc, bossPausePreProc, bossStartPreProc,

bossExpoCtrlCmdProc, bossExpoCtrlSyncReplyCB, bossExpStart, bossExpEnd,

bossExpoStatusEvtCB, bossNewDataFileEvtCB, bossExpoStatusEvtPreProc,

bossNewDataFileEvtPreProc - functions for handling the exposure control

commands

SYNOPSIS

evhCB_COMPL_STAT AbortCB(msgMESSAGE &msg, void *userData);

evhCB_COMPL_STAT ContCB(msgMESSAGE &msg, void *userData);

evhCB_COMPL_STAT EndCB(msgMESSAGE &msg, void *userData);

evhCB_COMPL_STAT PauseCB(msgMESSAGE &msg, void *userData);

evhCB_COMPL_STAT StartCB(msgMESSAGE &msg, void *userData);

ccsCOMPL_STAT ContPreProc(msgMESSAGE &msg, vltIN32 expoId,

void *userData);

ccsCOMPL_STAT EndPreProc(msgMESSAGE &msg, vltIN32 expoId,

void *userData);

ccsCOMPL_STAT PausePreProc(msgMESSAGE &msg, vltIN32 expoId,

void *userData);

ccsCOMPL_STAT StartPreProc(msgMESSAGE &msg, vltIN32 expoId,

void *userData);

ccsCOMPL_STAT ExpoCtrlCmdProc(msgMESSAGE &msg, vltIN32 expoId,

void *userData);

ccsCOMPL_STAT AbortPostProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

ccsCOMPL_STAT ContPostProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

ccsCOMPL_STAT EndPostProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

ccsCOMPL_STAT PausePostProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

ccsCOMPL_STAT StartPostProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

ccsCOMPL_STAT ExpStart(const char *filename, vltINT32 expoId);

ccsCOMPL_STAT ExpEnd(char* filename, vltINT32 expoId,char* detId);

evhCB_COMPL_STAT ExpoStatusEvtCB(evtEVENT_MSG &msg, void *);

evhCB_COMPL_STAT NewDataFileEvtCB(evtEVENT_MSG &msg, void *);

ccsCOMPL_STAT ExpoStatusEvtPreProc(evtEVENT_MSG &msg,

vltINT32 expoId,

void *userData);

ccsCOMPL_STAT NewDataFileEvtPreProc(evtEVENT_MSG &msg,

vltINT32 expoId,

void *userData);

ccsCOMPL_STAT UpdateObsStatus();

vltUINT32 GetObsStatus();

ccsCOMPL_STAT UpdateSubState(vltUINT32 obsStatus);

DESCRIPTION

These functions handle commands which control execution of exposure i.e.

START/END, PAUSE/CONT and ABORT commands. By default, the command is

forwarded to the DCS sub-systems on the subsystemlist. The subsystemlist

for a given exposure is specified by the mode (see INS.MODE keyword).

When expoId is not specified, as default the latest expoId is applied.

Detector can be spacified by the detId parameter.

The following options are supported:

-expoId <expoId> specify the exposure id.

-detId <detId> name of detector as specified in the configuration

-at <time> specify the time when the exposure must be

started, suspended or resumed (default is now).

This option is not relevant for END and ABORT

commands. The time format is (ISO8601):

[[CC]YY[-]MM[-]DD[T| ]]HH[:]MM[[:]SS[.TTT]]

Note: this parameter is handled by 'DCS' sub-system(s).

Callbacks for handling commands check command execution according

the current state before calling pre-processing method, and then

ExpoCtrlCmdProc() method.

virtual evhCB_COMPL_STAT StartCB(msgMESSAGE &msg, void *userData);

Callback for command START.

virtual evhCB_COMPL_STAT PauseCB(msgMESSAGE &msg, void *userData);

virtual evhCB_COMPL_STAT ContCB(msgMESSAGE &msg, void *userData);

Callbacks for command PAUSE and CONT.

virtual evhCB_COMPL_STAT AbortCB(msgMESSAGE &msg, void *userData);

Callback for handling ABORT command, which aborts the current exposition

immediately. It sends ABORT command to all DCS sub-systems or only to the

specified one and waits replies before forwording reply to the calling

process. During ABORT STOP command is sent to ICS-es.

virtual evhCB_COMPL_STAT EndCB(msgMESSAGE &msg, void *userData);

Safely finish the exposure. Image file is completed as normally.

When sent to a looping CCD, boss replaces the END command with STOP command.

At SOS level the detector can be specified hierachically, e.g:

END -detId XXXX.IRDCS

Reply from wait command arrives immediatly after reply from detector has arrived.

Send a WAIT command after END command to make sure that the exposure is finished

before the next one is started.

END command sent to an 'inactive exposure' - i.e. to an exposure that has been

setup but has not yet been started - would result in cancelling the exposure.

After cancellation the exposure cease to exist. Therefore exposure is no longer valid,

i.e. cannot be started, setup.

virtual ccsCOMPL_STAT ContPreProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT EndPreProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT PausePreProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

Pre-processing functions. Implementation of all methods are dummies to be

overloaded by an bossSERVER subclass.

irtual ccsCOMPL_STAT StartPreProcMain(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

irtual ccsCOMPL_STAT StartPreProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

irtual ccsCOMPL_STAT StartPreProcSpecial(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

These functions are called during the execution of the StartCB. StartPreProcMain

calles function StartPreProc when imagefile is to be saved. When there is no imagefile

is to be saved the function StartPreProcSpecial is called.

The StartPreProc function -as default- takes care of the expstart process

(i.e. sends the EXPSTART function to ICS(-es) and calls the appropriate function of

the TCS/VLTI as well.) When the users are overloading this function they must take

into account its original implementation. See document VLT-MAN-ESO-17240-2265.

The function StartPreProcSpecial() is an empty function to be overloaded by the users

when required.

When there is a special mode when neither ICS nor TCS declared on the subsystemlist

users are suggested to overload the function StartPreProcMain().

virtual ccsCOMPL_STAT ExpoCtrlCmdProc(msgMESSAGE &msg, vltINT32 expoId,

void *userData);

Handles commands which control execution of exposure i.e. START/END and

PAUSE/CONT commands. It consists to check exposure id and to send

command to the OS and DCS sub-systems involved in the control of the

exposure identified by expoId. Them it sends a reply to the calling

process according to the execution command status.

The following functions are used to inform sub-system about status of

exposure and to generate an ASCII file with the FITS header keyword. In

general, the ExpStart() has to be called in the pre-processing function of

the START command, and the ExpStart() by the callback attached the exposure

status DB attribute.

virtual ccsCOMPL_STAT ExpStart(const char *filename, vltINT32 expoId);

Inform sub-system that an exposure is about to start by calling ExpStart()

of the bossINTERFACE class (which has to be overloaded by each subclass)

and prepares FITS header. The FITS header file will be created in

directory $INS_ROOT/$INS_USER/DETDATA by ExpEnd() method. If it already

exists it is previously deleted.

virtual evhCB_COMPL_STAT ExpoStatusEvtCB(evtEVENT_MSG &msg, void *);

Handles the event messages sent when the database attributes, where the

exposure status are stored, change.

virtual evhCB_COMPL_STAT NewDataFileEvtCB(evtEVENT_MSG &msg, void *);

Handles the event messages sent when the database attributes, where the

new data file name are stored, change.

virtual ccsCOMPL_STAT ExpoStatusEvtPreProc(evtEVENT_MSG &msg,

vltINT32 expoId,

void *userData);

virtual ccsCOMPL_STAT NewDataFileEvtPreProc(evtEVENT_MSG &msg,

vltINT32 expoId,

void *userData);

Pre-processing functions for DB events. Implementation of all methods are

dummies to be overloaded by an bossSERVER subclass.

virtual ccsCOMPL_STAT ArchiveImage(vltINT32 expoId)

Send ARCHIVE commad to the archiver process, informing which

data are to be merged. A stand alone OS (that is not controlled by SOS)

automatically archives the image (i.e. inform VOLAC).

In case of SOS always the top level OS merges the data as default.

virtual ccsCOMPL_STAT AddTelescopKwToFitsHdr(bossINTERFACE_DCS * dcsSubSystemPtr)

Support function to add TELESCOPE keyword to the fitsheader of the imagefile

created by the given DCS (i.e. by argument dcsSubSystemPtr) when TCS is ignored.

The TELESCOP keyword is normally added by the TCS subsystem when

it is not ignored. In case the TCS subsystem is ignored or not

available but given on the subsystemlist of a selected mode,

the TELESCOPE keyword still has to be included in the fitsheader.

The value of the TELESCOP kewyord is set according to the configuration

keyword OCS.TEL.ID. This function takes care of this.

RIVATE

ccsCOMPL_STAT AddExpstartFlag(vltINT32 expoId,char * flag);

ccsCOMPL_STAT DeleteExpstartFlag(vltINT32 expoId,char * flag);

void AuxImageDataPrepared(vltINT32 expoId);

hese functions help to control the actions for Short exposure.

SEE ALSO

bossSERVER(4)

### generated by docDeroff ###

14.4 Manpage of bossEXPOSURE class

bossEXPOSURE

NAME

bossEXPOSURE - class for handling an exposure

SYNOPSIS

#include "bossEXPOSURE.h"

bossEXPOSURE newExposure;

PARENT CLASS

eccsERROR_CLASS

DESCRIPTION

The bossEXPOSURE provides methods to handle either single exposure or parallel

exposures. An exposure is identified by a positive integer number (i.e expoId).

The exposures are stored in a table in the database at the following location:

<alias>xxo:exposure.currExposureTbl

where <alias>xxo is the base point of the instrument OS and

xx is the two letter instrument code

An exposure is characterised by the following items:

expoId: identification number

mode: instrument mode associated with the exposure

the instrument mode is set by INS.MODE keyword in the setup.

The instruments mode are declared in the configuration file.

subsystems: subsystems taking part in the exposure

declared by instrument mode (INS.MODE) in the first setup

(in configuration file kw OCS.MODEi.SUSBSYST specifies the subsystems

belonging to the given mode)

inspath: instrument path given by the INS.PATH keyword or as part of the

selected instrument mode

detector: detector subsystem with which the exposure is taken

from the given subsystemlist it is automatically declared

filename: the name of file where the image is saved. Given by the OCS.DETi.IMGNAME

keyword. Note if sequence naming is selected the given filname is extended

by a 4 digit number starting with 0000, e.g. myfile_0000.fits

status: the status of the exposure. e.g. inactiv, integrating, finished, aborted,..

The bossEXPOSURE class is a member class of the bossSERVER class and

initialised in the constructor function of the bossSERVER.

PUBLIC METHODS

bossEXPOSURE(const dbSYMADDRESS dbPoint);

virtual ~bossEXPOSURE();

Constructor & Destructor.

virtual ccsCOMPL_STAT SetExpoType(char *expoType);

virtual char *GetExpoType();

Get/Set exposure type. See DICB for currently supported types.

The given parameter (expoType) is saved into the private variable of the class

and also written into the databasepoint <dbPoint>.expotype

Where dbPoint is the root point for the exposure.

virtual ccsCOMPL_STAT SetExpoCategory(char *expoCategory);

virtual char *GetExpoCategory();

Get/Set exposure category. See DICB for currently supported categories.

virtual ccsCOMPL_STAT SetExpoTechnique(char *expoTechnique);

virtual char *GetExpoTechnique();

Get/Set exposure technique. See DICB for currently supported technique.

virtual ccsCOMPL_STAT GetDetector( const char *dbAttr,char * detector);

Declares the name of the detector associated with the expostatus or newdata

database point 'dbAttr' given as argument.

Memory for detector must be allocated by the user.

virtual ccsCOMPL_STAT GetDetector(vltINT32 expoId,char* detector);

Declares the detector of the given exposure identified by its expoId.

The data is retrieved from the exposure table, threfore it is advised

to check for error. Memory for detector must be allocated by the user.

ccsCOMPL_STAT GetFileName(vltINT32 expoId,char *filename)

virtual ccsCOMPL_STAT GetInsMode(vltINT32 expoId,char * insmode );

virtual ccsCOMPL_STAT GetInsPath(vltINT32 expoId,char* path);

virtual ccsCOMPL_STAT GetExpstartFlag(vltINT32 expoId,char *expstrt);

virtual ccsCOMPL_STAT GetExposureStatus(vltINT32 expoId,char *status );

These function retrieve information about the exposure identified by

its expoId. The data is read from the database table.

Memory for the second argument must be allocated by the user.

ltLOGICAL bossEXPOSURE::IsDefined (int expoId)

ltLOGICAL bossEXPOSURE::IsDefined (char* expoIdString)

Returns true if exposure with given expoid has been already setup

and therefore declared in the exposure table.

ltINT32 bossEXPOSURE::NoExposures()

Returns the number of exposures in the exposure table.

virtual ccsCOMPL_STAT GetLastExpoId(vltINT32 *expoId);

Retrieves the exposure the last expoId

virtual char *GetExpoIdStr(vltINT32 expoId=0);

Return the current exposure ID as a string.

virtual ccsCOMPL_STAT CheckExpoId(vltINT32 expoId);

Returns SUCCESS if the exposure with the given expoId has been defined.

Same as function IsDefined(vltINT32 expoId);

virtual char *ExpoStatus2Str(vltUINT32 expoStatus);

Returns the exposure status given as argument in the format of a string.

virtual vltUINT32 bossEXPOSURE::GetGlobalExpoStatus()

Get the global exposure status as declared by the UpdateObsStatus().

It reads the status from the databasepoint <alias>xxo:exposure.expStatus

PRIVATE METHOD

ALthough the functiona below are public they are intended for private use inside

the boss module. OS-es calling these functions must be very careful not to break

down the internal behavior of boss.

virtual ccsCOMPL_STAT NewExpoId(vltINT32 expoId = 0);

Set new exposure ID. It is the number which characterises the setup which

leads to the exposure. If the specified 'expoId' is null, then the

the exposure ID is set to the last exposure ID increased by 1.

virtual void SetLastExpoId(vltINT32 expoId);

Sets the expoId;

virtual ccsCOMPL_STAT GetIdOfTheLastExposureInTbl(vltINT32 *lastExpoId);

Declarres the laste exposure in the database table.

virtual ctocsCOMPL_STAT bossEXPOSURE::AddExposure (int expoId, char *mode,

char *subsystems, char *inspath,

char *detector, char * filename,

char *state, char *expstrt)

virtual ccsCOMPL_STAT bossEXPOSURE::DeleteExposure (int expoId)

virtual ccsCOMPL_STAT bossEXPOSURE::DeleteExposure (char * expoIdString)

Functions to add/remove exposures to/from the exposure tables.

Exposures are added automatically to the exposure tables during the setup.

Exposures are removed from table when there is a setup fails, except

when setup is sent to a running exposure.

virtual ccsCOMPL_STAT DeclareDetectors(char *subSystems, char * detectors);

Selects the detecto subsystems from among the subSystems.

'subSystems' and 'detectors' are comma separated list of the subsystems.

Memory must be allocated by the user for argument 'detectors'.

irtual ccsCOMPL_STAT CopyLastExposure(vltINT32 expoId);

During the repetition of an exposure, (i.e. when a new setup has no -function

or -file parameter) the last exposure in the table is simply copied over.

No setup is sent to the subsystems. (See bossSetupCB)

csCOMPL_STAT bossEXPOSURE::CancelInactivExposures()

When END command is sent to an exposure that has not yet been

started but has been setup, the exposure will be cancelled, i.e. the status

of it will be set to 'CANCELLED'. (See bossExpoCtrl)

irtual ccsCOMPL_STAT bossEXPOSURE::RefreshTable()

Removes old finished/failed/aborted exposures from the exposure table.

Leaving always the last 10 exposures in the table.

The remaining exposures are moved to the the top of the table.

This function is called after every 20-th exposures.

virtual ccsCOMPL_STAT bossEXPOSURE::CleanTable()

clears the exposure table. This function is called at the startup of OS.

virtual ccsCOMPL_STAT SetObsStatus();

Sets the observation status, i.e. the global status of all exposures. The

observation status is updated by the server automatically (when exposure

status of the detectors change)

virtual ccsCOMPL_STAT UpdateObsStatus();

Update the observation status according to the status of all active

exposures (see EnableExposure() and DisableExposure() methods of DCS

subsystem interfaces).

Observation status is calculated as follows:

inscEXP_INACTIVE when all exposures are still idle

bossEXP_RUNNING when there is at least one exposure that is running

bossEXP_FINISHED when all exposure has been finished

bossEXP_ABORTED when one of the exposure has been aborted (and there

is no other running exposure)

PRIVATE DATA MEMBERS

dbSYMADDRESS dbRef_;

Root database point

eccsDB_TABLE<bossEXPOSURE_TABLE_ENTRY> * exposureTbl;

pointer to the exposure table.

dbSYMADDRESS expoGlobalStatusDbAttr;

Db attr. where exposure status stored.

bossINTERFACE_LIST *subSystemListPtr;

pointer to the list of subsystem interfaces declared by bossSERVER.

vltINT32 lastExpoId_;

vltBYTES256 expoType_;

Exposure type

LINE DATABASE

The information about the exposures are stored under <alias>xxo:exposure.

Here the '.currExposureTbl' contains information about the current and the last

upto 10-20 exposures. In the table the expoId,instrument mode,subsystems,inspath,

detector,filename,exposure status and the expstart flag

(indicating if process is in action) or not.

CLASS BASE_CLASS bossEXPOSURE

BEGIN

ATTRIBUTE BYTES256 expoCatg // Exposure category

ATTRIBUTE BYTES256 expoType // Exposure type

ATTRIBUTE BYTES256 expoTech // Exposure technique

// Exposure status. This attribute can be used by OS to maintain an 'global'

// exposure status according to the status of each invidual exposure.

ATTRIBUTE UINT32 expStatus inscEXP_UNDEFINED

ATTRIBUTE Table currExposureTbl(60,

BYTES64 expoId, // expoid in a format of string 'expo-xx'

BYTES64 mode, // Mode name

BYTES256 subsystems, // List of the subsystems

BYTES64 inspath, // ins Path

BYTES64 detector, // detector of the exposure

BYTES64 filename, // inspath

BYTES64 state, // state of the exposure taken by the given detector

BYTES64 expstrt // flag showing the whether the expstrt has finished

)

### generated by docDeroff ###

14.5 Manpage of bossINSMODE class

bossINS_MODES

NAME

bossINS_MODES - provides tools for handling instrument modes

SYNOPSIS

#include "bossINS_MODES.h"

PARENT CLASS

public fndOBJECT, eccsERROR_CLASS

bossINS_MODES insModes (dbPoint, dictionary, aliasTable);

DESCRIPTION

The bossINS_MODES class contains data members and methods to handle

instrument modes. An instrument mode is defined by a Name and a Setup

parameters. The setup parameter string can include Setup Files and/or

keywords as '-file <file1> [<file2> ...] -function <keyword1> <value1>

[<keyword2> <value2> ...]'.

The class can be used to define instrument mode and to complete keyword list

for the SETUP command when an instrument mode is requested. The name of the

current instrument mode is stored into the database (see DATABASE below).

The method CheckInsMode() can be used to supervise the keywords defining the

current instrument mode.

The Dictionary associated with the object as a reference, is used during

definition to check the consistency of setup parameters associated to the

instrument modes.

An Alias Conversion Table can also be associated with the object as a

reference to an external instance of the oslxALIAS class.

PUBLIC METHODS

**** Constructor/Destructor Methods ****

bossINS_MODES(const dbSYMADDRESS dbPoint,

oslxDICTIONARY *dictionary = NULL,

oslxALIAS *alias = NULL);

The constructor receives as a parameter the symbolic address of the

online database support point for the object, i.e. the point

where the object can find instrument modes definition table.

The constructor method associates optionally a dictionary to the object

and an Alias Conversion Table.

virtual ~bossINS_MODES()

virtual ccsCOMPL_STAT Configure(oslxSHORT_FITS &appConfig,

vltLOGICAL update = ccsTRUE);

Configures the instrument modes according to the application configuration

keywords (see ESO-VLT-DIC.OSB dictionary).

An instrument mode is defined by a NAME, a SETUP ( SHORT-FITS keywords),

a subsystemlist, and instrument path. The keyword 'OCS.MODEi.NAME' defines the

name of the instrument mode. The keyword 'OCS.MODEi.SETUP' defines the

associated setup parameters. Setup parameters are checked according to the dictionary

and the alias conversion table.The keyword OCS.MODEi.SUBSYST declares the list of

subsystems that take place in the given mode. The keyword OCS.MODEi.PATH declares

the path for the instrument. The instrument modes are stored in the

database table.

If <update> is FALSE, the database table is first cleaned, i.e. all

instrument modes are cleared.

virtual ccsCOMPL_STAT SetInsModeKeyword (const slxKEYW_LINE keyword);

Sets SHORT-FITS keyword which define the instrument mode in the SETUP

command.

virtual ccsCOMPL_STAT HandleInsMode (oslxSETUP &setup, char *insModeName);

Adds setup keywords corresponding to the instrument mode possibly

specified in the SETUP command via the SHORT-FITS keyword defined by

SetInsModeKeyword(). If an instrument mode is specified, the setup

keywords are added to the current keyword list of the setup object, and

the database attribute 'insModes' (see below) is udapted accordingly.

The second argument gives back the retrieved insModeName.

virtual ccsCOMPL_STAT CheckInsMode (oslxSETUP &setup);

Check if the new setup will influence the current instrument mode, if yes

the instrument mode status in the database is set to "Undefined".

virtual ccsCOMPL_STAT ResetCurrInsMode();

Resets the current instrument mode, i.e set to "Undefined".

PRIVATE METHODS

virtual ccsCOMPL_STAT AddMode (char *modeName, char *setupParams,

vltLOGICAL update);

Stores the instrument mode in database table. If <update> is TRUE, the

specified instrument mode is updated with new values, or added in the

database table if not previously defined. If <update> is FALSE, this

method checks if the instrument mode is already defined, and if yes the

request is rejected.

virtual ccsCOMPL_STAT CleanTable();

Cleans the database table where the instrument modes are defined.

virtual vltLOGICAL IsDefined(char *modeName);

Returns true (ccsTRUE) if the instrument mode is defined in database.

virtual vltINT32 NoInsModes();

Returns the number of defined instrument modes.

virtual ccsCOMPL_STAT GetSetupParams (char *modeName, char *setupParams);

Retrieves from database table the setup parameters of the selected

instrument mode. The instrument mode name is checked for validity (i.e.

if the mode is defined in the database table). If no valid mode is found,

it returns an error. If the mode is found, it returns the setup string

stored in the database.

virtual ccsCOMPL_STAT GetSubsystems(char *modeName, char *subsystems);

virtual ccsCOMPL_STAT GetInsPath(char *modeName, char *inspath);

virtual ccsCOMPL_STAT NewMode (char *modeName, oslxSETUP &setup);

Adds the setup keywords corresponding to the selected instrument mode.

These setup keywords are added to the current keywords list of the 'setup'

object.

virtual ccsCOMPL_STAT DbWriteInsModeName(char *modeName);

Write the new mode name into the database.

void InsModeSet(vltLOGICAL isset);

vltLOGICAL InsModeSet();

Set or return wether insmode is set already. By default insmodeset is set to FALSE

at startup or when setup has failed or when global state has changed.

PRIVATE DATA MEMBERS

dbSYMADDRESS dbRef;

oslxDICTIONARY *dictionary;

oslxALIAS *alias;

Pointers to the dictionary and alias table

eccsDB_TABLE<bossMODES_TABLE_ENTRY> *insModesTbl;

Instrument modes definition database table.

oslxKEYW_FILTER insModeKeywFilter;

Filter to extract Instrument Mode Keyword from setup keywords.

LINE DATABASE

The following database branch is necessary to the instance of

bossINS_MODES:

CLASS BASE_CLASS bossINS_MODES

BEGIN //

ATTRIBUTE BYTES32 insMode "" // Current instrument mode

ATTRIBUTE Table insModesTbl

(64,

BYTES32 name, // Mode name

BYTES256 setupParams) // Setup paramaters

END //

SEE ALSO

oslxSETUP(3), ixacAPP_CONFIG(4)

### generated by docDeroff ###

14.6 Manpage of bossINTERFACE_DCS

bossINTERFACE_DCS

NAME

bossINTERFACE_DCS - dedicated interface class to DCS sub-system

SYNOPSIS

#include "bossINTERFACE_DCS.h"

bossINTERFACE_DCS myInterface (dbPoint, 1);

PARENT CLASS

bossINTERFACE

DESCRIPTION

The bossINTERFACE_DCS is dedicated interface to DCS. It inherits the basic

comunication (and syncronization) facilities provided by bossINTERFACE, but

enhances it with specific features needed by DCS such as:

PUBLIC METHODS

bossINTERFACE_DCS(const dbSYMADDRESS dbPoint, char * srvId)

Constructor. It set the subsytem category to bossDCS_SUBSYS (see

SetCategory() method). See also bossINTERFACE(4).

virtual ~bossINTERFACE_DCS()

Destructor

sCOMPL_STAT SetDbAddressStatus(char* dbAddressStatus)

ets the database attribute where the exposure status flag is stored.

virtual vltUINT32 GetExpoStatus();

Returns exposure status read from the database (see function

SetDbAddressStatus()

If no database attribute has been set or if an error occurs

during the database reading then inscEXP_UNDEFINED is returned.

virtual ccsCOMPL_STAT SetExpoStatusEvtCB(evhHANDLER *evhHandler,

evhOBJ_CALLBACK &callback);

Sets callback to handle status changes of expousre. The callback is

attached to the status database attribute (See SetDbAddressStatus()

method) of the exposure.

virtual ccsCOMPL_STAT DisableExpoStatusEvt();

Deactivates the sending of event messages on exposure status changes.

virtual ccsCOMPL_STAT EnableExpoStatusEvt();

Enables the sending of event messages, previously disabled.

virtual ccsCOMPL_STAT SetDbAddressFileName(char *dbAttr);

Sets the database attribute where the new data file is stored. This

attributes is updated by DCS to inform about availability of a new data

file.

virtual ccsCOMPL_STAT SetNewDataFileNameEvtCB(evhHANDLER *evhHandler,

evhOBJ_CALLBACK &callback);

Sets callback to handle the new data file change. The callback is

attached to the new data database attribute (See

SetNewDataFileNameDbAttr() method) of the exposure.

irtual ccsCOMPL_STAT DisableNewDataFileNameEvt();

Deactivates the sending of event messages on new data file changes.

virtual ccsCOMPL_STAT EnableNewDataFileNameEvt();

Enables the sending of event messages, previously disabled.

virtual ccsCOMPL_STAT EnableExposure();

virtual ccsCOMPL_STAT DisableExposure();

Enable(Disable) the exposure. This consists to enable(disable) the

exposure and new data file events, and to update the exposure control

state. When an exposure has been enabled, its status is take into account

when observation status is updated (see UpdateObsStatus()).

virtual ccsCOMPL_STAT IsActive();

Return true if the exposure is active (see EnableExposure() and

DisableExposure() methods).

vltLOGICAL ImageFileExits(char *fileName);

Return true if the image file already exits in the directory

$INS_ROOT/$INS_USER/DETDATA, and false otherwise.*

virtual ccsCOMPL_STAT StoreNewDataFileName(const char *fileName);

virtual vltINT32 NoOfNewDataFileName();

virtual char *GetNewDataFileName(vltINT32 fileNo);

Methods to handled list of data file produced during an exposure. This

list is reset by ResetData() method.

ccsCOMPL_STAT bossINTERFACE_DCS::SetNextFileName(vltLOGICAL checkFile)

ccsCOMPL_STAT bossINTERFACE_DCS::ClearFileName()

vltINT32 bossINTERFACE_DCS::GetNamingType()

ccsCOMPL_STAT bossINTERFACE_DCS::SetNamingType(vltINT32 namingType)

ccsCOMPL_STAT bossINTERFACE_DCS::SetReqFileName(char *newFileName)

ccsCOMPL_STAT bossINTERFACE_DCS::SetSeqBaseName(const char *baseName)

ccsCOMPL_STAT bossINTERFACE_DCS::SetSeqIndex(vltUINT32 seqIndex)

vltUINT32 bossINTERFACE_DCS::GetSeqIndex()

ccsCOMPL_STAT bossINTERFACE_DCS::SetNextSeqName()

char * bossINTERFACE_DCS::GetFullFileName()

char * bossINTERFACE_DCS :: GetSimpleFileName(const char* completeName,char* fname)

These functions support the filenaming according to the selected type

("Request-Naming" or "Sequence-Naming") in the SETUP.

If filenaming is not set by the keyword OCS.DETi.NAMING the default setting is

"Sequence-Naming". When "Sequence-Naming" is applied,

the filename is supplemented with 4 digits. When filename with the given basename

does not yet exist the first file will be named as <basename>_0000.fits .

### generated by docDeroff ###

14.7 Manpage of bossINTERFACE_CCD

bossINTERFACE_CCD

NAME

bossINTERFACE_CCD - dedicated interface class to CCD sub-system

SYNOPSIS

#include "bossINTERFACE_CCD.h"

bossINTERFACE_CCD myInterface (dbPoint, 1);

PARENT CLASS

bossINTERFACE

DESCRIPTION

The bossINTERFACE_CCD is dedicated interface for CCD-s. It inherits the basic

comunication (and syncronization) facilities provided by bossINTERFACE, but

enhances it with specific features needed by TCCD and FIERA.

This special feature is to couple the local expoId of the CCD and OS ExpoId.

(as CCD set its own expoId-s). Note that the CCD does not just have a

local expoId (which only created at START ), but also a 'refId' with values:

0 for currentnly running exposure,

-1 for not yet running next exposure

which has to be used in the SETUP commands.

Some commands use expoId while others refId and there are command for which

no expoId or refId can be given. (All these are taken cared of by this interface.)

PUBLIC METHODS

bossINTERFACE_CCD(const dbSYMADDRESS dbPoint, char * srvId)

Constructor. It set the subsytem category to bossCCD_SUBSYS (see

SetCategory() method). See also bossINTERFACE(4).

~bossINTERFACE_CCD()

Destructor

SetupError(msgMESSAGE &msg)

When there is error reply received from the CCD this function has to be called

to clean up the previous settings wwhen necessary.

subsMsgModify (const msgCMD command, msgMESSAGE &msg)

Modify the the expoId of the given message according to the command sent.

(It is called before the the message has been sent)

subsMsgProcess(const msgCMD command)

Action carried out after reply from the subsystem arrived.

(Sets the local expoId of the CCD when START command returns its value.)

ccsCOMPL_STAT SetCcdName(char *ccdname);

char * GetCcdName();

Sets/gets ccdName as declared in the configuration file.

PRIVATE METHODS

deleteExpoId (const msgCMD command, msgMESSAGE &msg)

modifyExpoId (const msgCMD command, msgMESSAGE &msg)

### generated by docDeroff ###

14.8 Manpage of bossArchiver

bossArchiver

NAME

bossArchiver - server process used for merging and sending data to archive

SYNOPSIS

bossArchiver <InsName>

bossArchiver [-n <procName>] [-l level] [-v <level>] [-h]

[-dbAction <dbPoint>] [-dbRoot <dbPoint>]

[-a <level>] [-version] [-noDate] [-noFileLine] [-noExit]

DESCRIPTION

The program creates and initialise a simple instance of the bossARCHIVER class,

which is responsible for merging the partial header files together

with the imagefile. (See bossARCHIVER(4) manual for more details).

The recommended way to start up the so called 'Archiver' process is:

% bossArchiver <InsName>

where <InsName> is the name of the instrument as specified by the

keyword INS.CON.ID in the configuration file. <InsName> always has to be specified.

The name of the process created is: bossArchiver_<pr>o

where <pr> is the two letter instrument id as specified by the keyword

INS.CON.PREFIX in the configuration file.

The other way of starting up the 'Archiver process' is kept for back

compatibility and debug resons. This is described below:

The process name (with wich the process is registered to the message system)

can be specified by the command line option: -n procName

This name will have to be used to send messages to instead of the executable's name.

When the database root point for action log is set (command line option

-dbAction), the archiver process reports its current activities in the specified point.

The following options are supported:

-n <procName> name used to register process to the message system.

-l <level> set standard log level (max 2)

-v <level> set verbose log level (max 5)

-a <level> set action log level

-t <level> set timer log level

-h print this help

-version print the version number of the software

-noDate turn off the display of date in verbose log

messages (written to stdout)

-noFileLine turn off the display of file name and line number

in verbose log messages (written to stdout)

-noExit when applicable, avoid that application exits in

case of a problem when starting it up.

-dbAction <dbPoint>

name of the database root point used for logging

the current action (see ibacLog(3)).

-dbRoot <dbPoint>

The dbroot point of the indtrument OS to wich this

archiver process belong.

SEE ALSO

bossARCHIVER(4), bossControl(1)

### generated by docDeroff ###

Appendix

Appendix 1:Example of configuration file

##*****************************************************************

## xxmcfgINS.cfg

## The keywords for which default values are used are written by italic letters.

## Below only the keywords that are retrieved by OS from this cfg file are listed.

## The keywords that are required for the configuration for ICS or startup tool are not listed.

##*****************************************************************

#general information

INS.CON.ID "XXXX"; # Instrument identifier

INS.ID "XXXX/$Revision: 1.53 $"; # Instrument identifier

INS.CON.PREFIX "xx"; # Name prefix for modules and servers

OCS.CON.RELEASE "2000-06-16"; # Release date "yyyy-mm-dd"

OCS.CON.ORIGIN "TEST"; # Origin

OCS.CON.LOGLEVEL 0; # Log level

OCS.CON.OSDBROOT “<alias>xxo”; # dbroot point of the OS

OCS.DET.NUM 3; #number of detectors

# subsystem 1: IRACE DCS

OCS.DET1.NAME "IRDCS" # name of the IRACE detector

OCS.DET1.TYPE "IRACE"; # type of the detector

OCS.DET1.DICT "IRACE" # dictionary : ESO-VLT-DIC.IRACE

OCS.DET1.ENVNAME "wxxxx" # environment where proc. is running

OCS.DET1.PROCNAME "iracqServer" # name of the IRACE detector process

OCS.DET1.KEYWFILT "DET1.*.*.*.*.*.*" # keywords to be forwarded to subsyst

OCS.DET1.TIMEOUT 6000 # timeout for the process

OCS.DET1.DBROOT "<alias>iracq"; # db Root

#OCS.DET1.DBIFROOT "<alias>xxo:subsystems:irdcs"; # db address of interface (default)

#OCS.DET1.DBSTATE "<alias>iracq:irace.state"; # db address of 'state' (default)

#OCS.DET1.DBNEWDT "<alias>iracq:exposure.newDataFileName"; # db address of 'new data file'(default)

#OCS.DET1.DBEXPSTS "<alias>iracq:exposure.expStatus" ; # db address of 'exposure status' (default)

# subsystem 2: TCCD

OCS.DET2.NAME "TCCD" # name of the TCCD detector

OCS.DET2.TYPE "ACE"; # type of the detector

OCS.DET2.DICT "CCDDCS" # dictionary : ESO-VLT-DIC. CCDDCS

OCS.DET2.ENVNAME "wxxxx" # environment where TCCD proc. is running

OCS.DET2.PROCNAME "ccdconCI_tccd" # name of the TCCD detector process

OCS.DET2.KEYWFILT "DET2.*.*.*.*.*.*,DET.*.*.*.*.*.*" # keywords to be forwarded to subsyst

OCS.DET2.TIMEOUT 6000 # timeout for the process

OCS.DET2.DBROOT "<alias>tccd"; # db address of subsystem

#OCS.DET2.DBIFROOT "<alias>xxo:subsystems:tccd"; # db address of the interface

#OCS.DET2.DBSTATE "<alias>tccd.opState"; # db address of 'state'

#OCS.DET2.DBNEWDT "<alias>tccd:exposures:exposure_1:transfer.fileNameUnComp";

#OCS.DET2.DBEXPSTS "<alias>tccd:exposures:exposure_1.expStatus";

#subsystem 3: FIERA

OCS.DET3.NAME "FIERA" ;

OCS.DET3.TYPE "FIERA";

OCS.DET3.DICT "FCDDCS";

OCS.DET3.ENVNAME "wbos";

OCS.DET3.PROCNAME "fcdconCI_fiera";

OCS.DET3.KEYWFILT "DET3.*.*.*.*.*.*";

OCS.DET3.TIMEOUT 1000;

OCS.DET3.DBROOT "<alias>fiera";

#OCS.DET3.DBIFROOT "<alias>xxo:subsystems:fiera";

#OCS.DET3.DBSTATE "<alias>fiera.opState";

#OCS.DET3.DBNEWDT "<alias>fiera:exposures:exposure_1:transfer.fileNameUnComp";

#OCS.DET3.DBEXPSTS "<alias>fiera:exposures:exposure_1.expStatus";

#OCS.DET3.WIPING F; # start wiping when T

#OCS.DET3.STOP T; # leave it online when F

OCS.INS.NUM 1; #number of ICS subsystems

# subsystem: ICS

OCS.INS.NAME "ICS"; # Name of ICS

OCS.INS.DICT1 "XXXX_ICS"; # dictionary

OCS.INS.ENVNAME "wxxxx" ; # environment

OCS.INS.PROCNAME "xxiControl"; # process name

#OCS.INS1.DBROOT "<alias>XXXX:ICS"; # db root ( default)

#OCS.INS1.DBIFROOT "<alias>xxo:subsystems:ics"; # interface db address (default)

#OCS.INS1.DBSTATE "<alias>XXXX:ICS:PROCESSES:WS:icsControl.state"; # db address of state (default)

OCS.INS.KEYWFILT "INS.*.*.*.*.*.*"; # keyword filter

OCS.INS.TIMEOUT 6000; # timout in seconds

# subsystem: TCS

OCS.TEL.NAME "UT0"; # Telescope name ('UT1','UT2','UT3' or 'UT4')

OCS.TEL.FOCUS "NA"; # Telescope focus

OCS.TEL.DICT "TCS"; # dictionary

OCS.TEL.ENVNAME "wxxtcs"; # environment

OCS.TEL.PROCNAME "tifNA" ; # process name

#OCS.TEL.DBROOT "<alias>TCS"; # db root (default)

#OCS.TEL.DBIFROOT "<alias>xxo:subsystems:tcs"; # interface db root (default)

#OCS.TEL.DBSTATE "<alias>TCS:tcsState.tcsState"; # db address of state (default)

OCS.TEL.KEYWFILT "TEL.*.*.*.*.*.*"; # keyword filter

OCS.TEL.TIMEOUT 180000; # timout in seconds

OCS.TEL.ID "Tel name not set"; # value for TELESCOP kw ('ESO-VLT-Ui')

OCS.OS.NUM 0; #number of OS subsystems

# Instrument modes

# mode 1

OCS.MODE1.NAME "IR_IMAGING"; # name of the instrmode

OCS.MODE1.SETUP "-function INS.MIRR1.NAME IRED INS.DROT.POSANG 90.0"; # setup the mode

OCS.MODE1.SUBSYST "IRDCS UT0 ICS"; # subsystems involved in the given mode

OCS.MODE1.PATH "INFRARED"; # instrument path (EXPSTRT, EXPEND)

OCS.MODE2.NAME "GUIDING"; # name of the instrmode

OCS.MODE2.SETUP "-function INS.DROT.POSANG 10.0 -file ccd.det"; # setup mode

OCS.MODE2.SUBSYST "TCCD ICS UT0"; # subsystems involved in the given mode

OCS.MODE2.PATH "OPT_TCCD"; # instrument path (EXPSTRT, EXPEND)

OCS.MODE3.NAME "IR_SPECTROSCOPY"; # name of the instrmode

OCS.MODE3.SETUP "-function INS.MIRR1.NAME IRED INS.DROT.POSANG 10.0"; # setup of mode

OCS.MODE3.SUBSYST "IRDCS TCCD ICS UT0"; # subsystems involved in the given mode

OCS.MODE3.PATH "INFRARED"; # instrument path (EXPSTRT, EXPEND)

OCS.MODE4.NAME "OPT_IMAGING"; # name of the instrmode

OCS.MODE4.SETUP "-function INS.MIRR1.NAME OPTIC INS.DROT.POSANG 180.0"; # setup of mode

OCS.MODE4.SUBSYST "FIERA ICS UT0"; # subsystems

OCS.MODE4.PATH "OPT_SCCD"; # instrument path

# --- oOo ---

##****************************************************************

## xxmcfgSTART.cfg

## Below only the keywords that are retrieved by OS are listed.

##****************************************************************

OCS.DET1.ACCESS "NORMAL"; # Sub-system access mode.

OCS.DET2.ACCESS "NORMAL"; # Sub-system access mode.

OCS.DET3.ACCESS "NORMAL"; # Sub-system access mode.

OCS.INS1.ACCESS "NORMAL"; # Sub-system access mode.

OCS.TEL.ACCESS "IGNORE"; # Sub-system access mode.

#************************************************************************

# ___oOo___

Appendix 2: Dictionary of BOSS

The dictionary used by BOSS consists of the following keywords:

# configuration kws

OCS.CON.RELEASE

OCS.CON.ORIGIN

OCS.CON.LOGLEVEL

OCS.CON.OSDBROOT

# DCS configuration keywords

# ------------------------------------

OCS.DET.NUM

OCS.DETi.NAME

OCS.DETi.ENVNAME

OCS.DETi.PROCNAME

OCS.DETi.ACCESS

OCS.DETi.DICTi

OCS.DETi.DBROOT # dbroot of the subsystem

OCS.DETi.DBEXPSTS # db adrress of 'exposure status'

OCS.DETi.DBNEWDT # db adrress of 'new data'

OCS.DETi.DBSTATE # db adrress of 'state'

OCS.DETi.DBIFROOT # db root of the subsystem interface

OCS.DETi.MINFREE # space required by the image (optional)

OCS.DETi.KEYWFILT

OCS.DETi.TIMEOUT

OCS.DETi.TYPE

OCS.DETi.WIPE

OCS.DETi.STOP

# ICS configuration keywords

# ------------------------------------

OCS.INS.NUM

OCS.INSi.NAME

OCS.INSi.ENVNAME

OCS.INSi.PROCNAME

OCS.INSi.ACCESS

OCS.INSi.DICTi

OCS.INSi.DBROOT

OCS.INSi.DBSTATE

OCS.INSi.DBIFROOT

OCS.INSi.TIMEOUT

OCS.INSi.KEYWFILT

# TCS configuration keywords

# ------------------------------------

OCS.TEL.NAME

OCS.TEL.ENVNAME

OCS.TEL.PROCNAME

OCS.TEL.ACCESS

OCS.TEL.DICTi

OCS.TEL.DBROOT

OCS.TEL.DBSTATE

OCS.TEL.DBIFROOT

OCS.TEL.TIMEOUT

OCS.TEL.KEYWFILT

# OCS configuration keywords

# ------------------------------------

OCS.OS.NUM

OCS.OSi.NAME

OCS.OSi.ENVNAME

OCS.OSi.PROCNAME

OCS.OSi.TIMEOUT

OCS.OSi.ACCESS

OCS.OSi.DICTi

OCS.OSi.DBROOT

OCS.OSi.DBSTATE

OCS.OSi.DBIFROOT

OCS.OSi.KEYWFILT

# Instrument mode cfg keywords

# ------------------------------------

OCS.MODEi.NAME

OCS.MODEi.SETUP

OCS.MODEi.SUBSYST

OCS.MODEi.PATH

# SETUP keywords

# ------------------------------------

OCS.DETi.IMGNAME # set the image name

OCS.DETi.IMGEXT # image file name extention

OCS.DETi.NAMING # set request or sequential naming

OCS.PATH # set the path (see EXPEND/EXPSTRT cmd)

Appendix 3: CDT of BOSS

The CDT that is part of the package and must be included by the apllication’s CDT consists

of the following keywords.

1: ABORT -expoId <INTEGER> -detId <STRING>

replies: -done <STRING>

2: ADDFITS -expoId <INTEGER> -detId <STRING> -info <STRING>

replies: -done <STRING>

3: COMMENT -expoId <INTEGER> -detId <STRING> -string <STRING>

-clear <LOGICAL>

replies: -done <STRING>

4: CONT -expoId <INTEGER> -detId <STRING> -at <STRING>

replies: -done <STRING>

5: END -expoId <INTEGER> -detId <STRING>

replies: -done <STRING>

6: FORWARD -subSystem <STRING> -command <STRING> -arguments <STRING>

replies: -reply <STRING>

7: OFF -subSystem <STRING>

replies: -done <STRING>

8: ONLINE -subSystem <STRING>

replies: -done <STRING>

9: PAUSE -expoId <INTEGER> -detId <STRING> -at <STRING>

replies: -done <STRING>

10: SETUP -expoId <INTEGER> -file <STRING> -function <STRING>

-noMove <LOGICAL> -check <LOGICAL> -noExposure <LOGICAL>

replies: -expoId <INTEGER>

11: STANDBY -subSystem <STRING>

replies: -done <STRING>

12: START -expoId <INTEGER> -detId <STRING> -at <STRING>

replies: -done <STRING>

13: STATE -subSystem <STRING>

replies: -state <STRING>

14: STATUS -expoId <INTEGER> -function <STRING>

replies: -status <STRING>

16: WAIT -expoId <INTEGER> -detId <STRING> -first <LOGICAL> -cond <STRING> -all

replies: -expStatus <INTEGER>

17: ACCESS -subSystem <STRING> -mode < STRING > -info

replies: <STRING>

-o- -o- -o-

[1] When VLTI is used instead of TCS the module bossvlti must be included among the libs in the Makefile of the OS module. This module consists only an interface for VLTI.

Using this interface boss calls 'iss' functions (during EXPSTRT/EXPEND) in order to create its header file ('*.iss') which will be merged with the imagefile. Similar interface for TCS is included in boss. The reason why the interface for VLTI is placed in a separate module is that VLTI modules may not be available on VLT instruments WS.

[2] The name of this process does not really reflect its responsibility. (Perhaps ‘File Handler Process’ could be a better name. Nevertheless for historic reason the original name remains.)

[3] These files are stored under directory $INS_ROOT/$SYSTEM/DETDATA/.

Caution: Starting up more OS –es has to be sequentially.

Simultaneous start up of the archiver processes might reports error due to the clean up functionality (trying to remove the same files).

[4] Currently each ‘main process’ must have its own ‘archiver process’. (In principle, one Archiver process on each workstation could be satisfactory.)

[5] May be later version of BOSS will be more rigorous restricting the number of virtual functions.

[6] It is possible to declare other names but it is highly recommended to follow the standard naming.

[9] BOSS currently does not make use of this information. Later on an additional check might be added to verify the number of subsystems belonging to the given category.

[10] The database root of the OS can be also suppiled amongst the arguments of the constructor of the SERVER class. However after MAR2002 it is recommended to use the simpler constructor and the OCS.CON.OSDBROOT cfg keyword.

[11] It is strongly recommended to avoid this confusing situation!! ( It is a behavior of the base module OSLX)

[12] Parallel exposures are not supported in APR2003.

[13] Do not use DCS specific keywords to setup the image filename!

(May be later it will be allowed but currently not supported!!)

[15] In later version of BOSS the name of the instrument (e.g. XXXX) might be required as well to declare default dictionary for the instrument.

[16] Currently called as archiver process. In principle you need one Archiver process on each workstation where image is created. In practice you might need to start an Archiver process for each OS in case of superOS.

[17] All the arguments of the bossSERVER class will have default values in later version of boss.

[18] Note : The concepts ‘keydbmap’ and ‘FitsTemplate’is under discussion. The concept ‘keydbmap’ was introduced to couple keywords to dbpoints in order to get the value of the dbpoint easily sending command … to the Control Process. The file ‘FitsTemplate’ was to help including additional fitskeywords into the image file.

[19] Perhaps should be renamed as AppInit() to be consistent with AppConfig()

[20] ‘File handler process’ is also called as ‘archiver process’

[21] This is a deprecated functionality: For test purpose it is possible to switch this state to show the state of the OS itself placing the keyword OCS.CON.STATE.ALIGN in the configuration file or in the setup. When this keyword is found the the function: bossSERVER::SetAlignState() is called. The value of the ‘aligned state’ can be retrieved by function IsAlignedState().

[23] Condition CanSetupNextObs equivalent to parameter –header in the APR2003 release. Parameter –header should no longer be used (kept for back compatibility reasons)

[24] Condition CanStartNextObs used to be the default behavior of the WAIT commands in releases before APR2004.

[25] As the condition ‘ObsEnd’ is the default, the WAIT command replies later then in releases before APR2004, ensuring to report any problem during the whole lifecycle including merging. Where this cause noticeable delay in order to set back the previous behavior the parameter ‘-cond CanStartNextObs’ should be specified. In this case at the end of each OB the command ‘WAIT –all’ must be specified.

[26] In case the archiver process is started up in the ‘old way’ i.e. specifying the database point and process name:

bossArchiver -n bossArchiver_xxo -dbRoot '<alias>xxo'

the file is renamed as ’myfile.arf_' after successful handling.

When the archiver process is started with specifying the instrument name only as :

bossArchiver XXXX

the auxiliary files are removed unless debug is requested, i.e.: bossArchiver XXXX -debug

[27] Currently all exposures are included into one table. Separation of current exposures and previous exposures might be included in later version of BOSS.

[28] Earlier (before MARCH2002) substate values were stored as integer, rather then unari int. For back compatiblity reason the old substate values are also kept and displayed under db point: <alias>xxo:state.substate'.

[30] Problem forseen to place SOS above an other SOS which allows parallel exposure. This case however may never happen.

In principle parallel exposures should be achieved by using semi-parallel exposures.

[31] Please note that although it is possible to set the prefix other then OCSi, it is not recommended. New prefixes must be

approved!

Different prefix can be set by the function SetOsPrefix("YYYY") in the constructor of the OS server when necessary .

[32] Case for instrument FLAMES , when UVES creates the image file.

[33] The name of the temporary files here are only for information. They can be changed, therefore they should be accessed only through boss functions if necessary!

[34] it is under consideration which of these log-levels will be applicable using startup tool stoo.

[35]The dictionary of an instrument must be placed in a separate module [..] .

[36] The name of the cdt must correspond to the name of the process. i.e. when the process is called 'xxoControl', its CDT must be called 'xxoControl.cdt'

[37] In BOSS symbolic constant for commands are declared in bossSTD_COMMANDS_NAMES.h.

VLTSW20030388 - Added overloadable empty functions ApplImageHandleProc()
