CRIRES trending system: HISTORY report
HELP USERS-GUIDE MORE
Last update: 2013-01-13T03:46:14 (UT)
same group: xcorr ThAr N2O DISP RESOL   AVG
close window history: 2007 2008 2009 2010 2011   2012   2013   2014   HEALTH
  ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 4081.270 nm VAL4081.0,4081.4 179 lambda_cent this | last_yr | all AVG center wavelength vs. time, WREF=4092.9
2 QC1DB MEDIAN 30.534 nm VAL30.52,30.57 179 lambda_cent this | last_yr | all RMS of center wavelength vs. time, WREF=4092.9
*Data sources: QC1DB: QC1 database; LOCAL: local text file
Plot 1
data source:crires_wave
(QC1 database)
dataset:lambda_cent
median:4081.270nm
fixed thresholds:4081.0...4081.4nm
N_data plotted:179
[click on plot for closeup]
Plot 2
data source:crires_wave
(QC1 database)
dataset:lambda_cent
median:30.534nm
fixed thresholds:30.52...30.57nm
N_data plotted:179
[click on plot for closeup]
This plot

Wavelength calibration: trending of central wavelength (averages).

This plot uses the average of the central wavelength on the four detectors and the corresponding rms. The values are plotted vs. time. Historical plots show also trending vs. grating temperature (header key INS.TEMP4.VAL). Averages are only available for Garching values. Monitoring is for N2O absorption cell measurements with 4092.9 nm reference wavelength.


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
