GRAVITY trending system: HISTORY report
HELP USERS-GUIDE MORE
Last update: 2019-03-21T12:56:44 (UT)
same group: refpos_1 refpos_2 OPD_fit   Ar_lamp_1 Ar_lamp_2 dispersion
close window history: 2017 2018 2019 2020 2021 2022 2023 2024 2025   HEALTH
  ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 0.0002 none VAL-0.001,0.001 5 beta_corr_min this | last_yr | all minimum difference of fibre dispersion index compared to pipeline reference
2 •QC1DB MEDIAN 0.00044 none VAL-0.001,0.001 5 beta_corr_max this | last_yr | all maximum difference of fibre dispersion index compared to pipeline reference
3 •QC1DB MEDIAN 0.02 none none  5 beta_corr_range this | last_yr | all rangeof fibre dispersion index compared to pipeline reference
4 •QC1DB MEDIAN 1.03e-06 m none  5 gdelay_rms this | last_yr | all RMS of group delay, in metre
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
data source:gravity_dispersion
(QC1 database)
dataset:beta_corr_min•
median:0.0002none
fixed thresholds:-0.001...0.001none
N_data plotted:5
[click plot for closeup]
Plot 2
data source:gravity_dispersion
(QC1 database)
dataset:beta_corr_max•
median:0.00044none
fixed thresholds:-0.001...0.001none
N_data plotted:5
[click plot for closeup]
Plot 3
data source:gravity_dispersion
(QC1 database)
dataset:beta_corr_range•
median:0.02none
thresholds:none
N_data plotted:5
[click plot for closeup]
Plot 4
data source:gravity_dispersion
(QC1 database)
dataset:gdelay_rms•
median:1.03e-06m
thresholds:none
N_data plotted:5
[click plot for closeup]
This plot

Trending plot for fibre dispersion index.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
