SPHERE trending system: FULL report
HELP USERS-GUIDE MORE
Last update: 2021-05-17T04:46:35 (UT)
  | now: 2025-12-19T07:23:40 (UT) muc03 QC pipeline: spher-0.42.0b (installed 2021-03-01)
close window history: 2015 2016 2017 2018 2019 2020 2021   HEALTH FULL
  ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 209.472 unitless none  31 respow1 all (full time range) slit=WL (0.12'') grism resolving power in 2.01533 mu first reddest arc line (the lowest one in the raw frame)
1 •QC1DB none   unitless none  6 respow1 all (full time range) slit=NL (0.09'') grism resolving power in 2.01533 mu
2 •QC1DB MEDIAN 199.166 unitless none  31 respow2 all (full time range) slit=WL (0.12'') grism resolving power in 1.73023 mu second arc line
2 •QC1DB none   unitless none  6 respow2 all (full time range) slit=NL (0.09'') grism resolving power in 1.73023 mu
3 •QC1DB MEDIAN 177.952 unitless none  31 respow3 all (full time range) slit=WL (0.12'') grism resolving power in 1.5451 mu third arc line
3 •QC1DB none   unitless none  6 respow3 all (full time range) slit=NL (0.09'') grism resolving power in 1.5451 mu
4 •QC1DB MEDIAN 149.894 unitless none  31 respow4 all (full time range) slit=WL (0.12'') grism resolving power in 1.3094 mu fourth arc line
4 •QC1DB none   unitless none  6 respow4 all (full time range) slit=NL (0.09'') grism resolving power in 1.3094 mu
5 •QC1DB MEDIAN 128.106 unitless none  31 respow5 all (full time range) slit=WL (0.12'') grism resolving power in 1.12371 mu fifth arc line
5 •QC1DB none   unitless none  6 respow5 all (full time range) slit=NL (0.09'') grism resolving power in 1.12371 mu
6 •QC1DB MEDIAN 111.679 unitless none  31 respow6 all (full time range) slit=WL (0.12'') grism resolving power in 0.98772 mu last (bluest) arc line
6 •QC1DB none   unitless none  6 respow6 all (full time range) slit=NL (0.09'') grism resolving power in 0.98772 mu
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		respow1•
median:209.472unitless
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 2
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		respow2•
median:199.166unitless
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 3
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		respow3•
median:177.952unitless
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 4
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		respow4•
median:149.894unitless
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 5
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		respow5•
median:128.106unitless
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 6
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		respow6•
median:111.679unitless
thresholds:none
N_data plotted:31
[click plot for closeup]
This plot

For plots LSS_WAVE2 (arc line fluxes from the IRDIS LSS grism setup) and IRDIS_LSS_WAVE4 (arc line fluxes for the IRDIS LSS prism setup), the FULL version of box 3 shows the long-term behavior of the L3=1.545 mu lamp. In addition the scaled long-term behaviour of flux of the same lamp as registered in the much more frequently acquired IFS WAVE calibrations is shown, to visualize deviations of the LSS L3=1.545mu flux from the known long-term behavior.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
