SPHERE trending system: FULL report
HELP USERS-GUIDE MORE
Last update: 2021-05-17T04:46:53 (UT)
  | now: 2025-12-19T07:23:48 (UT) muc03 QC pipeline: spher-0.42.0b (installed 2021-03-01)
close window history: 2015 2016 2017 2018 2019 2020 2021   HEALTH FULL
  ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 27116.4 ADU none  31 flux1 all (full time range) slit=WL (0.12'') lamp flux in 2.01533 mu first reddest arc line (the lowest one in the raw frame)
1 •QC1DB none   ADU none  6 flux1 all (full time range) slit=NL (0.09'') lamp flux in 2.01533 mu
2 •QC1DB MEDIAN 45109.4 ADU none  31 flux2 all (full time range) slit=WL (0.12'') lamp flux in 1.73023 mu second arc line
2 •QC1DB none   ADU none  6 flux2 all (full time range) slit=NL (0.09'') lamp flux in 1.73023 mu
3 •QC1DB MEDIAN 57890.9 ADU none  31 flux3 all (full time range) slit=WL (0.12'') lamp flux in 1.5451 mu third arc line
3 •QC1DB none   ADU none  6 flux3 all (full time range) slit=NL (0.09'') lamp flux in 1.5451 mu
3 •QC1DB none   ADU none  901 flux4 all (full time range) 1.545mu lamp flux from IFS WAVE scaled by * 40
4 •QC1DB MEDIAN 15823.7 ADU none  31 flux4 all (full time range) slit=WL (0.12'') lamp flux in 1.3094 mu fourth arc line
4 •QC1DB none   ADU none  6 flux4 all (full time range) slit=NL (0.09'') lamp flux in 1.3094 mu
5 •QC1DB MEDIAN 44078.9 ADU none  31 flux5 all (full time range) slit=WL (0.12'') lamp flux in 1.12371 mu fifth arc line
5 •QC1DB none   ADU none  6 flux5 all (full time range) slit=NL (0.09'') lamp flux in 1.12371 mu
6 •QC1DB MEDIAN 37158 ADU none  31 flux6 all (full time range) slit=WL (0.12'') lamp flux in 0.98772 mu last (bluest) arc line
6 •QC1DB none   ADU none  6 flux6 all (full time range) slit=NL (0.09'') lamp flux in 0.98772 mu
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		flux1•
median:27116.4ADU
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 2
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		flux2•
median:45109.4ADU
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 3
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		flux3•
median:57890.9ADU
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 4
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		flux4•
median:15823.7ADU
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 5
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		flux5•
median:44078.9ADU
thresholds:none
N_data plotted:31
[click plot for closeup]
Plot 6
scores: not implemented
data source:sphere_irdis_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		flux6•
median:37158ADU
thresholds:none
N_data plotted:31
[click plot for closeup]
This plot

For plots LSS_WAVE2 (arc line fluxes from the IRDIS LSS grism setup) and IRDIS_LSS_WAVE4 (arc line fluxes for the IRDIS LSS prism setup), the FULL version of box 3 shows the long-term behavior of the L3=1.545 mu lamp. In addition the scaled long-term behaviour of flux of the same lamp as registered in the much more frequently acquired IFS WAVE calibrations is shown, to visualize deviations of the LSS L3=1.545mu flux from the known long-term behavior.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
