For plots LSS_WAVE2 (arc line fluxes from the IRDIS LSS grism setup) and IRDIS_LSS_WAVE4
(arc line fluxes for the IRDIS LSS prism setup), the FULL version of box 3 shows
the long-term behavior of the L3=1.545 mu lamp. In addition the scaled
long-term behaviour of flux of the same lamp as registered in the much
more frequently acquired IFS WAVE calibrations is shown, to visualize deviations of the
LSS L3=1.545mu flux from the known long-term behavior.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
