SPHERE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2016-10-11T09:11:23 (UT)
  | now: 2025-12-19T07:25:01 (UT) muc03 QC pipeline: spher-0.18.0 (installed 2016-03-17)
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 0.0844815 fractional VAL0.03,0.10 102 qc_rms this | last_yr | all narrow band laser lamp 1 fixed pattern noise
2 •QC1DB MEDIAN 0.100545 fractional VAL0.05,0.12 102 qc_rms this | last_yr | all narrow band laser lamp 2 fixed pattern noise
3 •QC1DB MEDIAN 0.0687475 fractional VAL0.01,0.08 102 qc_rms this | last_yr | all narrow band laser lamp 3 fixed pattern noise
4 •QC1DB MEDIAN 0.0768065 fractional VAL0.02,0.10 102 qc_rms this | last_yr | all broad band halogen lamp fixed pattern noise
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: no current data
data source:sphere_ifs_dflat
(QC1 database)
dataset:qc_rms•
median:0.0844815fractional
fixed thresholds:0.03...0.1fractional
N_data plotted:102
[click on plot for closeup]
Plot 2
scores: no current data
data source:sphere_ifs_dflat
(QC1 database)
dataset:qc_rms•
median:0.100545fractional
fixed thresholds:0.05...0.12fractional
N_data plotted:102
[click on plot for closeup]
Plot 3
scores: no current data
data source:sphere_ifs_dflat
(QC1 database)
dataset:qc_rms•
median:0.0687475fractional
fixed thresholds:0.01...0.08fractional
N_data plotted:102
[click on plot for closeup]
Plot 4
scores: no current data
data source:sphere_ifs_dflat
(QC1 database)
dataset:qc_rms•
median:0.0768065fractional
fixed thresholds:0.02...0.1fractional
N_data plotted:102
[click on plot for closeup]
General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
