Reference Frames
    HOME
QC links:

Standard VISIR reference frames

February 2015: the current content of the VISIR reference frames pages presents data taken with the old detectors (operational until May 2012). These will be replaced once new data are available.

The pre-upgrade daily Health Checks included:

  • a set of 2 dark frames for the imaging and spectroscopic detector; for the spectroscopic detector darks are taken in two instrumental setups: every day
  • a set of 6 flatfield frames for the imaging detector: every day


Standard VISIR DARK Frames

Detector:INS.MODE IMAGING (IMG) SPECTROSCOPIC (SPC) SPECTROSCOPIC (SPC)
Setup INS.FILT1.NAME_INS.PFOV=CLOSE_0.127 INS.RESOL_INS.SLIT1.WID_INS.GRAT1.WLEN=MR_1.0_7.8 INS.RESOL_INS.SLIT1.WID_INS.GRAT1.WLEN=HRS_1.0_8.9
Dark 2nd raw
0.3 Mb 0.3 Mb 0.3 Mb
hdr hdr hdr
Dark product
0.3 Mb 0.3 Mb 0.3 Mb
hdr hdr hdr

Standard VISIR FLATFIELD Frames

Detector:INS.MODE IMAGING (IMG)
Setup INS.FILT1.NAME_INS.PFOV=PAH1_0.127
Flat 2nd raw
0.3 Mb
hdr
Flat product
0.3 Mb
hdr
