ISAAC trending system: HISTORY plot
Last update: 2010-12-30T20:45:42 (UT)
same group: Linearity@10000 Lin_zoom@10000 Linearity@5000 Lin_zoom@5000
close window history: 2008 2009 2010 2011 2012 2013   HEALTH
  ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 oQC1DB MEDIAN 6449.25977 ratio VAL-0.02,0.02 2 qc_detlin_5000 this | last_yr | all SW-arm, DoubleCorr nonlinearity correction fraction at 10000 ADU
2 oQC1DB MEDIAN 0.00876 ratio VAL0.01,0.02 8 qc_detlin_5000 this | last_yr | all LW, UncorrHighBias nonlinearity correction fraction at 10000 ADU
3 oQC1DB MEDIAN 29.1027 ratio none   13 qc_detlin_5000 this | last_yr | all LW, DoubleCorrHighBias nonlinearity correction fraction at 10000 ADU
4 oQC1DB MEDIAN -19832.0 ratio none   7 qc_detlin_5000 this | last_yr | all LW, DoubleCorrLowBias nonlinearity correction fraction at 10000 ADU
*Data sources: QC1DB: QC1 database; LOCAL: local text file
Plot 1
data source:isaac_line
(QC1 database)
parameter | dataset:qc_detlin_5000o
median:6449.25977ratio
fixed thresholds:-0.02...0.02ratio
N_data:2
[click on plot for closeup]
Plot 2
data source:isaac_line
(QC1 database)
parameter | dataset:qc_detlin_5000o
median:0.00876ratio
fixed thresholds:0.01...0.02ratio
N_data:8
[click on plot for closeup]
Plot 3
data source:isaac_line
(QC1 database)
parameter | dataset:qc_detlin_5000o
median:29.1027ratio
thresholds:none
N_data:13
[click on plot for closeup]
Plot 4
data source:isaac_line
(QC1 database)
parameter | dataset:qc_detlin_5000o
median:-19832.0ratio
thresholds:none
N_data:7
[click on plot for closeup]
This plot

This is the trending plot for the ISAAC Linearity calibration frames. The non-linearity polynom is :

counts_corrected = counts_meas + B/A * counts_meas^2 + C/A * counts_meas^3

Dividing by counts_meas, and subtracting 1 and apply the formular for a reference count level of 10 000 ADU we get:

lin_eff (5000 ADU) = ( counts_corr / counts_meas ) - 1 =

B/A * 5000 + C/A * 5000 * 5000 =

These plots describe:
1. SW, DoubleCorr
2. LW, UncorrHighBias
3. LW, DoubleCorrHighBias
4. LW, DoubleCorrLowBias
Find more information about ISAAC Linearity frames here.

Other QC parameters related to detector properties (like read noise, are trended.


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
