KMOS trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-04-16T15:29:05 (UT)
  | now: 2024-04-16T18:16:41 (UT) muc01 QC pipeline: kmos-4.0.3 (installed 2022-03-28)
same group: non-uniformity uniformity maxdev
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
KMOS news:
Report news:
DATE*: [?] 2024-04-09
report | NLT
2024-04-10
report | NLT
2024-04-11
report | NLT
2024-04-12
report | NLT
2024-04-13
no data | NLT
2024-04-14
report | NLT
2024-04-15
report | NLT
r...
Raw CAL displays:
raw raw raw raw no CAL raw files no CAL raw files raw
P...
CAL product quality:
products products products products no CAL products no CAL products products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 0.117 ADU VAL0,0.35 7 spat_max_nonunif this | last_yr | all uniformity, IZ band
2 QC1DB MEDIAN 0.119 ADU VAL0,0.35 8 spat_max_nonunif this | last_yr | all uniformity, YJ band
3 QC1DB MEDIAN 0.12 ADU VAL0,0.35 7 spat_max_nonunif this | last_yr | all uniformity, H band
4 QC1DB MEDIAN 0.148 ADU VAL0,0.35 7 spat_max_nonunif this | last_yr | all uniformity, HK band
5 QC1DB MEDIAN 0.127 ADU VAL0,0.35 7 spat_max_nonunif this | last_yr | all uniformity, K band
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 1|
data source:kmos_skyflat
(QC1 database)
dataset:spat_max_nonunif
median:0.117ADU
fixed thresholds:0...0.35ADU
N_data plotted:7
[click plot for closeup]
Plot 2
scores: 1|
data source:kmos_skyflat
(QC1 database)
dataset:spat_max_nonunif
median:0.119ADU
fixed thresholds:0...0.35ADU
N_data plotted:8
[click plot for closeup]
Plot 3
scores: 1|
data source:kmos_skyflat
(QC1 database)
dataset:spat_max_nonunif
median:0.12ADU
fixed thresholds:0...0.35ADU
N_data plotted:7
[click plot for closeup]
Plot 4
scores: 1|
data source:kmos_skyflat
(QC1 database)
dataset:spat_max_nonunif
median:0.148ADU
fixed thresholds:0...0.35ADU
N_data plotted:7
[click plot for closeup]
Plot 5
scores: 1|
data source:kmos_skyflat
(QC1 database)
dataset:spat_max_nonunif
median:0.127ADU
fixed thresholds:0...0.35ADU
N_data plotted:7
[click plot for closeup]
This plot

Three parameters are trended for sky-flats:
spat_max_nonunif: largest illumination correction rms.
spat_unif: total rms of all illumination correction images
spat_maxdev: mean illumination correction of the most deviating IFU



General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
