MUSE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2022-02-01T13:17:57 (UT)
  | now: 2024-10-14T09:19:07 (UT) muc09 QC pipeline: muse-2.8.5 (installed 2021-06-24)
same group: gain gain_det
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
MUSE news:
Report news: 2022-01-26 Use of detmon recipe decommissioned. PLOT not updated anymore. [qc_muse@eso.org]
DATE*: [?] 2024-10-07
report | NLT
2024-10-08
report | NLT
2024-10-09
report | NLT
2024-10-10
report | NLT
2024-10-11
report | NLT
2024-10-12
report | NLT
2024-10-13
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw
P...
CAL product quality:
products products products products products products products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN   e/ADU VAL1.09,1.32 0 reg1_gain this | last_yr | all avg: GAIN avg in region 1
2 QC1DB MEDIAN   e/ADU VAL1.09,1.32 0 reg2_gain this | last_yr | all avg: GAIN avg in region 2
3 QC1DB MEDIAN   e/ADU VAL1.09,1.32 0 reg3_gain this | last_yr | all avg: GAIN avg in region 3
4 QC1DB MEDIAN   e/ADU VAL1.09,1.32 0 reg4_gain this | last_yr | all avg: GAIN avg in region 4
5 QC1DB MEDIAN   e/ADU VAL0.,0.15 0 reg1_gain this | last_yr | all rms: GAIN rms in region 1
6 QC1DB MEDIAN   e/ADU VAL0.,0.15 0 reg2_gain this | last_yr | all rms: GAIN rms in region 2
7 QC1DB MEDIAN   e/ADU VAL0.,0.15 0 reg3_gain this | last_yr | all rms: GAIN rms in region 3
8 QC1DB MEDIAN   e/ADU VAL0.,0.15 0 reg4_gain this | last_yr | all rms: GAIN rms in region 4
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg1_gain
median:no datae/ADU
fixed thresholds:1.09...1.32e/ADU
N_data plotted:0
[click plot for closeup]
Plot 2
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg2_gain
median:no datae/ADU
fixed thresholds:1.09...1.32e/ADU
N_data plotted:0
[click plot for closeup]
Plot 3
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg3_gain
median:no datae/ADU
fixed thresholds:1.09...1.32e/ADU
N_data plotted:0
[click plot for closeup]
Plot 4
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg4_gain
median:no datae/ADU
fixed thresholds:1.09...1.32e/ADU
N_data plotted:0
[click plot for closeup]
Plot 5
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg1_gain
median:no datae/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:0
[click plot for closeup]
Plot 6
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg2_gain
median:no datae/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:0
[click plot for closeup]
Plot 7
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg3_gain
median:no datae/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:0
[click plot for closeup]
Plot 8
scores: not implemented
data source:muse_detmon
(QC1 database)
dataset:reg4_gain
median:no datae/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:0
[click plot for closeup]
This plot

This is the DETMON_gain health check plot for MUSE. The gain values are calculated by the detmon_opt_lp_mr recipe (using the PTC method) in 4 selected regions in 4 different quadrants of each detector.

    The selected region coordinates are ( llx,lly,urx,ury):
  • region1: 1933,565,1999,2065
  • region2: 2242,565,2308,2065
  • region3: 2242,2164,2308,3664
  • region4: 1933,2164,1999,3664

Data are taken with the instrumental mode (INS.MODE) ENGINEERING and the read out mode (DET.READ.CURNAME) SCI1.0

The plotted values are averaged over all 24 detectors for each region. Also, the rms of the average values are plotted in the bottom panels.

The DETMON calibration data are taken with template TPL.ID=MUSE_cal_linearity


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
