VIMOS trending system: HISTORY report
HELP USERS-GUIDE MORE
Last update: 2015-07-12T03:00:37 (UT)
same group: dark_low dark_high gain fp-noise   detmon_gain
close window history: 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014   2015   2016   2017 2018   HEALTH
  ... ... ... ... ... ... ... ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 1.85 e/ADU VAL1.80,1.9 18 conad_avg this | last_yr | all gain for 225kHz,1port,Low read-out mode
2 QC1DB MEDIAN 1.8 e/ADU VAL1.76,1.86 18 conad_avg this | last_yr | all gain for 225kHz,1port,Low read-out mode
3 QC1DB MEDIAN 1.84 e/ADU VAL1.78,1.88 18 conad_avg this | last_yr | all gain for 225kHz,1port,Low read-out mode
4 QC1DB MEDIAN 1.87 e/ADU VAL1.82,1.92 18 conad_avg this | last_yr | all gain for 225kHz,1port,Low read-out mode
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
data source:vimos_scrflat
(QC1 database)
dataset:conad_avg
median:1.85e/ADU
fixed thresholds:1.8...1.9e/ADU
N_data plotted:18
[click on plot for closeup]
Plot 2
data source:vimos_scrflat
(QC1 database)
dataset:conad_avg
median:1.8e/ADU
fixed thresholds:1.76...1.86e/ADU
N_data plotted:18
[click on plot for closeup]
Plot 3
data source:vimos_scrflat
(QC1 database)
dataset:conad_avg
median:1.84e/ADU
fixed thresholds:1.78...1.88e/ADU
N_data plotted:18
[click on plot for closeup]
Plot 4
data source:vimos_scrflat
(QC1 database)
dataset:conad_avg
median:1.87e/ADU
fixed thresholds:1.82...1.92e/ADU
N_data plotted:18
[click on plot for closeup]
This plot

Trending plot for GAIN (conversion factor from ADU to electrons, e-/ADU).

The gain is determined from imaging lamp flats taken with the R filter and with the 225kHz,1port,Low read-out mode. Please note that in the VIMOS headers this quantity is written as CONAD.

Template ID: img_cal_ScreenFlat. Pipeline recipe: vmimflatscreen.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
