Workflow information system for QC
Last update: 2022-12-02T17:50:30 (UT)
  | now: 2022-12-02T21:59:04 (UT)
same group: raw AB_proc AB_certif prod   packs
General news: NOTE: The Health Check and calChecker services will be moved to qcFlow in the course of 2023 on an instrument by instrument basis. The current pages will then not be updated any longer.
Report news:
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
- dfoMonitor | calChecker
- All WISQ plots are updated once per day. The links 'Data downloads' might offer more recent data than plotted, since the database is fed by other processes than the plot process.
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 2.96 min none  256 exec_time this | last_yr | all execution times of autoDaily; closeup of last 10 days
2 QC1DB MEDIAN 2.72 min none  528 exec_time this | last_yr | all execution times for calChecker
3 oQC1DB MEDIAN 0.216 min none  664 exec_time this | last_yr | all execution times for tellTracker
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
data source:exec_time
(QC1 database)
dataset:exec_time
median:2.96min
thresholds:none
N_data plotted:256
[click plot for closeup]
Plot 2
data source:exec_time
(QC1 database)
dataset:exec_time
median:2.72min
thresholds:none
N_data plotted:528
[click plot for closeup]
Plot 3
data source:exec_time
(QC1 database)
dataset:exec_timeo
median:0.216min
thresholds:none
N_data plotted:664
[click plot for closeup]
This plot

This plot visualizes the execution times for the dfos tools autoDaily, calChecker and tellTracker. Their median values should be monitored to be well below the current execution pattern (autoDaily: one hour, calChecker: half an hour, tellTracker: 15 min).


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
