GRAVITY trending system: HEALTH CHECK report
Last update: 2024-04-25T18:30:00 (UT)
[enable javascript for displaying time difference!]
General news:
NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
GRAVITY news:
Report news:
Plot? Symb? Source Average ? Thresholds ? N_ QC1 Data Remarks
method value unit method value
1
• QC1DB MEDIAN 11.1 pixel VAL 10.80,11.50 22 profile_center_sc1
this |
last_yr |
all
center of 1st flat-field profile, SPLIT polarisation
2
• QC1DB MEDIAN 160 pixel none 22 profile_center_sc13
this |
last_yr |
all
center of 13th flat-field profile, SPLIT polarisation
3
• QC1DB MEDIAN 0.557 pixel VAL 0.53,0.59 22 profile_width_sc1
this |
last_yr |
all
width of 1st flat-field profile, SPLIT polarisation
4
• QC1DB MEDIAN 0.543 pixel none 22 profile_width_sc13
this |
last_yr |
all
width of 13th flat-field profile, SPLIT polarisation
5
• QC1DB MEDIAN 4.13 pixel VAL 3.9,4.4 11 profile_center_sc1
this |
last_yr |
all
center of 1st flat-field profile, COMBINED polarisation
6
• QC1DB MEDIAN 148 pixel none 11 profile_center_sc13
this |
last_yr |
all
center of 13th flat-field profile, COMBINED polarisation
7
• QC1DB MEDIAN 0.559 pixel VAL 0.52,0.6 11 profile_width_sc1
this |
last_yr |
all
width of 1st flat-field profile, COMBINED polarisation
8
• QC1DB MEDIAN 0.55 pixel none 11 profile_width_sc13
this |
last_yr |
all
width of 13th flat-field profile, COMBINED polarisation
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1 scores: 7 |
data source: gravity_p2vm dataset: profile_center_sc1 • median: 11.1 pixel fixed thresholds: 10.8...11.5 pixel N_data plotted: 22 [click plot for closeup]
Plot 2 scores: not implemented
data source: gravity_p2vm dataset: profile_center_sc13 • median: 160 pixel thresholds: none N_data plotted: 22 [click plot for closeup]
Plot 3 scores: 7 |
data source: gravity_p2vm dataset: profile_width_sc1 • median: 0.557 pixel fixed thresholds: 0.53...0.59 pixel N_data plotted: 22 [click plot for closeup]
Plot 4 scores: not implemented
data source: gravity_p2vm dataset: profile_width_sc13 • median: 0.543 pixel thresholds: none N_data plotted: 22 [click plot for closeup]
Plot 5 scores: 2 |
data source: gravity_p2vm dataset: profile_center_sc1 • median: 4.13 pixel fixed thresholds: 3.9...4.4 pixel N_data plotted: 11 [click plot for closeup]
Plot 6 scores: not implemented
data source: gravity_p2vm dataset: profile_center_sc13 • median: 148 pixel thresholds: none N_data plotted: 11 [click plot for closeup]
Plot 7 scores: 2 |
data source: gravity_p2vm dataset: profile_width_sc1 • median: 0.559 pixel fixed thresholds: 0.52...0.6 pixel N_data plotted: 11 [click plot for closeup]
Plot 8 scores: not implemented
data source: gravity_p2vm dataset: profile_width_sc13 • median: 0.55 pixel thresholds: none N_data plotted: 11 [click plot for closeup]
This plot
Cross-dispersion profiles in flat fields: central position and width of the
1st and 13th profile.
General information
Click on any of the plots to see a close-up version .
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked statistical averages are indicated by a solid line, and thresholds by broken lines outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ ↓ you can download the data for each parameter set if the 'Data downloads' link shows up
