SPHERE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2016-06-08T22:41:17 (UT)
  | now: 2025-12-19T07:25:59 (UT) muc03 QC pipeline: spher-0.18.0 (installed 2016-03-17)
same group: DIST_Y_LEFT DIST_J_LEFT DIST_H_LEFT DIST_K_LEFT   DIST_Y_RIGHT DIST_J_RIGHT DIST_H_RIGHT DIST_K_RIGHT
close window history: 2014 2015   2016   HEALTH
  ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 0.00691594 NONE none  27 coeff_x_0_0 this | last_yr | all opt. dist. pol. coeff.
2 •QC1DB MEDIAN -0.00174527 NONE none  27 coeff_x_0_1 this | last_yr | all opt. dist. pol. coeff.
3 •QC1DB MEDIAN -0.0102022 NONE none  27 coeff_x_1_0 this | last_yr | all opt. dist. pol. coeff.
4 •QC1DB MEDIAN 3.42735e-07 NONE none  27 coeff_x_1_1 this | last_yr | all opt. dist. pol. coeff.
5 •QC1DB MEDIAN 0.191223 NONE none  27 coeff_y_0_0 this | last_yr | all opt. dist. pol. coeff.
6 •QC1DB MEDIAN -0.00274688 NONE none  27 coeff_y_0_1 this | last_yr | all opt. dist. pol. coeff.
7 •QC1DB MEDIAN 0.00113543 NONE none  27 coeff_y_1_0 this | last_yr | all opt. dist. pol. coeff.
8 •QC1DB MEDIAN 1.13845e-07 NONE none  27 coeff_y_1_1 this | last_yr | all opt. dist. pol. coeff.
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_x_0_0•
median:0.00691594NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
Plot 2
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_x_0_1•
median:-0.00174527NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
Plot 3
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_x_1_0•
median:-0.0102022NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
Plot 4
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_x_1_1•
median:3.42735e-07NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
Plot 5
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_y_0_0•
median:0.191223NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
Plot 6
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_y_0_1•
median:-0.00274688NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
Plot 7
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_y_1_0•
median:0.00113543NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
Plot 8
scores: not implemented
data source:sphere_irdis_distmap
(QC1 database)
dataset:coeff_y_1_1•
median:1.13845e-07NONE
thresholds:none
N_data plotted:27
[click on plot for closeup]
This plot

This plot show the optiocal distortion coefficient X_1_0 and Y_0_1 as a function of the IFS bench temperature. The polynomial to correct the shifts in x direction is:

Delta X = X_0_0 + X_1_0 * x + X_0_1 * y + X_1_1 * x * y + ...

and for the shifts in y-direction:

Delta Y = Y_0_0 + Y_1_0 * x + Y_0_1 * y + Y_1_1 * x * y + ...

Hence X_1_0 is the first order linear scale (the plate scale) in x-direction and Y_0_1 is the first order scale in y-direction.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
