ddt::DdtProducerConsumerBase Class Reference

#include <ddtProducerConsumerBase.hpp>

Inheritance diagram for ddt::DdtProducerConsumerBase:

Public Types
enum	NotificationType { NEW_DATA , PUB_REG , PUB_UNREG , SHM_DEL }

Public Member Functions
virtual void	Notify (NotificationType type)=0

Protected Attributes
int32_t	min_port
int32_t	max_port
DdtLogger *	logger
const int	MIN_PORT_DEFAULT = 5100
const int	MAX_PORT_DEFAULT = 5500
const int	MIN_RANGE = 3
const int	LINE_LENGTH = 256
	DdtProducerConsumerBase (DdtLogger *ddt_logger)
virtual	~DdtProducerConsumerBase ()
void	Init (DdtLogger *ddt_logger)
void	LoadDefaults ()
void	ReadIni ()
void	PrintConfigValues ()
int32_t	GetFreePort () const

Detailed Description

This class serves as a base class for DdtDataProducer and DdtDataConsumer classes. It provides the ReadIni() and GetFreePort() functions for derived classes.

Member Enumeration Documentation

NotificationType

enum ddt::DdtProducerConsumerBase::NotificationType

There are different types of notifications:

Enumerator
NEW_DATA	New data notification
PUB_REG	Publisher registration
PUB_UNREG	Publisher unregisters
SHM_DEL	Shared memory deleted

Constructor & Destructor Documentation

DdtProducerConsumerBase()

DdtProducerConsumerBase::DdtProducerConsumerBase ( DdtLogger *  ddt_logger )

explicit

Constructor

Parameters

ddt_logger

A DDT logger object (no transfer of ownership).

~DdtProducerConsumerBase()

DdtProducerConsumerBase::~DdtProducerConsumerBase ( )

virtualdefault

Destructor

Member Function Documentation

GetFreePort()

int32_t DdtProducerConsumerBase::GetFreePort ( ) const

protected

Reads /proc/net/tcp and returns a free port from the port range specified in databroker.ini.

Returns

A free port number.

iterate over port range check each iteration if port is in use break and return the port if it is free

Init()

void DdtProducerConsumerBase::Init ( DdtLogger *  ddt_logger )

protected

Initializes member variables.

Parameters

ddt_logger

A DDT logger object (no transfer of ownership).

LoadDefaults()

void DdtProducerConsumerBase::LoadDefaults ( )

protected

Loads default values for configuration parameters.

Notify()

virtual void ddt::DdtProducerConsumerBase::Notify ( NotificationType  type )

pure virtual

Sends a notification to local subscribers.

Parameters

type	The type of the notification.

Implemented in DdtDataProducerConsumerFake, ddt::DdtDataConsumer, and ddt::DdtDataProducer.

PrintConfigValues()

void DdtProducerConsumerBase::PrintConfigValues ( )

protected

Prints the values of configuration parameters.

ReadIni()

void DdtProducerConsumerBase::ReadIni ( )

protected

Reads the databroker configuration file.

Member Data Documentation

LINE_LENGTH

const int ddt::DdtProducerConsumerBase::LINE_LENGTH = 256

protected

Number of characters per line when reading the ports file.

logger

DdtLogger* ddt::DdtProducerConsumerBase::logger

protected

The DDT logger object.

max_port

int32_t ddt::DdtProducerConsumerBase::max_port

protected

Configurable upper boundary of the port range used for notifications.

MAX_PORT_DEFAULT

const int ddt::DdtProducerConsumerBase::MAX_PORT_DEFAULT = 5500

protected

The default upper boundary of the port range used for notifications.

min_port

int32_t ddt::DdtProducerConsumerBase::min_port

protected

Configurable lower boundary of the port range used for notifications.

MIN_PORT_DEFAULT

const int ddt::DdtProducerConsumerBase::MIN_PORT_DEFAULT = 5100

protected

The default lower boundary of the port range used for notifications.

MIN_RANGE

const int ddt::DdtProducerConsumerBase::MIN_RANGE = 3

protected

Minimum number of ports for the specified port range.

---

The documentation for this class was generated from the following files:

• datatransfer/databrokerlib/src/include/ddt/ddtProducerConsumerBase.hpp
• datatransfer/databrokerlib/src/ddtProducerConsumerBase.cpp
