FORS1 trending system: History Plots
Last update: 2009-04-09T06:53:16 (UT)
| now: 2022-05-23T17:33:21 (UT)
same group: dark linearity gain   conad fp_noise
less ... | history ... | plot tutorial ... | contact               [?]
Print: Information and research: News:
- png file - advanced studies: QC1 browser | QC1 plotter

Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB no MEDIAN 0.00416 NONE VAL-0.005,0.015 11 non_linear this | last_yr | all chip 1, high gain
2 QC1DB no MEDIAN -0.00027 NONE VAL-0.01,0.01 11 non_linear this | last_yr | all chip 2, high gain
3 QC1DB no MEDIAN 0.00101 NONE VAL-0.01,0.01 10 non_linear this | last_yr | all chip 1, low gain
4 QC1DB no MEDIAN -0.02448 NONE VAL-0.035,-0.015 9 non_linear this | last_yr | all chip 2, low gain
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: to indicate that OPSLOG data are included
This plot

These plots show the difference at 60000 counts between the flux obtained from 2nd order polynomial fit of flux vs. exposure time and the flux predicted by the linear term only, normalized by the polynomial flux.


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
