These are the trending plots for the SINFONI QC parameters derived from the Spectro-photometric STD stars.

Spectro photometric standard star monitoring has been implemented beginning 2017-03.
The intent is to monitor the efficiency of the instrument.
The list of spectro-photometric STD is the same than XSHOOTER.

Several bins are defined for each Band to calculate the efficiency.
S1_J 1.16604 1.17199
S1_J 1.21302 1.22695
S1_J 1.24 1.24797
S1_J 1.28306 1.29205

S2_H 1.541 1.54801
S2_H 1.541 1.56303
S2_H 1.58604 1.59501
S2_H 1.61704 1.63401
S2_H 1.674 1.686

S4_H+K 1.541 1.548
S4_H+K 1.611 1.642
S4_H+K 1.696 1.708
S4_H+K 2.092 2.099
S4_H+K 2.221 2.242

S3_K 2.09098 2.09808
S3_K 2.13189 2.14806
S3_K 2.15198 2.16105
S3_K 2.22107 2.23798

Other QC parameters are also trended here.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
