SINFONI trending system: HEALTH CHECK report PUPIL

General news:	Click 'scores&comments' to switch to score details, and 'HC plot' to switch back to the graphics.
SINFONI news:	PPRS050265: filter wheel position: DARKs are not valid (dome emission), not scored CCB-0000498/PPRS 049255 0500719: grating wheel failure: jump in K central WL
Report news:

DATE*: [?]

2013-06-12
report | NLT

2013-06-13
report | NLT

2013-06-14
report | NLT

2013-06-15
report | NLT

2013-06-16
report | NLT

2013-06-17
report | NLT

2013-06-18
report | NLT

P...

Product quality:

no products

products

no OPSLOG data

scores&comments |

FULL | history ... | plot tutorial ... | contact [?]

*Date on this monitor changes at 21:00 UT

Print:	Information and research:
- png file	- advanced studies: QC1 browser \| QC1 plotter

Plot
?

Symb
?

Source
*

OPS?
**

Average ?

Thresholds ?

N_
data

QC1
parameter

Data
downloads

Remarks

method

value

unit

method

value

•

QC1DB

MEDIAN

37.4

Pixels

VAL

30,45

qc_pupil_centerx

this | last_yr | all

X-centroid position of the sinfoni pupil (in pixels). The nominal value is at 32.5 pixels.

QC1DB

MEDIAN

31.7

Pixels

VAL

23,38

qc_pupil_centery

this | last_yr | all

Y-centroid position of the sinfoni pupil (in pixels). The nominal value is at 32.5 pixels.

•

QC1DB

MEDIAN

0.5

Pixels

VAL

0,10

qc_pupil0_shiftx

this | last_yr | all

X-offset of the sinfoni pupil with respect to the frame center. The nominal value is at 0.0 pixels.

QC1DB

MEDIAN

0.5

Pixels

VAL

-5,5

qc_pupil0_shifty

this | last_yr | all

Y-offset of the sinfoni pupil with respect to the frame center. The nominal value is at 0.0 pixels.

*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included

Plot 1 scores: 3\|
data source:	sinfoni_pupil (QC1 database)
dataset:	qc_pupil_centerx	•
median:	37.4	Pixels
fixed thresholds:	30...45	Pixels
N_data plotted:	18
[click on plot for closeup]

Plot 2 scores: 3\|
data source:	sinfoni_pupil (QC1 database)
dataset:	qc_pupil_centery	o
median:	31.7	Pixels
fixed thresholds:	23...38	Pixels
N_data plotted:	18
[click on plot for closeup]

Plot 3 scores: 3\|
data source:	sinfoni_pupil (QC1 database)
dataset:	qc_pupil0_shiftx	•
median:	0.5	Pixels
fixed thresholds:	0...10	Pixels
N_data plotted:	18
[click on plot for closeup]

Plot 4 scores: 3\|
data source:	sinfoni_pupil (QC1 database)
dataset:	qc_pupil0_shifty	o
median:	0.5	Pixels
fixed thresholds:	-5...5	Pixels
N_data plotted:	18
[click on plot for closeup]

General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
