Active Phasing Experiment bench

The Active Phasing Experiment (APE) during integration. The APE has been installed on VLT´s 8.2-metre Unit Telescope Melipal (UT3), from December 2008 to April 2009, with the purpose of gaining experience in controlling segmented primary mirrors in preparation for the European Extremely Large Telescope (E-ELT). The central part of the experiment is the active segmented mirror seen in its red protection on the photo. The E-ELT 40-metre-class diameter primary mirror will be composed of about 800 hexagonal segments, 1.4 metres wide and 5 cm thick. The E-ELT will be the largest optical/near-infrared telescope in the world.

Credit:

ESO

Bookmark and Share

About the Image

Id:elt-test-bench
Type:Photographic
Release date:16 June 2010, 15:28
Size:5349 x 3605 px

About the Object

Name:APE
Type:• Unspecified : Technology : Observatory : Instrument
• X - E-ELT
