OMEGACAM trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-04-17T16:01:47 (UT)
  | now: 2024-04-18T01:38:35 (UT) muc06 QC pipeline: omega-1.1.8 (installed 2023-06-22)
same group: dark
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
OMEGACAM news:
Report news:
DATE*: [?] 2024-04-11
report | NLT
2024-04-12
report | NLT
2024-04-13
no data | NLT
2024-04-14
report | NLT
2024-04-15
report | NLT
2024-04-16
report | NLT
2024-04-17
report | NLT
r...
Raw CAL displays:
raw raw no CAL raw files no CAL raw files raw raw raw
P...
CAL product quality:
products products no CAL products no CAL products products products products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 0.336 ADU/pix/hr VAL0.,0.7 13 qc_dark_current this | last_yr | all DARK current averaged over all 32 detectors (ADU/pixel/hour)
2 QC1DB MEDIAN 0.206 ADU/pix/hr none  390 qc_dark_current this | last_yr | all DARK current for each individual detector (ADU/pixel/hour)
3 QC1DB MEDIAN 108 part/cm2/hr VAL100.,120. 13 qc_particle_rate this | last_yr | all particle rate averaged over all 32 detectors (particles/cm2/hour)
4 LOCAL none   none none  403 det_id n/a score per detector:
GREEN = within the thresholds
4 LOCAL none   none none  0 det_id n/a score per detector:
RED = beyond the thresholds
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:omegacam_dark
(QC1 database)
dataset:qc_dark_current
median:0.336ADU/pix/hr
fixed thresholds:0.0...0.7ADU/pix/hr
N_data plotted:13
[click plot for closeup]
Plot 2
scores: not implemented
data source:omegacam_dark
(QC1 database)
dataset:qc_dark_current
median:0.206ADU/pix/hr
thresholds:none
N_data plotted:390
[click plot for closeup]
Plot 3
scores: not implemented
data source:omegacam_dark
(QC1 database)
dataset:qc_particle_rate
median:108part/cm2/hr
fixed thresholds:100.0...120.0part/cm2/hr
N_data plotted:13
[click plot for closeup]
Plot 4
scores: not implemented
data source:local data source
dataset:
(numbers below apply to this dataset)
det_id
average:none
thresholds:none
N_data plotted:403
[click plot for closeup]
This plot

Trending plots for the detector dark current and particle rate.

QC parameters are derived from each of 32 detectors of OmegaCAM dark frames.

DB Name: omegacam_dark
Fits header: QC.DARK.CURRENT / QC.PARTICLE.RATE
QC1 DB: qc_dark_current / qc_particle_rate

Description:
The dark current and particle rate is measured from the pipeline product MEAN_DARK

Setup:
BIN.X / BIN.Y / READ.MODE / READ.SPEED = 1/1/normal/normal

These Health Check plots describe:
Fig. 1 dark_current_AVG: The dark current averaged over all 32 detectors (in ADU/pixel/hour). This plot is sensitive to any changes common to all detectors.
Fig. 2 gain_ALL: The dark current measured for each individual detector (in ADU/pixel/hour). This plot is sensitive changes in individual detectors.
Fig. 3 particle_rate_AVG: The dark frame particle rate averaged over all 32 detectors (in particles/cm^2/hour).
Fig. 4 score_outliers: Scores of the dark current as measured for each of the 32 detectors.
Green = within the defined thresholds.
Red = beyond the defined thresholds.


OmegaCAM detector plane layout (detector_ID locations):
OmegaCAM detector layout


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
