OMEGACAM trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-05-23T16:04:41 (UT)
  | now: 2024-05-24T04:37:10 (UT) muc06 QC pipeline: omega-1.1.8 (installed 2023-06-22)
same group: DOME_level_uSDSS gSDSS rSDSS iSDSS zSDSS BJOHN VJOHN
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
The links to KMOS, UVES, and ESPRESSO have been moved to a new section (qcFlow operational) at the lower part of the navigation bar.
OMEGACAM news:
Report news:
DATE*: [?] 2024-05-17
no data | NLT
2024-05-18
no data | NLT
2024-05-19
no data | NLT
2024-05-20
no data | NLT
2024-05-21
no data | NLT
2024-05-22
no data | NLT
2024-05-23
no data | NLT
r...
Raw CAL displays:
no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files
P...
CAL product quality:
no CAL products no CAL products no CAL products no CAL products no CAL products no CAL products no CAL products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 3.35e+04 ADU VAL10000.,55000. 9 qc_raw_dome_median this | last_yr | all V_JOHN: median level in raw DOME flats averaged over all 32 detectors (ADU)
2 QC1DB MEDIAN 3.39e+04 ADU none  288 qc_raw_dome_median this | last_yr | all V_JOHN: median level in raw DOME flats for each individual detector (ADU)
3 oQC1DB MEDIAN 3.34e+04 ADU VAL1000.,55000. 9 qc_raw_dome_min this | last_yr | all V_JOHN: level of raw DOME flat with the minimum flux averaged over all detectors (ADU)
3 QC1DB MEDIAN 3.35e+04 ADU VAL1000.,55000. 9 qc_raw_dome_max this | last_yr | all V_JOHN: level of raw DOME flat with the maximum flux averaged over all detectors (ADU)
4 LOCAL none   none none  864 det_id n/a score per detector:
GREEN = within the thresholds
4 LOCAL none   none none  0 det_id n/a score per detector:
RED = beyond the thresholds
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: no current data
data source:omegacam_dome
(QC1 database)
dataset:qc_raw_dome_median
median:3.35e+04ADU
fixed thresholds:10000.0...55000.0ADU
N_data plotted:9
[click plot for closeup]
Plot 2
scores: not implemented
data source:omegacam_dome
(QC1 database)
dataset:qc_raw_dome_median
median:3.39e+04ADU
thresholds:none
N_data plotted:288
[click plot for closeup]
Plot 3
scores: multiple dataset, cannot be scored
data source:omegacam_dome
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_raw_dome_mino
median:3.34e+04ADU
fixed thresholds:1000.0...55000.0ADU
N_data plotted:9
[click plot for closeup]
Plot 4
scores: not implemented
data source:local data source
dataset:
(numbers below apply to this dataset)
det_id
average:none
thresholds:none
N_data plotted:864
[click plot for closeup]
General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
