XSHOOTER trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-09-22T23:02:06 (UT)
  | now: 2014-09-23T02:47:53 (UT) muc02 QC pipeline: xshoo-2.4.0 (installed 2014-03-26)
same group: x_time y_time
General news:
XSHOOTER news: XSHHOTER is expected to be back at UT2 at ~ Oct. 16 2014
Report news:
DATE*: [?] 2014-09-16
no data | NLT
2014-09-17
no data | NLT
2014-09-18
no data | NLT
2014-09-19
no data | NLT
2014-09-20
no data | NLT
2014-09-21
no data | NLT
2014-09-22
no data | NLT
P...
Product quality:
no products no products no products no products no products no products no products
  no OPSLOG data

scores&comments | history ... | plot tutorial ... | contact               [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB no MEDIAN 43.1 pixel none  103 x_ul this | last_yr | all x-position of line at 992.3190 nm (upper left)
2 QC1DB no MEDIAN 946 pixel none  103 x_ur this | last_yr | all x-position of line at 2310.0452 nm (upper right)
3 QC1DB no MEDIAN 74.5 pixel none  103 x_ll this | last_yr | all x-position of line at 1013.9750 nm (lower left)
4 QC1DB no MEDIAN 900 pixel none  103 x_lr this | last_yr | all x-position of line at 2445.9363 nm (lower right)
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: not implemented
data source:xshooter_format
(QC1 database)
dataset:x_ul
median:43.1pixel
thresholds:none
N_data plotted:103
[click on plot for closeup]
Plot 2
scores: not implemented
data source:xshooter_format
(QC1 database)
dataset:x_ur
median:946pixel
thresholds:none
N_data plotted:103
[click on plot for closeup]
Plot 3
scores: not implemented
data source:xshooter_format
(QC1 database)
dataset:x_ll
median:74.5pixel
thresholds:none
N_data plotted:103
[click on plot for closeup]
Plot 4
scores: not implemented
data source:xshooter_format
(QC1 database)
dataset:x_lr
median:900pixel
thresholds:none
N_data plotted:103
[click on plot for closeup]
This plot

This plot shows the x-positions of 4 reference lines in the FMTCHK frame (coordinates refer to the PRE format, in which all arms follow the VIS orientation).

In the UVB arm the following arc lines are used:

  • UL: 325.737, the order=23 instance is used
  • LL: 303.350
  • UR: 586.031
  • LR: 550.999, the order=13 instance is used

In the VIS arm the following arc lines are used:

  • UL: 567.383, the order=29 instance is used
  • LL: 561.206, the order=29 instance is used
  • UR: 1033.27
  • LR: 933.476, the order=17 instance is used

General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
