MUSE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2023-03-26T13:18:23 (UT)
  | now: 2023-03-26T15:09:18 (UT) muc09 QC pipeline: muse-2.8.6 (installed 2022-03-30)
same group: gain gain_det
General news: NOTE: The Health Check and calChecker services will be moved to qcFlow in the course of 2023 on an instrument by instrument basis. The current pages will then not be updated any longer.
MUSE news:
Report news:
DATE*: [?] 2023-03-19
report | NLT
2023-03-20
report | NLT
2023-03-21
report | NLT
2023-03-22
report | NLT
2023-03-23
report | NLT
2023-03-24
report | NLT
2023-03-25
report | NLT
r...
Raw CAL displays:
raw no CAL raw files raw raw raw raw raw
P...
CAL product quality:
products no CAL products products products products products products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 1.09 e/ADU VAL1.08,1.10 10 out1_gain this | last_yr | all avg: GAIN avg in quadrant 1
2 QC1DB MEDIAN 1.09 e/ADU VAL1.08,1.10 10 out2_gain this | last_yr | all avg: GAIN avg in quadrant 2
3 QC1DB MEDIAN 1.09 e/ADU VAL1.08,1.10 10 out3_gain this | last_yr | all avg: GAIN avg in quadrant 3
4 QC1DB MEDIAN 1.1 e/ADU VAL1.09,1.11 10 out4_gain this | last_yr | all avg: GAIN avg in quadrant 4
5 QC1DB MEDIAN 0.00564 e/ADU VAL0.,0.15 10 out1_gainerr this | last_yr | all rms: GAIN rms in quadrant 1
6 QC1DB MEDIAN 0.00514 e/ADU VAL0.,0.15 10 out2_gainerr this | last_yr | all rms: GAIN rms in quadrant 2
7 QC1DB MEDIAN 0.00564 e/ADU VAL0.,0.15 10 out3_gainerr this | last_yr | all rms: GAIN rms in quadrant 3
8 QC1DB MEDIAN 0.00592 e/ADU VAL0.,0.15 10 out4_gainerr this | last_yr | all rms: GAIN rms in quadrant 4
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out1_gain
median:1.09e/ADU
fixed thresholds:1.08...1.1e/ADU
N_data plotted:10
[click plot for closeup]
Plot 2
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out2_gain
median:1.09e/ADU
fixed thresholds:1.08...1.1e/ADU
N_data plotted:10
[click plot for closeup]
Plot 3
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out3_gain
median:1.09e/ADU
fixed thresholds:1.08...1.1e/ADU
N_data plotted:10
[click plot for closeup]
Plot 4
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out4_gain
median:1.1e/ADU
fixed thresholds:1.09...1.11e/ADU
N_data plotted:10
[click plot for closeup]
Plot 5
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out1_gainerr
median:0.00564e/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:10
[click plot for closeup]
Plot 6
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out2_gainerr
median:0.00514e/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:10
[click plot for closeup]
Plot 7
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out3_gainerr
median:0.00564e/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:10
[click plot for closeup]
Plot 8
scores: not implemented
data source:muse_lingain
(QC1 database)
dataset:out4_gainerr
median:0.00592e/ADU
fixed thresholds:0.0...0.15e/ADU
N_data plotted:10
[click plot for closeup]
This plot

This is the gain health check plot for MUSE. The gain values are calculated by the muse_lingain recipe in multiple regions in 4 different quadrants of each detector.

Data are taken with the instrumental mode (INS.MODE) ENGINEERING and the read out mode (DET.READ.CURNAME) SCI1.0

The plotted values are averaged over all 24 detectors for each region. Also, the rms of the average values are plotted in the bottom panels.

The LINGAIN calibration data are taken with template TPL.ID=MUSE_cal_linearity


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
