GIRAFFE trending system: HEALTH CHECK report
Last update: 2012-05-26T03:06:53 (UT)
| now: 2012-05-26T08:34:36 (UT)
HELP USERS-GUIDE MORE
same group: SIM-lamp FF-lamp ARC-lamp   NAS-lamp
General news:
GIRAFFE news:
Report news:
DATE*: [?] 2012-05-19
report | NR 		2012-05-20
report | NR 		2012-05-21
report | NR 		2012-05-22
report | NR 		2012-05-23
report | NR 		2012-05-24
report | NR 		2012-05-25
report | NR
P...
Product quality:
products products products products products products products
  no OPSLOG data

scores&comments | history ... | plot tutorial ... | contact                 daily/often; important to check     [?] 		*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 OPS?
**		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB no none   counts/sec VAL300,1700 90 flux this | last_yr | all flux of SIMCAL lamp, Medusa1
2 •QC1DB no none   counts/sec VAL300,1700 89 flux this | last_yr | all as plot 1, Medusa2
3 •QC1DB no none   counts/sec VAL100,700 89 flux this | last_yr | all as plot 1, IFU1 (Y axis: 0...1000)
4 •QC1DB no none   counts/sec VAL100,700 89 flux this | last_yr | all as plot 1, IFU2 (Y axis: 0...1000)
5 •QC1DB no none   counts/sec VAL150,700 89 flux this | last_yr | all as plot 1, Argus (Y axis: 0...1000)
7 •QC1DB no MEAN 1.21958 ratio to Medusa1 20%± 0.24392 84 flux   computed ratio Med2/Med1
(no data available for download)
8 •QC1DB no MEAN 0.57583 same 20%± 0.11517 84 flux   as plot 7, IFU1/Medusa1
9 •QC1DB no MEAN 0.43052 same 20%± 0.0861 83 flux   as plot 7, IFU2/Medusa1
10 •QC1DB no MEAN 0.63848 same 20%± 0.1277 83 flux   as plot 7, Argus/Medusa1
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: to indicate that OPSLOG data are included
Plot 1
scores: 7|
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
average:none
fixed thresholds:300.0...1700.0counts/sec
N_data plotted:90
[click on plot for closeup]
Plot 2
scores: 7|
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
average:none
fixed thresholds:300.0...1700.0counts/sec
N_data plotted:89
[click on plot for closeup]
Plot 3
scores: 7|
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
average:none
fixed thresholds:100.0...700.0counts/sec
N_data plotted:89
[click on plot for closeup]
Plot 4
scores: 7|
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
average:none
fixed thresholds:100.0...700.0counts/sec
N_data plotted:89
[click on plot for closeup]
Plot 5
scores: 7|
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
average:none
fixed thresholds:150.0...700.0counts/sec
N_data plotted:89
[click on plot for closeup]
Plot 7
scores: QC1 parameter computed, cannot be scored
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
mean:1.21958ratio to Medusa1
rel. thresholds: ±20%0.97567...1.4635ratio to Medusa1
N_data plotted:84
[click on plot for closeup]
Plot 8
scores: QC1 parameter computed, cannot be scored
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
mean:0.57583same
rel. thresholds: ±20%0.46067...0.691same
N_data plotted:84
[click on plot for closeup]
Plot 9
scores: QC1 parameter computed, cannot be scored
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
mean:0.43052same
rel. thresholds: ±20%0.34442...0.51663same
N_data plotted:83
[click on plot for closeup]
Plot 10
scores: QC1 parameter computed, cannot be scored
data source:giraffe_simlamp
(QC1 database)
dataset:flux•
mean:0.63848same
rel. thresholds: ±20%0.51078...0.76618same
N_data plotted:83
[click on plot for closeup]
This plot

This is the trending plot monitoring the stability of the GIRAFFE SIMCAL arclamp and the 5 fibre systems. These data are derived from the daily SIMLAMP,TAL health check measurements (5 with the HR grating, H525.8B setting).

Plots 1-5.For each of the five fibre systems, an emission line is selected, its intensity is integrated and divided by the EXPTIME. The resulting flux, in counts/sec, is trended over time.

Plots 7-10. 4 slit systems are ratioed against the Medusa1 system. Since all slits are illuminated by the same lamp, lamp effects cancel out, while effects of the specific fibre system are enhanced.

If a certain trend effect is visible in *all* four slits, it is likely to occur in Medusa1. If it shows up in one fibre system only, it originates in that particular slit.

Find more information here. The SIMLAMP data are also used to evaluate the grating stability.


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
