MIDI trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-10-01T19:34:49 (UT)
  | now: 2014-10-01T21:13:07 (UT) muc05 QC pipeline: midi-2.8.3 (installed 2014-03-19)
same group: OPEN HS SP longtrend_OP longtrend_HS longtrend_SP
General news:
MIDI news:
Report news:
DATE*: [?] 2014-09-24
report | NLT
2014-09-25
report | NLT
2014-09-26
report | NLT
2014-09-27
report | NLT
2014-09-28
report | NLT
2014-09-29
report | NLT
2014-09-30
report | NLT
2014-10-01
report | NLT
P...
Product quality:
products products products products products products products no products
  last OPSLOG data:
2014-09-30*

monitor

scores&comments | history ... | plot tutorial ... | contact                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB yes (3) MEDIAN 190.05 NONE VAL189.9,190.2 58 open_beamA_X this | last_yr | all
2 QC1DB yes (3) MEDIAN 189.17 NONE VAL189,189.3 58 open_beamB_X this | last_yr | all
3 QC1DB yes (3) MEDIAN 79.92 NONE VAL79.4,80 58 open_beamA_Y this | last_yr | all
4 QC1DB yes (3) MEDIAN 166.13 NONE VAL165.6,166.2 58 open_beamB_Y this | last_yr | all
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 7|
data source:midi_refpix
(QC1 database)
dataset:open_beamA_X
median:190.05NONE
fixed thresholds:189.9...190.2NONE
N_data plotted:58
[click on plot for closeup]
Plot 2
scores: 7|
data source:midi_refpix
(QC1 database)
dataset:open_beamB_X
median:189.17NONE
fixed thresholds:189...189.3NONE
N_data plotted:58
[click on plot for closeup]
Plot 3
scores: 7|
data source:midi_refpix
(QC1 database)
dataset:open_beamA_Y
median:79.92NONE
fixed thresholds:79.4...80NONE
N_data plotted:58
[click on plot for closeup]
Plot 4
scores: 7|
data source:midi_refpix
(QC1 database)
dataset:open_beamB_Y
median:166.13NONE
fixed thresholds:165.6...166.2NONE
N_data plotted:58
[click on plot for closeup]
This plot

The reference pixels of MIDI are the two pixels of the detector onto which the centroids of the target images must fall in order to ensure a proper beam overlap. They are measured using the center of a pinhole, in the 3 set-ups OPEN, HIGH_SENS and SCI_PHOT, for telescopes beams A and B feeding MIDI, for the interferometric channnels 1 and 2 of MIDI, and for the photometric channels PA and PB of MIDI (in SCI_PHOT only).


General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
