MIDI trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-08-21T19:36:10 (UT)
  | now: 2014-08-21T20:08:44 (UT) muc05 QC pipeline: midi-2.8.3 (installed 2014-03-19)
same group: OPEN HS SP longtrend_OP longtrend_HS longtrend_SP
General news:
MIDI news:
Report news:
DATE*: [?] 2014-08-14
report | NLT
2014-08-15
report | NLT
2014-08-16
report | NLT
2014-08-17
report | NLT
2014-08-18
report | NLT
2014-08-19
report | NLT
2014-08-20
report | NLT
P...
Product quality:
products products products products products products products
  last OPSLOG data:
2014-08-20*

monitor

scores&comments | history ... | plot tutorial ... | contact                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB yes (3) MEDIAN 189.85 YES VAL188.7,190.3 61 sp_beamA1_X this | last_yr | all BEAM A-ch 1 (Win2)
1 QC1DB yes (3) MEDIAN 189.08 YES VAL188.7,190.3 61 sp_beamA2_X this | last_yr | all BEAM A-ch 2 (Win3)
1 QC1DB yes (3) MEDIAN 190.05 YES VAL188.7,190.3 61 sp_beamB1_X this | last_yr | all BEAM B-ch 1 (Win2)
1 QC1DB yes (3) MEDIAN 189.27 YES VAL188.7,190.3 61 sp_beamB2_X this | last_yr | all BEAM B-ch 2 (Win3)
2 QC1DB yes (3) MEDIAN 79.65 YES VAL78.5,80.5 61 sp_beamA1_Y this | last_yr | all BEAM A-ch 1 (Win2)
2 QC1DB yes (3) MEDIAN 80.41 YES VAL78.5,80.5 61 sp_beamB1_Y this | last_yr | all BEAM B-ch 1 (Win2)
3 QC1DB yes (3) MEDIAN 165.10 YES VAL164,166 61 sp_beamA2_Y this | last_yr | all BEAM A-ch 2 (Win3)
3 QC1DB yes (3) MEDIAN 165.85 YES VAL164,166 61 sp_beamB2_Y this | last_yr | all BEAM B-ch 2 (Win3)
4 QC1DB yes (3) MEDIAN 187.51 YES VAL186.5,189.5 61 sp_beamPA_X this | last_yr | all BEAM A-Photom (Win4)
4 QC1DB yes (3) MEDIAN 188.57 YES VAL186.5,189.5 61 sp_beamPB_X this | last_yr | all BEAM B-Photom (Win1)
5 QC1DB yes (3) MEDIAN 220.31 YES VAL219.5,220.5 61 sp_beamPA_Y this | last_yr | all BEAM A-Photom (Win4)
6 QC1DB yes (3) MEDIAN 29.62 YES VAL29,30 61 sp_beamPB_Y this | last_yr | all BEAM B-Photom (Win1)
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: multiple dataset, cannot be scored
data source:midi_refpix
(QC1 database)
dataset:
(numbers below apply to this dataset)
sp_beamA1_X
median:189.85YES
fixed thresholds:188.7...190.3YES
N_data plotted:61
[click on plot for closeup]
Plot 2
scores: multiple dataset, cannot be scored
data source:midi_refpix
(QC1 database)
dataset:
(numbers below apply to this dataset)
sp_beamA1_Y
median:79.65YES
fixed thresholds:78.5...80.5YES
N_data plotted:61
[click on plot for closeup]
Plot 3
scores: multiple dataset, cannot be scored
data source:midi_refpix
(QC1 database)
dataset:
(numbers below apply to this dataset)
sp_beamA2_Y
median:165.10YES
fixed thresholds:164...166YES
N_data plotted:61
[click on plot for closeup]
Plot 4
scores: multiple dataset, cannot be scored
data source:midi_refpix
(QC1 database)
dataset:
(numbers below apply to this dataset)
sp_beamPA_X
median:187.51YES
fixed thresholds:186.5...189.5YES
N_data plotted:61
[click on plot for closeup]
Plot 5
scores: 7|
data source:midi_refpix
(QC1 database)
dataset:sp_beamPA_Y
median:220.31YES
fixed thresholds:219.5...220.5YES
N_data plotted:61
[click on plot for closeup]
Plot 6
scores: 7|
data source:midi_refpix
(QC1 database)
dataset:sp_beamPB_Y
median:29.62YES
fixed thresholds:29...30YES
N_data plotted:61
[click on plot for closeup]
This plot

The reference pixels of MIDI are the two pixels of the detector onto which the centroids of the target images must fall in order to ensure a proper beam overlap. They are measured using the center of a pinhole, in the 3 set-ups OPEN, HIGH_SENS and SCI_PHOT, for telescopes beams A and B feeding MIDI, for the interferometric channnels 1 and 2 of MIDI, and for the photometric channels PA and PB of MIDI (in SCI_PHOT only).


General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
