NACO trending system: HEALTH CHECK report
Last update: 2012-02-11T02:22:53 (UT)
| now: 2012-02-11T12:39:29 (UT)
HELP USERS-GUIDE MORE
same group: hot/cold_pixels gain FPN
General news:
NACO news:
Report news:
DATE*: [?] 2012-02-04
no data | NR 		2012-02-05
report | NR 		2012-02-06
report | NR 		2012-02-07
no data | NR 		2012-02-08
no data | NR 		2012-02-09
no data | NR 		2012-02-10
report | NR
P...
Product quality:
no products products products no products no products no products products
  no OPSLOG data

scores&comments | history ... | plot tutorial ... | contact               [?] 		*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 OPS?
**		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB no MEAN 10.50421   VAL9.2,11.7 92 gain this | last_yr | all detector gain from lampflats taken with Double_RdRstRd mode and DIT 4s
3 •QC1DB no MEAN 10.47278   VAL9.2,11.7 93 gain this | last_yr | all detector gain from lampflats taken with Double_RdRstRd mode and DIT 15s
2 •QC1DB no MEAN 12.96757   VAL11.2,14.6 3 gain this | last_yr | all detector gain from lampflats taken with FowlerNsamp mode and DIT 4 s
4 •QC1DB no MEAN 11.75757   VAL11.2,14.6 11 gain this | last_yr | all detector gain from lampflats taken with FowlerNsamp mode and DIT 15s
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: to indicate that OPSLOG data are included
Plot 1
scores: 7|
data source:naco_lampflat
(QC1 database)
dataset:gain•
mean:10.50421
fixed thresholds:9.2...11.7
N_data plotted:92
[click on plot for closeup]
Plot 3
scores: 7|
data source:naco_lampflat
(QC1 database)
dataset:gain•
mean:10.47278
fixed thresholds:9.2...11.7
N_data plotted:93
[click on plot for closeup]
Plot 2
scores: 2|
data source:naco_lampflat
(QC1 database)
dataset:gain•
mean:12.96757
fixed thresholds:11.2...14.6
N_data plotted:3
[click on plot for closeup]
Plot 4
scores: 2|
data source:naco_lampflat
(QC1 database)
dataset:gain•
mean:11.75757
fixed thresholds:11.2...14.6
N_data plotted:11
[click on plot for closeup]
This plot

Detector gain, a conversion factor in e-/ADU, estimated from the daily internal lamp flatfields. It is derived by the naco_img_lampflat recipe of the NACO pipeline. The data points are separated according to detector readout mode and detector integration time (DIT) the flats were taken with.

General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
