SINFONI trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-07-24T05:00:18 (UT)
  | now: 2014-07-24T07:10:35 (UT) muc04 QC pipeline: sinfo-2.5.3 (installed 2014-05-22)
same group: DARK_dit=300   dit=10 dit=60 dit=600 dit=900
General news:
SINFONI news:
Report news:
DATE*: [?] 2014-07-17
report | NLT
2014-07-18
report | NLT
2014-07-19
report | NLT
2014-07-20
report | NLT
2014-07-21
report | NLT
2014-07-22
report | NLT
2014-07-23
report | NLT
P...
Product quality:
products products products products products products products
  last OPSLOG data:
2014-07-22*

last files ...
monitor

scores&comments | FULL | history ... | plot tutorial ... | contact               [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB yes (0) MEDIAN 20.3 ADU VAL12.0,32.0 83 qc_darkmed_ave this | last_yr | all median dark level, as computed from the master dark
2 QC1DB yes (0) MEDIAN 0.793 ADU VAL-1.3,5.0 83 qc_darkmed_stdev this | last_yr | all standard deviation of median dark level
3 QC1DB yes (0) MEDIAN 3.65 ADU VAL2.9,4.5 83 qc_ron2 this | last_yr | all rms noise derived by subtracting 2 consecutive raw darks (normalized to DET.DIT = 1 second)
4 QC1DB yes (0) MEDIAN 2.7 ADU VAL0.6,6.5 83 qc_gaf_fpn this | last_yr | all fixed pattern noise as computed by fitting a Gaussian to the master dark histogram
5 QC1DB no MEDIAN 9.75e+03 number VAL2000,20000 83 qc_bpm_nbadpix this | last_yr | all number of pixels with a high dark current
6 QC1DB no MEDIAN 0.00144 unitless VAL-0.2,0.3 83 qc_oes1 this | last_yr | all raw file 1:median ratio of odd-even column stripes in the area of slitlet THIS IS NOT scored
7 QC1DB no MEDIAN -0.0163 unitless VAL-0.3,0.3 83 qc_oes2 this | last_yr | all raw file 2:median ratio of odd-even column stripes in the area of slitlet THIS IS NOT scored
8 QC1DB no MEDIAN -0.00605 unitless VAL-0.2,0.3 83 qc_oes3 this | last_yr | all raw file 3:median ratio of odd-even column stripes in the area of slitlet THIS IS NOT scored
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 7|
data source:sinfoni_dark
(QC1 database)
dataset:qc_darkmed_ave
median:20.3ADU
fixed thresholds:12.0...32.0ADU
N_data plotted:83
[click on plot for closeup]
Plot 2
scores: 7|
data source:sinfoni_dark
(QC1 database)
dataset:qc_darkmed_stdev
median:0.793ADU
fixed thresholds:-1.3...5.0ADU
N_data plotted:83
[click on plot for closeup]
Plot 3
scores: 7|
data source:sinfoni_dark
(QC1 database)
dataset:qc_ron2
median:3.65ADU
fixed thresholds:2.9...4.5ADU
N_data plotted:83
[click on plot for closeup]
Plot 4
scores: 7|
data source:sinfoni_dark
(QC1 database)
dataset:qc_gaf_fpn
median:2.7ADU
fixed thresholds:0.6...6.5ADU
N_data plotted:83
[click on plot for closeup]
Plot 5
scores: 7|
data source:sinfoni_dark
(QC1 database)
dataset:qc_bpm_nbadpix
median:9.75e+03number
fixed thresholds:2000...20000number
N_data plotted:83
[click on plot for closeup]
Plot 6
scores: not implemented
data source:sinfoni_dark
(QC1 database)
dataset:qc_oes1
median:0.00144unitless
fixed thresholds:-0.2...0.3unitless
N_data plotted:83
[click on plot for closeup]
Plot 7
scores: not implemented
data source:sinfoni_dark
(QC1 database)
dataset:qc_oes2
median:-0.0163unitless
fixed thresholds:-0.3...0.3unitless
N_data plotted:83
[click on plot for closeup]
Plot 8
scores: not implemented
data source:sinfoni_dark
(QC1 database)
dataset:qc_oes3
median:-0.00605unitless
fixed thresholds:-0.2...0.3unitless
N_data plotted:83
[click on plot for closeup]
This plot

These are the trending plots for the SINFONI QC parameters derived from DARK frames.

These plots describe:

1. the median DARK level, as computed from each master dark frame.

2. the standard deviation of the median DARK level.

3. the root-mean-squared noise, as derived by subtracting two consecutive raw dark frames, computing a median standard deviation in
selected sub-windows, computing a median standard deviation in selected sub-windows in the difference image, and then normalizing to DET.DIT=1 second.

4. the fixed pattern noise, as computed by fitting a Gaussian to the histogram of the master dark frames. The fpn is simply the standard deviation of Gaussian.

5. the number of pixels with a high dark current.

6/7/8. the odd-even column stripes in the area of slitlet #25. If med(odd) = median of all odd columns in the area of slitlet #25
and med(even) = median of all even columns in the area of slitlet #25 then, this plot is defined as:
oes25 = 2 * (med(odd) - med(even)) / (med(odd) + med(even))
the plots show the effect for the first 3 raw files of the DARK

Find more information about SINFONI DARK frames here.

Other QC parameters related to detector properties (like dark level, linearity, gain, etc.) are also trended here.


General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
