| This documentation is intended both for QC scientists and SciOps astronomers (who may want to ignore the technical information displayed in grey). | |||||||||||||||||||||||
|
|||||||||||||||||||||||
| bottom plots | contact | |||||||||||||||||||||||
| NAME | dark_qc_2CCD.prg | ||||||||||||||||||||||
| VERSION |
1.0 -- basic functions 1.1 -- FORS2 adaptation (fpatat, 10/05/2000) 1.2 -- raw analysis removed. 4port conad added 1.3 -- Paola Sartoretti : adapt to FORS2 - MIT CCD, and added error (RON) 1.4 -- smoehler : adapt to FORS1 with 2 CCDs (2007-04-02) | ||||||||||||||||||||||
| SYNTAX | MIDAS | ||||||||||||||||||||||
| CALL |
measureQuality from $DFS_PRODUCT/DARK/$DATE: inmidas -P -j "@@ $DFO_PROC_DIR/dark_qc_2CCD.prg $date $PF" | ||||||||||||||||||||||
| INSTRUMENT | FORS1 | ||||||||||||||||||||||
| RAWTYPE | DARK | ||||||||||||||||||||||
| PURPOSE | checks product DARK file for FORS1 QC assessment; the plots are later reviewed within certifyProducts. The first plot (dark_grap1.png) is stored as Postscript file in $DFO_PLT_DIR. | ||||||||||||||||||||||
| PROCINPUT |
MASTER_DARK product; | ||||||||||||||||||||||
| QC1TABLE |
trending | table(s) in QC1 database: fors1_dark | ||||||||||||||||||||||
| TRENDPLOT |
trending | HealthCheck plot(s) associated to this procedure: trend_report_DARK_HC.html | ||||||||||||||||||||||
| QC1PAGE |
trending | associated documentation: dark_qc1.html | ||||||||||||||||||||||
| QC1PLOTS top |
dark_grap1.png left: averaged central rows and columns of all quadrants of master dark in e-/hr/pix (median filtered with window size of 7 pixels) clockwise from top left: Y200...300, X450...550, X1450...1550, Y700...800 right: histogram: all pixel values of master dark in log frequency histogram; should show dominant peak with Gaussian shape (which translates to parabola shape in this log freq diagram) top panel: date; name of analyzed master dark frame (left, red); number of frames, exposure time, conversion factor (right, black) bottom panel: some QC1 parameters- median_master and sigma_master in e-/px/hr dark_disp1.png full display of master frame | ||||||||||||||||||||||
| QC1PARAM |
QC1 parameters written into QC1 table: QC1db names: datancom | dark_avg | sigma_dark_avg | dark_A(BCD) | sigma_dark_A(BCD) | median_master | sigma_master FITS key names: DATANCOM | (dark_qc.prg) | (dark_qc.prg) | (dummy) | (dummy) | (dark_qc.prg) | (dark_qc.prg) QC1 params created by pipeline: datancom, median_master, sigma_master QC1 params created by this procedure: all except datancom, median_master, sigma_master | ||||||||||||||||||||||
| ALGORITHM |
Description of algorithms: dark_avg: median level of master dark averaged over X200...1800, Y400...800 in e-/hr/pix, excluding values outside +-50 sigma_dark_avg: RON/exp.time*3600 in e-/hr/pix median_master: statistics (median) of full master frame sigma_master: statistics (std_dev) of full master frame | ||||||||||||||||||||||
| CERTIF |
Reasons for rejection: - unusual structure; - non-Gaussian shape of histogram; - DATANCOM lower than usual (3), especially if N=3 version nearby in time | ||||||||||||||||||||||
| COMMENTS | QC1 DB columns dark_A(BCD) and sigma_dark_A(BCD) contains always "none". | ||||||||||||||||||||||
