SPHERE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-04-22T04:48:55 (UT)
  | now: 2024-04-22T12:23:55 (UT) muc03 QC pipeline: spher-0.52.0 (installed 2024-03-22)
same group: SPOS_YJ SPOS_YJH
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
SPHERE news: Note that the current Health Check monitor runs with an incomplete pipeline and an incomplete set of QC1 parameters. QCG can currently not guarantee completeness and significance at the usual level.
Report news:
DATE*: [?] 2024-04-15
no data | NLT
2024-04-16
report | NLT
2024-04-17
report | NLT
2024-04-18
report | NLT
2024-04-19
report | NLT
2024-04-20
report | NLT
2024-04-21
report | NLT
r...
Raw CAL displays:
no CAL raw files raw raw raw raw raw raw
P...
CAL product quality:
no CAL products products products products products products products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 20234.5 number VAL19000,21000 34 qc_number_spectra this | last_yr | all number of spectra
2 QC1DB MEDIAN 0.99964 fractional VAL0.995,1.005 34 qc_scale_measured this | last_yr | all scale
3 QC1DB none   pixel none  34 qc_offset_x this | last_yr | all x-offset in pixel as function of optical bench temperature
3 QC1DB none   pixel none  34 qc_offset_y this | last_yr | all y-offset in pixel as function of optical bench temperature
4 QC1DB FIXED 6.5 pixel VAL5.0,8.0 34 qc_offset_x this | last_yr | all x-offset in pixel
5 QC1DB FIXED -2 pixel VAL-3.5,-0.5 34 qc_offset_y this | last_yr | all y-offset in pixel
6 QC1DB none   pixel none  34 qc_offset_y this | last_yr | all xy-offset in pixel
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 1|
data source:sphere_ifs_specpos
(QC1 database)
dataset:qc_number_spectra
median:20234.5number
fixed thresholds:19000...21000number
N_data plotted:34
[click plot for closeup]
Plot 2
scores: 1|
data source:sphere_ifs_specpos
(QC1 database)
dataset:qc_scale_measured
median:0.99964fractional
fixed thresholds:0.995...1.005fractional
N_data plotted:34
[click plot for closeup]
Plot 3
scores: not implemented
data source:sphere_ifs_specpos
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_offset_x
average:none
thresholds:none
N_data plotted:34
[click plot for closeup]
Plot 4
scores: 1|
data source:sphere_ifs_specpos
(QC1 database)
dataset:qc_offset_x
fixed average:6.5pixel
fixed thresholds:5.0...8.0pixel
N_data plotted:34
[click plot for closeup]
Plot 5
scores: 1|
data source:sphere_ifs_specpos
(QC1 database)
dataset:qc_offset_y
fixed average:-2pixel
fixed thresholds:-3.5...-0.5pixel
N_data plotted:34
[click plot for closeup]
Plot 6
scores: not implemented
data source:sphere_ifs_specpos
(QC1 database)
dataset:qc_offset_y
average:none
thresholds:none
N_data plotted:34
[click plot for closeup]
This plot

This plots shows:

  • (1) The number of found slitlet spectra
  • (2) correcting scale to fit the lenslet model and the SPOS calibration slitlet center point pattern.
  • (4,5) The pixel offset between the SPHERE IFS spectra positions of the raw input frame and the lenselet model.
  • (6) The pixel offsets in the XY-plane
  • (3) The pixel offsets as a function of the optical bench temperature. The solid lines are empirical non-linear relations. The dashed line is the empirical relation before the earth quake in 2015-11 and shows the shift by 0.6 pixel introduced by this event.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
