SPHERE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2023-12-05T11:07:26 (UT)
  | now: 2023-12-05T21:24:37 (UT) muc03 QC pipeline: spher-0.50.0 (installed 2023-11-13)
same group: CI_HIGH_FLAT CI_RMS   CI_FPN CI_NBP
General news: NOTE: The Health Check and calChecker services will be moved to qcFlow in the course of 2023 on an instrument by instrument basis. The current pages will then not be updated any longer.
SPHERE news: Note that the current Health Check monitor runs with an incomplete pipeline and an incomplete set of QC1 parameters. QCG can currently not guarantee completeness and significance at the usual level.
Report news:
DATE*: [?] 2023-11-28
report | NLT
2023-11-29
report | NLT
2023-11-30
report | NLT
2023-12-01
report | NLT
2023-12-02
report | NLT
2023-12-03
report | NLT
2023-12-04
report | NLT
2023-12-05
no data | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw no CAL raw files
P...
CAL product quality:
products products products products products products products no CAL products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 14208.8 ADU VAL1000,25000 14 qc_adu_left_4 this | last_yr | all Y-band left beam
2 QC1DB MEDIAN 16434.8 ADU VAL1000,25000 14 qc_adu_left_4 this | last_yr | all J-band left beam
3 QC1DB MEDIAN 17693.8 ADU VAL1000,25000 47 qc_adu_left_4 this | last_yr | all H-band left beam
4 QC1DB MEDIAN 8907.51 ADU VAL1000,25000 14 qc_adu_left_4 this | last_yr | all K-band left beam
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 2|
data source:sphere_irdis_flat
(QC1 database)
dataset:qc_adu_left_4
median:14208.8ADU
fixed thresholds:1000...25000ADU
N_data plotted:14
[click plot for closeup]
Plot 2
scores: 2|
data source:sphere_irdis_flat
(QC1 database)
dataset:qc_adu_left_4
median:16434.8ADU
fixed thresholds:1000...25000ADU
N_data plotted:14
[click plot for closeup]
Plot 3
scores: 5|
data source:sphere_irdis_flat
(QC1 database)
dataset:qc_adu_left_4
median:17693.8ADU
fixed thresholds:1000...25000ADU
N_data plotted:47
[click plot for closeup]
Plot 4
scores: 2|
data source:sphere_irdis_flat
(QC1 database)
dataset:qc_adu_left_4
median:8907.51ADU
fixed thresholds:1000...25000ADU
N_data plotted:14
[click plot for closeup]
This plot

This plot shows the median counts in the brightest of five raw input flats. The QC parameter is monitored for the left beam and for the four broad band filters in the common filter wheel: B_Y, B_H, B_J and B_K, separately. The dual beam filter wheel is 'CLEAR' in classical imaging mode.

The bi-variate distribution in the B_Ks filter values originate from different templates.

New 2018-10-16: The plot shows the counts in one plane of the raw frame cube corresponding to NDIT=1. For NDIT=40, the total counts in the brightest raw flat is 40 times the counts of one plane of the raw frame cube. To achieve a S/N-ratio = 200 in the brightest raw flat, about 1000 ADU (new threshold) must be achieved in a single plane. The S/N ratio in the final master flat is not checked for.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
