SPHERE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-04-22T13:08:06 (UT)
  | now: 2024-04-22T14:06:52 (UT) muc03 QC pipeline: spher-0.52.0 (installed 2024-03-22)
same group: bias ron
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
SPHERE news: Note that the current Health Check monitor runs with an incomplete pipeline and an incomplete set of QC1 parameters. QCG can currently not guarantee completeness and significance at the usual level.
Report news:
DATE*: [?] 2024-04-15
no data | NLT
2024-04-16
report | NLT
2024-04-17
report | NLT
2024-04-18
report | NLT
2024-04-19
report | NLT
2024-04-20
report | NLT
2024-04-21
report | NLT
r...
Raw CAL displays:
no CAL raw files raw raw raw raw raw raw
P...
CAL product quality:
no CAL products products products products products products products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 1.96439 ADU VAL0.5,4.0 18 qc_ron this | last_yr | all ron, read mode = SlowPolarimetry, camera1
2 QC1DB MEDIAN 1.89548 ADU VAL0.5,4.0 18 qc_ron this | last_yr | all ron, read mode = SlowPolarimetry, camera2
3 QC1DB MEDIAN 1.87747 ADU VAL0.5,4.0 17 qc_ron this | last_yr | all ron, read mode = FastPolarimetry, camera1
4 QC1DB MEDIAN 1.85322 ADU VAL0.5,4.0 17 qc_ron this | last_yr | all ron, read mode = FastPolarimetry, camera2
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 1|
data source:sphere_zimpol_bias_pol
(QC1 database)
dataset:qc_ron
median:1.96439ADU
fixed thresholds:0.5...4.0ADU
N_data plotted:18
[click plot for closeup]
Plot 2
scores: 1|
data source:sphere_zimpol_bias_pol
(QC1 database)
dataset:qc_ron
median:1.89548ADU
fixed thresholds:0.5...4.0ADU
N_data plotted:18
[click plot for closeup]
Plot 3
scores: 1|
data source:sphere_zimpol_bias_pol
(QC1 database)
dataset:qc_ron
median:1.87747ADU
fixed thresholds:0.5...4.0ADU
N_data plotted:17
[click plot for closeup]
Plot 4
scores: 1|
data source:sphere_zimpol_bias_pol
(QC1 database)
dataset:qc_ron
median:1.85322ADU
fixed thresholds:0.5...4.0ADU
N_data plotted:17
[click plot for closeup]
This plot

This plot shows the read out noise (RON) from SPHERE ZIMPOL BIAS raw frames acquired in SlowPolarimetry and FastPolarimetry readmode. The values are not retrieved from the pipeline but are calculated by using a script.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
