VIMOS trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-08-22T03:36:24 (UT)
  | now: 2014-08-22T17:47:22 (UT) muc03 QC pipeline: vimos-2.9.13 (installed 2014-03-19)
same group: image_quality ellipticity   IQ_Q1 IQ_Q2 IQ_Q3 IQ_Q4
General news:
VIMOS news:
Report news:
DATE*: [?] 2014-08-15
report | NLT
2014-08-16
report | NLT
2014-08-17
report | NLT
2014-08-18
report | NLT
2014-08-19
report | NLT
2014-08-20
report | NLT
2014-08-21
report | NLT
P...
Product quality:
products products products products products products products
  no OPSLOG data

scores&comments | history ... | plot tutorial ... | contact                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB no MEDIAN 2.24 pix none  57 iq_mean_cell7 this | last_yr | all average image quality in cell 7 (upper left)
2 QC1DB no MEDIAN 2.23 pix none  57 iq_mean_cell9 this | last_yr | all average image quality in cell 9 (upper right)
3 QC1DB no MEDIAN 2.1 pix VAL2.0,2.4 57 iq_mean_cell5 this | last_yr | all average image quality in cell 5 (centre)
4 QC1DB no MEDIAN 2.23 pix none  57 iq_mean_cell1 this | last_yr | all average image quality in cell 1 (lower left)
5 QC1DB no MEDIAN 2.28 pix none  57 iq_mean_cell3 this | last_yr | all average image quality in cell 3 (lower right)
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: not implemented
data source:vimos_mask2ccd
(QC1 database)
dataset:iq_mean_cell7
median:2.24pix
thresholds:none
N_data plotted:57
[click on plot for closeup]
Plot 2
scores: not implemented
data source:vimos_mask2ccd
(QC1 database)
dataset:iq_mean_cell9
median:2.23pix
thresholds:none
N_data plotted:57
[click on plot for closeup]
Plot 3
scores: 9|
data source:vimos_mask2ccd
(QC1 database)
dataset:iq_mean_cell5
median:2.1pix
fixed thresholds:2.0...2.4pix
N_data plotted:57
[click on plot for closeup]
Plot 4
scores: not implemented
data source:vimos_mask2ccd
(QC1 database)
dataset:iq_mean_cell1
median:2.23pix
thresholds:none
N_data plotted:57
[click on plot for closeup]
Plot 5
scores: not implemented
data source:vimos_mask2ccd
(QC1 database)
dataset:iq_mean_cell3
median:2.28pix
thresholds:none
N_data plotted:57
[click on plot for closeup]
This plot

Trending plots for monitoring the VIMOS focus.

The daily focus check is performed on the same data that is measured to determine the mask to CCD coefficients. SExtractor is called to determine image quality (in pixels), ellipticity, and orientation of the pinhole images. There are two plots that show the mean values for each quadrant for image quality and ellipticity and four plots with the image quality in the centre and the corners of each quadrant.

The image quality is measured as the FWHM of the major axis of the pinhole ellipse. Please note that the mask to CCD calibrations are only measured once per day. Any change of the focus quality during the night cannot be seen. Science data should still be examined carefully in order to ensure nominal image quality.

Scoring is enabled only for averaged image quality, averaged ellipticity, and for the image quality in cell 5 (centre of each quadrant).

Especially for Q2 and Q3, ellipticity seems to be temperature dependent.

Template ID: img_tec_MaskToCcd. Pipeline recipe: vmmasktoccd (requires pipeline version 2.5.5 or higher).


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
