VIMOS trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-09-16T03:41:34 (UT)
  | now: 2014-09-16T06:15:41 (UT) muc03 QC pipeline: vimos-2.9.13 (installed 2014-03-19)
same group: QTH50_lamp He_lamp Ne_lamp Ar_lamp
General news:
VIMOS news:
Report news:
DATE*: [?] 2014-09-09
no data | NLT
2014-09-10
no data | NLT
2014-09-11
no data | NLT
2014-09-12
no data | NLT
2014-09-13
no data | NLT
2014-09-14
no data | NLT
2014-09-15
no data | NLT
P...
Product quality:
no products no products no products no products no products no products no products
  last OPSLOG data:
2014-09-01*

last files ...
monitor

scores&comments | history ... | plot tutorial ... | contact                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB yes (1) MEDIAN 1.08e+06 ADU/s VAL0.8E6,1.3E6 150 flux this | last_yr | all Q2, flux from IFU flats
2 QC1DB yes (1) MEDIAN 1.27e+06 ADU/s VAL1.0E6,1.5E6 150 flux this | last_yr | all Q1, flux from IFU flats
3 QC1DB yes (1) MEDIAN 1.38e+06 ADU/s VAL1.0E6,1.6E6 150 flux this | last_yr | all Q3, flux from IFU flats
4 QC1DB yes (1) MEDIAN 1.32e+06 ADU/s VAL1.0E6,1.6E6 150 flux this | last_yr | all Q4, flux from IFU flats
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 6|
data source:vimos_ifu_score
(QC1 database)
dataset:flux
median:1.08e+06ADU/s
fixed thresholds:800000.0...1300000.0ADU/s
N_data plotted:150
[click on plot for closeup]
Plot 2
scores: 6|
data source:vimos_ifu_score
(QC1 database)
dataset:flux
median:1.27e+06ADU/s
fixed thresholds:1000000.0...1500000.0ADU/s
N_data plotted:150
[click on plot for closeup]
Plot 3
scores: 6|
data source:vimos_ifu_score
(QC1 database)
dataset:flux
median:1.38e+06ADU/s
fixed thresholds:1000000.0...1600000.0ADU/s
N_data plotted:150
[click on plot for closeup]
Plot 4
scores: 6|
data source:vimos_ifu_score
(QC1 database)
dataset:flux
median:1.32e+06ADU/s
fixed thresholds:1000000.0...1600000.0ADU/s
N_data plotted:150
[click on plot for closeup]
This plot

Trending plot for the QTH50 FF lamp.

The lamp performance is measured using IFU spectroscopic flats. The same lamp is also used for MOS spectroscopic flats with HR grisms and imaging screen flats with U and B filters. The values should show smooth trending without sudden jumps.

Only day-time measurements with HR_orange are plotted. These are usually measured daily.

Template ID: ifu_cal_DayCalib: Pipeline recipe: vmifucalib.


General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
