VIMOS trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-10-23T03:35:45 (UT)
  | now: 2014-10-23T13:46:17 (UT) muc03 QC pipeline: vimos-2.9.13 (installed 2014-10-20)
same group: LR_blue LR_red MR HR_blue HR_orange HR_red
General news:
VIMOS news:
Report news:
DATE*: [?] 2014-10-16
report | NLT
2014-10-17
report | NLT
2014-10-18
report | NLT
2014-10-19
report | NLT
2014-10-20
report | NLT
2014-10-21
report | NLT
2014-10-22
report | NLT
P...
Product quality:
products products products products products products products
  no OPSLOG data

scores&comments | FULL | history ... | plot tutorial ... | contact               [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB no MEDIAN 0.2 none VAL0.1,0.25 22 efficiency4 this | last_yr | all efficiency at 4900A
2 QC1DB no MEDIAN 0.178 none VAL0.1,0.25 22 efficiency4 this | last_yr | all efficiency at 4900A
3 QC1DB no MEDIAN 0.179 none VAL0.1,0.25 22 efficiency4 this | last_yr | all efficiency at 4900A
4 QC1DB no MEDIAN 0.199 none VAL0.1,0.25 21 efficiency4 this | last_yr | all efficiency at 4900A
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 2|
data source:vimos_mos_std
(QC1 database)
dataset:efficiency4
median:0.2none
fixed thresholds:0.1...0.25none
N_data plotted:22
[click on plot for closeup]
Plot 2
scores: 2|
data source:vimos_mos_std
(QC1 database)
dataset:efficiency4
median:0.178none
fixed thresholds:0.1...0.25none
N_data plotted:22
[click on plot for closeup]
Plot 3
scores: 2|
data source:vimos_mos_std
(QC1 database)
dataset:efficiency4
median:0.179none
fixed thresholds:0.1...0.25none
N_data plotted:22
[click on plot for closeup]
Plot 4
scores: 2|
data source:vimos_mos_std
(QC1 database)
dataset:efficiency4
median:0.199none
fixed thresholds:0.1...0.25none
N_data plotted:21
[click on plot for closeup]
This plot

Trending plot for the overall MOS efficiency, measured using spectrophotometric standard stars.

The following settings are used:
LR_blue grism + OS-blue filter
LR_red grism + OS-red filter
MR grism + GG475 filter
HR_blue grism (without filter)
HR_orange grism + GG435 filter
HR_red grism + GG475 filter

A new HR_blue grism has been installed in March 2012. The plots for HR_blue show the efficiency at 5700A until 2011. From 2012 onwards, these plots are for the efficiency at 4500A.

Template ID: mos_cal_Specphot. Pipeline recipe: vmmosstandard.

Plots that show the efficiency vs. wavelength have been created by averaging several standard star measurements. They show the efficiency before and after the 2010 instrument upgrade. Measurements with the new HR_blue grism from March 2012 are included here.


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
