SPHERE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-04-24T04:53:35 (UT)
  | now: 2024-04-24T12:49:00 (UT) muc03 QC pipeline: spher-0.52.0 (installed 2024-03-22)
same group: LAMP SN-ratio RMS SHUTTER
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
SPHERE news: Note that the current Health Check monitor runs with an incomplete pipeline and an incomplete set of QC1 parameters. QCG can currently not guarantee completeness and significance at the usual level.
Report news:
DATE*: [?] 2024-04-17
report | NLT
2024-04-18
report | NLT
2024-04-19
report | NLT
2024-04-20
report | NLT
2024-04-21
report | NLT
2024-04-22
report | NLT
2024-04-23
no data | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw no CAL raw files
P...
CAL product quality:
products products products products products products no CAL products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 0.029744 ADU VAL0.001,0.2 14 qc_rms_iframe this | last_yr | all counts in V imaging flats, CAM1
2 QC1DB MEDIAN 0.017986 ADU VAL0.001,0.2 13 qc_rms_iframe this | last_yr | all counts in R imaging flats, CAM1
3 QC1DB MEDIAN 0.02135 ADU VAL0.001,0.2 13 qc_rms_iframe this | last_yr | all counts in I imaging flats, CAM1
4 QC1DB MEDIAN 0.01499 ADU VAL0.001,0.2 14 qc_rms_iframe this | last_yr | all counts in V imaging flats, CAM2
5 QC1DB MEDIAN 0.013005 ADU VAL0.001,0.2 13 qc_rms_iframe this | last_yr | all counts in R imaging flats, CAM2
6 QC1DB MEDIAN 0.01507 ADU VAL0.001,0.2 13 qc_rms_iframe this | last_yr | all counts in I imaging flats, CAM2
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 2|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_rms_iframe
median:0.029744ADU
fixed thresholds:0.001...0.2ADU
N_data plotted:14
[click plot for closeup]
Plot 2
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_rms_iframe
median:0.017986ADU
fixed thresholds:0.001...0.2ADU
N_data plotted:13
[click plot for closeup]
Plot 3
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_rms_iframe
median:0.02135ADU
fixed thresholds:0.001...0.2ADU
N_data plotted:13
[click plot for closeup]
Plot 4
scores: 2|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_rms_iframe
median:0.01499ADU
fixed thresholds:0.001...0.2ADU
N_data plotted:14
[click plot for closeup]
Plot 5
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_rms_iframe
median:0.013005ADU
fixed thresholds:0.001...0.2ADU
N_data plotted:13
[click plot for closeup]
Plot 6
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_rms_iframe
median:0.01507ADU
fixed thresholds:0.001...0.2ADU
N_data plotted:13
[click plot for closeup]
This plot

This plot shows the RMS retrieved from the ZIMPOL imaging master flats. It monitors potential changes in the flat field structure. The following setups are monitored:

  • V filter, DIT, NDIT = 4.0, 10
  • N_R filter, DIT, NDIT = 2.0, 20
  • N_I filter, DIT, NDIT = 2.0, 40

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
