SPHERE trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-05-02T04:53:27 (UT)
  | now: 2024-05-03T02:16:13 (UT) muc03 QC pipeline: spher-0.52.0 (installed 2024-03-22)
same group: LAMP SN-ratio RMS SHUTTER
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
SPHERE news: Note that the current Health Check monitor runs with an incomplete pipeline and an incomplete set of QC1 parameters. QCG can currently not guarantee completeness and significance at the usual level.
Report news:
DATE*: [?] 2024-04-26
report | NLT
2024-04-27
report | NLT
2024-04-28
report | NLT
2024-04-29
report | NLT
2024-04-30
report | NLT
2024-05-01
report | NLT
2024-05-02
report | NLT
r...
Raw CAL displays:
no CAL raw files raw raw raw raw raw no CAL raw files
P...
CAL product quality:
no CAL products products products products products products no CAL products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 302.774 ratio VAL200,1000 13 qc_SNR_iframe this | last_yr | all SN-ratio in V imaging flats, CAM1
2 QC1DB MEDIAN 458.901 ratio VAL200,1000 11 qc_SNR_iframe this | last_yr | all SN-ratio in R imaging flats, CAM1
3 QC1DB MEDIAN 653.735 ratio VAL200,1000 11 qc_SNR_iframe this | last_yr | all SN-ratio in I imaging flats, CAM1
4 QC1DB MEDIAN 323.381 ratio VAL200,1000 13 qc_SNR_iframe this | last_yr | all SN-ratio in V imaging flats, CAM2
5 QC1DB MEDIAN 505.021 ratio VAL200,1000 11 qc_SNR_iframe this | last_yr | all SN-ratio in R imaging flats, CAM2
6 QC1DB MEDIAN 714.664 ratio VAL200,1000 11 qc_SNR_iframe this | last_yr | all SN-ratio in I imaging flats, CAM2
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 2|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_SNR_iframe
median:302.774ratio
fixed thresholds:200...1000ratio
N_data plotted:13
[click plot for closeup]
Plot 2
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_SNR_iframe
median:458.901ratio
fixed thresholds:200...1000ratio
N_data plotted:11
[click plot for closeup]
Plot 3
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_SNR_iframe
median:653.735ratio
fixed thresholds:200...1000ratio
N_data plotted:11
[click plot for closeup]
Plot 4
scores: 2|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_SNR_iframe
median:323.381ratio
fixed thresholds:200...1000ratio
N_data plotted:13
[click plot for closeup]
Plot 5
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_SNR_iframe
median:505.021ratio
fixed thresholds:200...1000ratio
N_data plotted:11
[click plot for closeup]
Plot 6
scores: 1|
data source:sphere_zimpol_iflat_img
(QC1 database)
dataset:qc_SNR_iframe
median:714.664ratio
fixed thresholds:200...1000ratio
N_data plotted:11
[click plot for closeup]
This plot

This plot monitors the signal-to-noise ratio of the ZIMPOL imaging master lamp flat. The underlying assumption is, that all planes of the raw frame cube are illuminated with the same number of counts. The following setups are monitored:

  • V filter, DIT, NDIT = 4.0, 10 and 8.0, 8
  • N_R filter, DIT, NDIT = 2.0, 20 and 2.0, 8
  • N_I filter, DIT, NDIT = 2.0, 40 and 2.0, 8

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
