SPHERE trending system: HEALTH CHECK report
Last update: 2023-12-02T04:58:35 (UT)
[enable javascript for displaying time difference!]
General news:
NOTE: The Health Check and calChecker services will be moved to qcFlow in the course of 2023 on an instrument by instrument basis. The current pages will then not be updated any longer.
SPHERE news:
Note that the current Health Check monitor runs with an incomplete pipeline and an incomplete set of QC1 parameters.
QCG can currently not guarantee completeness and significance at the usual level.
Report news:
Plot? Symb? Source Average ? Thresholds ? N_ QC1 Data Remarks
method value unit method value
1
• QC1DB MEDIAN 0.892896 efficiency VAL 0.6,1.0 14 qc_med
this |
last_yr |
all
readmode = SlowPolarimetry, CAM=1
2
• QC1DB MEDIAN 0.783428 efficiency VAL 0.6,1.0 14 qc_med
this |
last_yr |
all
readmode = SlowPolarimetry, CAM=2
3
• QC1DB MEDIAN 0.797573 efficiency VAL 0.6,1.0 16 qc_med
this |
last_yr |
all
readmode = FastPolarimetry, CAM=1
4
• QC1DB MEDIAN 0.700118 efficiency VAL 0.6,1.0 16 qc_med
this |
last_yr |
all
readmode = FastPolarimetry, CAM=2
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1 scores: 2 |
data source: sphere_zimpol_modem_eff dataset: qc_med • median: 0.892896 efficiency fixed thresholds: 0.6...1.0 efficiency N_data plotted: 14 [click plot for closeup]
Plot 2 scores: 2 |
data source: sphere_zimpol_modem_eff dataset: qc_med • median: 0.783428 efficiency fixed thresholds: 0.6...1.0 efficiency N_data plotted: 14 [click plot for closeup]
Plot 3 scores: 2 |
data source: sphere_zimpol_modem_eff dataset: qc_med • median: 0.797573 efficiency fixed thresholds: 0.6...1.0 efficiency N_data plotted: 16 [click plot for closeup]
Plot 4 scores: 2 |
data source: sphere_zimpol_modem_eff dataset: qc_med • median: 0.700118 efficiency fixed thresholds: 0.6...1.0 efficiency N_data plotted: 16 [click plot for closeup]
This plot
The four boxes show the polarimetric phase modulation demodulation efficiency as calculated
by the pipeline recipe for
both detectors (CAM1 and CAM2) and
both readmodes (S= SlowPolarimetry and F=FastPolarimetry).
General information
Click on any of the plots to see a close-up version .
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked statistical averages are indicated by a solid line, and thresholds by broken lines outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ ↓ you can download the data for each parameter set if the 'Data downloads' link shows up
