VIMOS trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2013-05-25T03:36:47 (UT)
  | now: 2013-05-25T19:06:22 (UT) muc03 QC pipeline: vimos-2.9.7 (installed 2013-04-23)
same group: X0_Y0 XX_YY XY_YX   Y0_TEMP
General news: Click 'scores&comments' to switch to score details, and 'HC plot' to switch back to the graphics.
VIMOS news:
Report news: 2013-05-23 apparently mask insertion problems during during daily mask-to-CCD check [qc_vimos@eso.org]
DATE*: [?] 2013-05-18
report | NLT 		2013-05-19
report | NLT 		2013-05-20
report | NLT 		2013-05-21
report | NLT 		2013-05-22
report | NLT 		2013-05-23
report | NLT 		2013-05-24
report | NLT
P...
Product quality:
products products products products products products products
  last OPSLOG data:
2013-05-24*
last files ...
monitor

scores&comments | history ... | plot tutorial ... | contact                 daily/often; important to check     [?] 		*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 OPS?
**		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB yes (5) MEDIAN 995.8 pix VAL994,998 107 x0 this | last_yr | all coefficient x0, Q2
2 •QC1DB yes (6) MEDIAN 1023.6 pix VAL1022,1026 105 x0 this | last_yr | all coefficient x0, Q1
3 •QC1DB yes (5) MEDIAN 1103.0 pix VAL1102,1106 107 y0 this | last_yr | all coefficient y0, Q2
4 •QC1DB yes (6) MEDIAN 1041.4 pix VAL1040,1044 105 y0 this | last_yr | all coefficient y0, Q1
5 •QC1DB yes (5) MEDIAN 1016.4 pix VAL1014,1018 106 x0 this | last_yr | all coefficient x0, Q3
6 •QC1DB yes (7) MEDIAN 1026.8 pix VAL1025,1029 107 x0 this | last_yr | all coefficient x0, Q4
7 •QC1DB yes (5) MEDIAN 1409.4 pix VAL1407,1411 106 y0 this | last_yr | all coefficient y0, Q3
8 •QC1DB yes (7) MEDIAN 1363.0 pix VAL1361,1365 107 y0 this | last_yr | all coefficient y0, Q4
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 15|
data source:vimos_mask2ccd
(QC1 database)
dataset:x0•
median:995.8pix
fixed thresholds:994...998pix
N_data plotted:107
[click on plot for closeup]
Plot 2
scores: 14|
data source:vimos_mask2ccd
(QC1 database)
dataset:x0•
median:1023.6pix
fixed thresholds:1022...1026pix
N_data plotted:105
[click on plot for closeup]
Plot 5
scores: 14|
data source:vimos_mask2ccd
(QC1 database)
dataset:x0•
median:1016.4pix
fixed thresholds:1014...1018pix
N_data plotted:106
[click on plot for closeup]
Plot 6
scores: 15|
data source:vimos_mask2ccd
(QC1 database)
dataset:x0•
median:1026.8pix
fixed thresholds:1025...1029pix
N_data plotted:107
[click on plot for closeup]
Plot 3
scores: 15|
data source:vimos_mask2ccd
(QC1 database)
dataset:y0•
median:1103.0pix
fixed thresholds:1102...1106pix
N_data plotted:107
[click on plot for closeup]
Plot 4
scores: 14|
data source:vimos_mask2ccd
(QC1 database)
dataset:y0•
median:1041.4pix
fixed thresholds:1040...1044pix
N_data plotted:105
[click on plot for closeup]
Plot 7
scores: 14|
data source:vimos_mask2ccd
(QC1 database)
dataset:y0•
median:1409.4pix
fixed thresholds:1407...1411pix
N_data plotted:106
[click on plot for closeup]
Plot 8
scores: 15|
data source:vimos_mask2ccd
(QC1 database)
dataset:y0•
median:1363.0pix
fixed thresholds:1361...1365pix
N_data plotted:107
[click on plot for closeup]
This plot

Trending plots for monitoring the coefficients of the mask to CCD transformation.

The transformation is as follows:
X = a(xx)*x + a(xy)*y + x(0)
Y = a(yx)*x + a(yy)*y + y(0)
with (x,y) being mask coordinates in mm and (X,Y) CCD coordinates in pixel. X direction is along the slit orientation, y direction is perpendicular to the slits (i.e. in dispersion direction).

These trending plots show the time evolution of x(0) and y(0). x(0) should be within +/- 2 pixels around the average, y(0) within +/- 1 pixel. These thresholds are indicated in the plots. The procedure in case of violation of the thresholds is described on the SciOps Wiki pages.

Template ID: img_tec_MaskToCcd. Pipeline recipe: vmmasktoccd.

General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
