VIMOS trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-10-20T15:49:25 (UT)
  | now: 2014-10-21T02:45:45 (UT) muc03 QC pipeline: vimos-2.9.13 (installed 2014-10-20)
same group: LR_blue LR_red MR HR_blue HR_orange HR_red
General news:
VIMOS news:
Report news:
DATE*: [?] 2014-10-14
report | NLT
2014-10-15
report | NLT
2014-10-16
report | NLT
2014-10-17
report | NLT
2014-10-18
report | NLT
2014-10-19
report | NLT
2014-10-20
no data | NLT
P...
Product quality:
products products products products products products no products
  last OPSLOG data:
2014-10-18*

last files ...
monitor

scores&comments | history ... | plot tutorial ... | contact               [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB yes (1) MEDIAN 0.107 pix VAL0.05,0.14 43 ids_rms this | last_yr | all Q2, rms of dispersion solution
2 QC1DB yes (1) MEDIAN 0.11 pix VAL0.05,0.14 39 ids_rms this | last_yr | all Q1, rms of dispersion solution
3 QC1DB yes (1) MEDIAN 0.109 pix VAL0.05,0.14 44 ids_rms this | last_yr | all Q3, rms of dispersion solution
4 QC1DB yes (1) MEDIAN 0.106 pix VAL0.05,0.14 44 ids_rms this | last_yr | all Q4, rms of dispersion solution
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 8|
data source:vimos_mos_wave
(QC1 database)
dataset:ids_rms
median:0.107pix
fixed thresholds:0.05...0.14pix
N_data plotted:43
[click on plot for closeup]
Plot 2
scores: 6|
data source:vimos_mos_wave
(QC1 database)
dataset:ids_rms
median:0.11pix
fixed thresholds:0.05...0.14pix
N_data plotted:39
[click on plot for closeup]
Plot 3
scores: 8|
data source:vimos_mos_wave
(QC1 database)
dataset:ids_rms
median:0.109pix
fixed thresholds:0.05...0.14pix
N_data plotted:44
[click on plot for closeup]
Plot 4
scores: 8|
data source:vimos_mos_wave
(QC1 database)
dataset:ids_rms
median:0.106pix
fixed thresholds:0.05...0.14pix
N_data plotted:44
[click on plot for closeup]
This plot

Trending plot for rms of dispersion solution from MOS arc lamp measurements.

Only arc lamp measurements taken to calibrate MOS science observations are used; exposures with the standard star masks are disregarded.

Template ID: mos_cal_Arc (daytime), mos_cal_NightCalib (attached night-time). Pipeline recipe: vmspcaldisp.

Pipeline results for LR grisms are usually not reliable. This is mainly caused by multiplexing of the slits in the MOS masks. The rms of the dispersion solution shows, therefore, huge scatter and automated scoring is not possible. Interpretation of the rms plots for LR grisms requires experience.


General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
