FORS2 trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-08-28T02:21:36 (UT)
  | now: 2014-08-28T11:08:24 (UT) muc01 QC pipeline: fors2-4.9.24 (installed 2014-03-11)
same group: SCR_FF_RI SCR_FF_uv SCR_FF_b   SCR_FF_RMS_RI SCR_FF_RMS_uv SCR_FF_RMS_b
General news:
FORS2 news:
Report news:
DATE*: [?] 2014-08-21
report | NLT
2014-08-22
report | NLT
2014-08-23
report | NLT
2014-08-24
report | NLT
2014-08-25
report | NLT
2014-08-26
report | NLT
2014-08-27
report | NLT
P...
Product quality:
products products products products products products no products
  last OPSLOG data:
2014-08-24*

last files ...
monitor

scores&comments | history ... | plot tutorial ... | contact               [?]
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
OPS?
**
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB yes (0) MEDIAN 2.11e+04 ADU VAL14000,25000 25 efficiency this | last_yr | all lamp flux in ADU/sec for R_SPECIAL, chip 1
2 QC1DB yes (0) MEDIAN 2.2e+04 ADU VAL14000,25000 25 efficiency this | last_yr | all lamp flux in ADU/sec for R_SPECIAL, chip 2
3 QC1DB yes (0) MEDIAN 6.75e+03 ADU VAL4000,12000 25 efficiency this | last_yr | all lamp flux in ADU/sec for I_BESS, chip 1
4 QC1DB yes (0) MEDIAN 8.38e+03 ADU VAL4000,12000 25 efficiency this | last_yr | all lamp flux in ADU/sec for I_BESS, chip 2
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 3|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:2.11e+04ADU
fixed thresholds:14000...25000ADU
N_data plotted:25
[click on plot for closeup]
Plot 2
scores: 3|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:2.2e+04ADU
fixed thresholds:14000...25000ADU
N_data plotted:25
[click on plot for closeup]
Plot 3
scores: 3|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:6.75e+03ADU
fixed thresholds:4000...12000ADU
N_data plotted:25
[click on plot for closeup]
Plot 4
scores: 3|
data source:fors2_scrflat
(QC1 database)
dataset:efficiency
median:8.38e+03ADU
fixed thresholds:4000...12000ADU
N_data plotted:25
[click on plot for closeup]
This plot

The FlatBlue+1 and FlatBlue+2 lamps are used for imaging screen flats.
The RMS is calculated from the master screen flat image pixel sample (2x2 binning) X: @200 @1800 and Y: @400 @800 covering the unvignetted area of chip1 and chip2.


General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
